Lavor Pressure Cleaner LKX 31 86110134 Spare Parts
Fix Your Pressure Cleaner 86110134 - LKX 31 M'00 230/60 CM-G- C/REG.PORT. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee
In the following tables, look for the spare part and its respective code.
| 86110134-1 - IDRO LKX 31 M'00 230/60 CM-G- C/REG.PORT Pag.1 | ||
| # | Part Num. | Description |
| 001 | 3.002.0122 | SCREW M6X12ZNT |
| 002 | 4.613.0111 | JOLLY5/LKX YELLOW UPPER HOUSING |
| 003 | 4.608.0203 | TANK FOR GAS OIL/DETERGENT |
| 004 | 4.612.0029 | CABLE |
| 005 | 4.608.0073 | SHORT SPACER FOR TANK JOLLY 4/ 93 |
| 006 | 5.009.0032 | UNLOADER OIL CAP 3/8 PLASTIC W ITH GASKET |
| 007 | 4.608.0074 | LONG SPACER FOR TANK JOLLY 4/9 3 |
| 008 | 5.613.0096 | BOILER AXLE JOLLY 4/93 |
| 010 | 3.200.0038 | O-RING GASKET 53,65X2,62 REF.3 212 |
| 011 | 5.613.0115 | BACK AXLE |
| 012 | 6.605.0168 | WHEEL D.260X85 BLACK |
| 013 | 4.608.0434 | WHEEL COVER |
| 014 | 5.009.0340 | QUICK COUPLING ASSY +GASKET+RING NUT |
| 015 | 3.100.0043 | 3/8 M ROTATING QUICK COUPLING |
| 016 | 4.618.0012 | H.P. HOSE 5/16 310BAR 10mt |
| 017 | 3.700.0029 | RL35 GUN 3/8+S3+ADAPT+REG 30158500 |
| 018 | 3.701.0015 | LANCE INOX L.700 +PL4/1+WASHER+ QUICK CONN.M22 |
| 019 | 3.103.0052 | HIGH PRESSURE NOZZLE 1/8M 15055 (C25055) |
| 8611X091-1 - IDRO LKX 31 M'00 230/60 BASE Pag.2 | ||
| Pos. | Codice | Description |
| 002 | 4.608.0079 | DASHBOARD '93 WITH COMPLETE SI LKSCREEN |
| 003 | 4.608.0019 | BLACK THERMOSTATE KNOB 3079/1 |
| 004 | 4.608.0019 | BLACK COCK KNOB 3081/1 |
| 005 | 3.403.0091 | THERMOSTAT 30/150 BULB 6,5 |
| 006 | 3.105.0003 | DETERGENT REGULATING COCK WITH RUBBER HOLDER D.7 |
| 007 | 4.608.0065 | BOX DASHBOARD '93 |
| 008 | 4.608.0071 | GUIDING CABLE COVER DASHBOAR D '93 |
| 009 | 5.009.0165 | SWITCH SEALING SURROUND |
| 010 | 5.009.0165 | TIN SWITCH COVER |
| 011 | 3.401.0027 | MICRO-SWITCH ABT WF 200 CO |
| 012 | 5.009.0213 | DOUBLE-POLE SWITCH |
| 013 | 5.613.0156 | SWITCH SUPPORT |
| 015 | 3.107.0004 | PRESS.GAUGE DIAM.50 0/250 1/4 REAR+CLAMP |
| 016 | 4.618.0014 | PRESSURE GAUGE TUBE DN 2X330TG |
| 017 | 4.008.0556 | TRANSPARENT HOSE D.6x12 L=400 REINFORCED |
| 018 | 3.099.0282 | TWO-WIRES WRAPPER FOR 6X12 HOSE (15126) |
| 019 | 3.405.0023 | JUNCTION BOX |
| 020 | 4.608.0078 | GASKET |
| 025 | 5.611.0002 | COMPLETE FLANCE FOR BURNER |
| 026 | 4.607.0001 | GLOW PLUG RESTANT PLATE 15X32 |
| 027 | 4.614.0004C | ELECTRODE O772589000 |
| 028 | 3.100.0017 | ELBOW 4 1/8 COPPER TUBE |
