Makita Spare Parts for Angle Grinder GA4541

Makita genuine spare parts or replacements parts for to repair Angle Grinder GA4541

In the following table, look for the model of the Angle Grinder and the respective parts of the code.
Makita GA4541

Angle Grinder GA4541
1 168705-9 GEAR BOX FOR GA
2 252186-8 NUT M6 X 9554NB
3 253077-6 WASHER P. 6 4300 / 01BV
4 227591-8 GEAR FOR 10 GA
5 211142-7 BEARING 6001LLB X GD0800C
6 141981-0 COVER GEAR BOX
7 234230-3 SPRING COMPRESSION 33
8 141515-9 BRAKE HOLDER
9 326132-8 PLATE BRAKE
11 240135-7 FAN 60B
12 515369-4 ARMATURE
13 681656-4 INSULATOR X GD0810C
14 253823-7 ROND. FLAT 7 X JS1600
15 210027-4 BEARING 627DDW X 9561CV
16 421738-8 RING LABYRINTH 22 X 9561CV
20 455351-0 SPACER
22 453375-0 DEFLETTORE B
23 266258-3 SCREW 4 X 70 X 9564
24 344871-8 RETAINING X GD0800C
25 626649-4 STATOR GA SERIES
27 194074-2 CARBON BRUSHES CB-325 X 9554NB
28 266007-8 SCREW M3 X10 HP2030
29 643769-9 BRUSHES HOLDER
30 453376-8 HOUSING MOTOR B
31 266326-2 SCREW 4x18 X MT601
32 687169-3 CLAMP HP1620
33 638949-0 SWITCH HOLDER
35 682559-5 SAVE CABLE X 6822
36 266326-2 SCREW 4x18 X MT601
38 453364-5 BACK COVER FOR GA
40 651418-4 SWITCH ST115A-40 X 9541
42 233071-4 SPRING COMPRESSION 4 X 9541
43 453847-5 LEVER SWITCH
44 453377-6 KEY SWITCH B
45 346557-0 PLATE SWITCH
46 453369-5 BUTTON
47 234057-1 SPRING COMPRRESSION 6 GA5021C
48 266467-4 SCREW 4X50 FS2500K
49 213032-0 RING 4 X GA4530
50 256535-1 PLUG FOR 6 GA
51 263002-9 RUBBER PLUG 4
52 210026-6 BALL BEARING 696ZZ
53 961005-4 RETAINING RING S9
54 253180-3 FLAT WASHER 10 X 6221DW
55 310577-0 JOINT
56 346556-2 C PLATE FOR GA
57 227592-6 GEAR FOR 38 GA
58 313228-4 JUNCTION FOR GA
59 210302-8 BEARING 6903ZZ FOR GA
60 253744-3 ROND.PIANA 12 24B / 12N / 14
61 263002-9 RUBBER PLUG 4
62 213641-5 RING FOR 51 GA
63 318839-0 BOX BEARING B
64 265490-6 SCREW M4 X 16 X 9561CV
65 211129-9 BALL BEARING NSK 6201DD
66 267279-8 FLAT WASHER 21 X HR2450FT
67 443124-3 FELT RING 17 GD0600
68 285854-8 RETAINING BEARING 20-33
69 962105-3 RETAINING RING R26
70 326133-6 POST
71 310514-4 FLANGE POST
72 123144-0 WHEEEL GUARD GA SERIES
73 224447-6 FLANGE INTERNAL 42B P99
74 224554-5 EXTERNAL FLANGE 14-45 X 9541 P08
75 135555-7 JUNCTION CPL P99