| 029 | 3.099.0015 | RING SEEGER I D.21 SP1 DIN 472 |
| 030 | 4.608.0002 | SITE GLASS DIAM.20 SP.1,8 |
| 031 | 4.605.0001 | WROUGHT BURNER FLANGE |
| 032 | 3.104.0028 | GAS OIL NOZZLE 1,25 60/A |
| 033 | 4.606.0064 | COVER FIXING STUD |
| 034 | 4.616.0006 | COPPER TUBE DIAM.4 COMPACT |
| 035 | 6.605.0105 | TRANSFORMER 220/60 818C/S1 WITH CABLE L=600 W.FASTON |
| 036 | 4.607.0011 | MOTOR FOOT CLAMP |
| 037 | 5.609.0023 | FAN PROTECTION CAGE ASSY |
| 038 | 4.608.0036 | FEEDING CABLE CONNECTOR |
| 039 | 4.608.0068 | GUIDING HANDLE COMPACT 4P |
| 040 | 5.613.0119 | HANDLE SUPPORT |
| 041 | 4.608.0103 | GASOIL PUMP PROTECTING CARTER |
| 042 | 3.099.0018 | FAN WITH HOLDER |
| 043 | 3.300.0005 | 100W/230-60 BURNER MOTOR |
| 044 | 6.605.0173 | GAS OIL PUMP PLASTIC COUPLING |
| 045 | 3.100.0015 | STRAIGHT CONNECT.1/8M. FOR COP P.TUBE D.4 |
| 046 | 3.551.0062 | GAS OIL PUMP SINGLE HOSE+ELECT RODE 220V |
| 047 | 3.004.0015 | PLAIN WASHER D.22X39X3 UNI6592 |
| 048 | 4.606.0013 | COIL FIXING NUT 1/2 BRASS SPE C. |
| 049 | 5.611.0067 | TEKNA '95 DIESEL FILTER UNIT |
| 050 | 4.618.0035 | TUBE R1 PUMP/COIL TG480 |
| 051 | 4.618.0043 | HOSE |
| 052 | 5.611.0012 | EXTERNAL BURNER COVER DIAM.341 |
| 053 | 5.611.0099 | RUBBER COATED CABLE L=480 WITH PROTECT. |
| 054 | 3.003.0010 | BLIND NUT E. M6 UNI 5721 BRASS |
| 055 | 3.004.0006 | PLAIN WASHER D.6.4X12X1.6 GALVANIZED UNI6592 |
| 056 | 5.613.0147 | BOILER OUTWARD COVER |
| 057 | 5.610.0105 | BUNCHER WITH TAPER D.82 WITH H OLES |
| 058 | 5.613.0122 | INTERNAL COVER COMBUSTION CHAMBER CHIMNEY L=90 |
| 059 | 4.604.0001 | COIL TOP H.335 |
| 060 | 5.613.0118 | BOILER BODY |
| 061 | 6.605.0247 | RIGID REFRACTORY BOTTOM D.290 DENS.280 |
| 062 | 6.605.0247 | CHEESY REFRACTORY BOTTOM D.290 DENS.64 |
| 063 | 4.607.0006 | COIL FIXING STRIP PLATE 20/1 0 |
| 064 | 4.608.0162 | GASKET WITHOUT AMIANTH. FOR BO ILER ESP.2 |
| 065 | 5.613.0116 | BOILER BASE |
| 074 | 4.618.0041 | LOW PRESS. PIPE D.19X10 L=470 |
| 087 | 5.609.0059 | THERMOSTAT BODY |
| 088 | 4.608.0003 | RING NUT D17XM22 EXHAUST.RAPID LINKAGE |
| 089 | 3.100.0018 | RAPID COUPLING 3/8M-1/2M 08 (GALVANIZED BRASS) |
| 090 | 4.606.0038 | ADJUSTING SCREW FOR SAFETY VALVE |
| 091 | 4.606.0087 | THERMOST.BULB BODY AND SAFETY VALVE |
| 092 | 3.100.0020 | REDUCTION M.GAS/M.GAS 1/2-3/8 |
| 093 | 5.613.0282 | THERMOSTATE BULB HOLDER JOLLY 4/93 |
| 094 | 4.606.0019 | SUCTION CONNECTOR M22 IDRO COM PACT |
| 095 | 4.008.0031 | INLET WATER FILTER H2O D.16 CONICAL |
| 097 | 4.618.0030 | TUBE B.P. D.20X10 3/8M-3/8M. L .450 |
| 56010174-1 - MOTOPOMPA LWM 230/60 4P HP3 LWS-K 3025 S SX Pag.3 | ||
| Pos. | Codice | Description |
| 000 | 5.601.0070 | LWM 230/50 4P KW.3 LW3025 |
| 000 | 5.601.0065 | LWM 400/60 5,5HP 4P W154 |
| 002 | 3.404.0007 | CAPACITOR 65mF 450V D.50XL120 W/WIRES AND FASTON MALE |
| 004 | 3.004.0010 | WASHER D6X11 Sp0,7 DIN6798A ZN T |
| 005 | 4.607.0008 | TIE ROD MOTOR LW M6X160 |
| 006 | 3.003.0019 | NUT |
| 007 | 3.406.0012 | CABLE HOLDER PLATE PG.16 |
| 008 | 3.410.0008 | TERMINAL BOX COVER |
| 009 | 3.405.0005 | TERMINAL BOX |
| 010 | 3.299.0004 | GASKET |
| 011 | 4.606.0081 | MOTOR CHOCK DIAM.150 H 14 |
| 012 | 4.607.0019 | PLATE FOR TERMINAL BOX HOLDER |
| 013 | 3.002.0131 | SCREW TSPEI M8X16 CL.10,9 UNI5933 ZNT |
| 014 | 4.607.0010 | MOTOR PUMP COUPLING FLANGE |
| 015 | 3.100.0022 | REDUCTION M.GAS/M.GAS 3/8 1/4 |
| 016 | 3.704.0006 | PRESSURE SWITCH PS2 1/8M 25BAR |
| 017 | 3.554.0023 | LWS-K 3025 S LEFT 1750 RPM -6301135100- PUMP |
| 018 | 4.606.0088 | RUBBER HOLDER 1/4 G M D.7 |
| 020 | 3.106.0034 | SECURITY VALVE G1/4 M D6 200 BAR |
| 021 | 4.007.0181 | COUPLING FOR SECURITY VALVE |
| 022 | 4.618.0035 | TUBE R1 PUMP/COIL TG480 |
| 023 | 4.618.0030 | TUBE B.P. D.20X10 3/8M-3/8M. L .450 |
| 024 | 3.100.0046 | REDUCTION F3/8 CIL.M1/2 CIL.SV |
| 025 | 3.003.0007 | EXAGONAL NUT M6 MEDIA UNI 5588 CL10 ZNT |
| 026 | 3.004.0035 | WASHER GROWER D.6 UNI1751 ZNT |
| 027 | 4.605.0003 | ANTERIOR CALOTTE MOTOR LW D. 1 50 |
| 028 | 3.002.0050 | HEXAGON HEAD SCREW M6X25 UNI 5739 ZNT M6X25 UNI 5739 ZNT |
| 029 | 3.001.0009 | BEARING 6007-2Z |
| 030 | 5.605.0047 | ROTOR SHAFT ALL.LW |
| 031 | 5.602.0022 | CARCASSA LWM 230/60 4P 150X90 H130 FORATA |
| 032 | 3.001.0010 | BEARING 6205-2Z |
| 033 | 3.099.0017 | UNLOADING RING D.51XD.42 |
| 034 | 6.005.0194 | PASTERIOR CALOTTE MOTOR LW.V D .150 |
| 035 | 3.099.0018 | FAN WITH HOLDER |
| 036 | 4.607.0082 | FAN COVER |
| 037 | 5.606.0149 | NEW MOTOR LWM 230V/60HZ D.150 H130 4 POLES BUY WITH 037A-037B-037C |
| 037A | 4.608.0294 | NEW FAN COVER BUY WITH 037-037B-037C |
| 037B | 3.099.0240 | NEW FAN BUY WITH 037-037A-037C |
| 037C | 4.605.0105 | NEW COUPLING FLANGE BUY WIYH 037-037A-037B |
| 038 | 5.601.0174 | LWM 230/60 4 POLES HP3 LWS-K 3025 S LEFT MOTORPUMP |
| 054 | 4.006.0109 | TAPERED 1/8 CAP |
| 055 | 5.609.0080 | SEAL SEAT ASSY +OR |
| 065 | 5.609.0199 | HOLD-ROD ASSY FOR BRASS HEAD |
| 066 | 4.607.0206 | PLATE FOR SPRING |
| 067 | 4.607.0207 | SPRING PRESSURE REGULATION |
| 068 | 4.606.0206 | PRESSURE REGULATION KNOB |
| 069 | 3.200.0046 | O-RING 21,95X1,78 REF.2087 |
| 070 | 3.099.0136 | PIN 2X12 UNI 1708 |
| 3554BY23-1 - POMPA LWS-K 3025 S SX 1750 rpmBY-PASS Pag.4 | ||
| Pos. | Codice | Description |
| 001 | 3.555.0002 | HEAD D.18 3218.0315.00 |
| 002 | 3.555.0076 | HEAD CAP G1/8 3202.0018.00 |
| 003 | 3.002.0455 | SCREW M6X55 3609.0152.00 |
| 004 | 3.555.0005 | OR 2.62X17.13 1210.0046.00 |
| 005 | 3.555.0028 | VALVE PLATE SEAT 3009.0087.00 |
| 006 | 3.555.0007 | STEEL PLATE FOR VALVE 3604.0017.00 |
| 007 | 3.555.0028 | VALVE SPRING 1802.0177.00 |
| 008 | 3.555.0028 | VALVE CAGE 1205.0025.00 |
| 009 | 3.200.0027 | OR 2.62X20.24 FOR CAP 1210.0048.00 |
| 010 | 3.555.0012 | VALVE CAP 3202.0155.00 |
| 011 | 3.002.0227 | SCREW M5X10 3609.0088.00 |
| 012 | 3.555.0057 | CLAMP FOR CAP 1004.0012.00 |
| 013 | 3.555.0056 | SMALL COVER 0402017200 |
| 014 | 3.200.0219 | O-RING 44.03X3.53 |
| 015 | 3.555.0079 | SPACER 3019.0011.00 |
| 016 | 3.001.0085 | RADIAL SPHERE BEARING 20X52X15 6304 HIGH QUALITY |
| 017 | 6.605.0115 | PUMP HOUSING 0403.0128.00 |
| 020 | 3.555.0046 | HEAD RING D.18 0009019300 |
| 021 | 3.555.0047 | O-RING D.18 1241002200 |
| 022 | 3.555.0048 | O-RING 18X25X5.5 1241002800 |
| 023 | 3.555.0049 | HOLDER RING FOR SEAL D.18 0009019700 |
| 024 | 3.555.0085 | O-RING 1,78X26,7 1210022300 |
| 025 | 6.605.0111 | OIL GASKET KIT |
| 026 | 3.555.0059 | NUT 0600.0048.00 |
| 027 | 3.555.0060 | WASHER 8.2X14X1.5 2811008000 |
| 028 | 3.555.0027 | PISTON D.18 0202.0018.00 |
| 029 | 3.555.0062 | WASHER FOR PISTON BASE 2812003800 |
| 030 | 3.200.0043 | OR-1.78X6.07 1210.0055.00 |
| 031 | 3.555.0064 | PISTON GUIDE 2409.0044.00 |
| 032 | 4.607.0534 | WRIST PIN |
| 033 | 4.606.0215 | CONNECTING ROD 0205.0050.00 |
| 034 | 3.555.0067 | GASKET 3019.0033.00 |
| 035 | 3.555.0143 | OIL LEVEL INDICATOR 3201.0010.00 |
| 036 | 3.555.0069 | OR 1.78X23.52 1210.0333.00 |
| 037 | 3.555.0070 | OR 2.62X101.27 1210.0206.00 |
| 038 | 6.605.0115 | HOUSING COVER 0402014200 |
| 039 | 3.555.0088 | SCREW M6X25 3609.0041.00 |
| 040 | 6.005.0306 | OIL SEAL SHAFT 25X62X10 |
| 041 | 6.605.0113 | SEEGER KIT D.25 |
| 042 | 6.605.0114 | SEEGER KIT D.62 |
| 043 | 3.001.0084 | RADIAL SPHERE BEARING 25X62X17 |
| 044 | 3.555.0072 | KEY 8X7X28 1602.0045.00 |
| 045 | 3.555.0134 | SHAFT D.24 0001.0294.00 |
| 046 | 3.099.1480 | OIL CAP (L=58 STICK) |
| 047 | 3.555.0016 | CAP 3/8G |
| 051 | 3.555.0013 | WASHER 21.2X27.1X1.5 |
| 061 | 3.555.0028 | VALVE ASSY 1220.0030.00 |
| 062 | 3.555.0028 | COMPLETE VALVE KIT 5025.0011.00 |
| 063 | 3.555.0024 | WATER SEAL KIT FOR LW 3525 5019003700 |
| 064 | 3.555.0027 | PISTON KIT LW 3525 2409.0072.00 |
| 065 | 3.555.0025 | OIL VALVE KIT FOR LW 5019004000 |
| 066 | 3.200.0046 | O-RING 21,95X1,78 REF.2087 |
| 067 | 4.606.0206 | PRESSURE REGULATION KNOB |
| 068 | 3.099.0136 | PIN 2X12 UNI 1708 |
| 069 | 4.607.0207 | SPRING PRESSURE REGULATION |
| 070 | 4.607.0206 | PLATE FOR SPRING |
| 071 | 4.607.0204 | D.11 PISTON esp.03 |
| 073 | 4.608.0326 | PARBAK 8-011 N 300-90 X OR 203 |
| 074 | 4.606.0092 | REGULATOR COUPLING |
| 075 | 3.200.0005 | O-RING 15,6X1,78 SHORE 70 REF.2062 |
| 076 | 3.200.0071 | OR GASKET 11,1X1,78 SH 90 |
| 077 | 3.200.0020 | OR 2.90X1.78 SHORE 90 |
| 078 | 4.607.0371 | FIXING ROD AISI 420C-W |
| 079 | 4.606.0108 | CONTROL ROD FOR TS |
| 080 | 5.609.0080 | SEAL SEAT ASSY +OR |
| 081 | 5.609.0199 | HOLD-ROD ASSY FOR BRASS HEAD |
| 082 | 6.005.0030 | DETERG.INJECT.HOSE FITTING |
| 083 | 3.005.0001 | BALL INOX 420 DIAM.5 DEGREE OF ACCURACY G 500 |
| 084 | 4.007.0014 | DETERG.STOP VALVE SPRING 4X8 ESP.3 |
| 085 | 5.609.0079 | OUTLET COUPLING FOR BRASS HEAD |
| 086 | 4.007.0324 | STOP VALVE SPRING D.6X20 |
| 087 | 5.609.0041 | NON RETURN VALVE + OR ASSEMBLY |
| 088 | 5.609.0158 | CONNECTION FOR CAP |
| 089 | 3.200.0007 | O-RING GASKET 3.69X1.78 NBR 70SH REF.2015 |
| 090 | 3.200.0010 | O-RING 7,66X1,78 |
| 091 | 4.006.0109 | TAPERED 1/8 CAP |
| 092 | 5.609.0158 | 1/8 G COUPLING FOR MICRO HOLDER BOX |
| 097 | 3.555.0015 | WASHER 16.7X22X1.5 2811008400 |
| 098 | 3.555.0014 | BRASS CAP G1/2 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s LAVOR websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to LAVOR brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Lavor LKX 31 - 86110134
6 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N LAVOR:
- LAVOR S/N START WITH (8. ) and have 8 DIGITS
New
You might also like
Comments (0)
No customer reviews for the moment.
Viewed products
Customers who bought this product also bought:
16 other products in the same category:
Lavor Pressure Cleaner LKX 31 86110134 Spare Parts
Lavor original spare parts for to replace broken parts for to fix Cold Water High Pressure Cleaner 86110134 - LKX 31 M'00 230/60 CM-G- C/REG.PORT.Fix Your Pressure Cleaner LKX 31 M'00 230/60 CM-G- C/REG.PORT. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee
