Lavor FKX 1123 Pressure Cleaner Parts
€1.73
Tax included
Lavor Original Parts for Pressure Cleaner FKX 1123
Lavor original spare parts for to replace broken parts for to fix Hot Water High Pressure Cleaner FKX 1123 230/50 TS -G- C/ AVV. LWS - 8.052.0602Fix Your Pressure Cleaner. All Spares are Ready For Quick Delivery. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Lavor Original Parts for Pressure Cleaner FKX 1123
Lavor original spare parts for to replace broken parts for to fix Hot Water High Pressure Cleaner FKX 1123 230/50 TS -G- C/ AVV. LWS - 8.052.0602In the following tables, look for the spare part and its respective code.
| IDRO FKX 1123 230/50 TS -G- C/ AVV. LWS - 8.052.0602 | ||
| Pag.1 | ||
| # | Part Num | Description |
| 1 | 3.002.0147 | TC-TC SCREW M6X35 ZNT UNI 7687 |
| 2 | 4.013.0305 | UPPER FAIRING FKX -G- PANT.108C INJECTION |
| 3 | 3.002.0099 | TC-TC SCREW M6X55 UNI 7687 ZNT |
| 4 | 3.004.0007 | FLAT WASHER D.6X18 Th.2 ZNT UNI6593 |
| 5 | 6.005.0650 | KIT 135 BLACK FKX TANK WITH CAP |
| 6 | 5.013.0039 | COVERED FINISHED HANDLE FOR FKX WITH HOSE REEL |
| 7 | 4.008.0444 | TRANSPARENT HOSE 6X9 L=340mm |
| 8 | 4.008.0006 | DETERGENT FILTER |
| 9 | 3.002.0028 | TC-TC SCREW M4X12 UNI 7687 ZNT |
| 10 | 4.008.0277 | FIXED WALL CABLE CLIP (LWS) |
| 11 | 4.008.0751 | FKX FUEL TANK CAP 1" 1/4 G EXP.00 |
| 12 | 4.012.0150 | H05VV-F CABLE 3X1.5 MT. 5.4 THICKNESS SCHUKO SPLASHPROOF F/F |
| 13 | 4.008.0296 | WHEEL D.200 MOZ. D.15 SPI200 STRAIGHT BEAT |
| 14 | 3.099.0020 | WHEEL CLIP D.28.3 FOR AXLE D.15 |
| 15 | 3.099.0101 | WHEEL BOSS FOR SP200 - BLACK- |
| 16 | 3.099.0120 | PLASTIC CAP FOR FKX DETERGENT TANK |
| 17 | 3.700.0036 | S'02C GUN 3/8'-M22 |
| 18 | 4.018.0056 | HOSE 1/4 21MPa L=8000 R1 3/8 G-3/8 G 90° FOR FKX STARTER |
| 19 | 3.712.0018 | LANCE WITHOUT COVER A/B 1.15 -G- M22 HOT (MAX 220BAR 3200PSI) |
| 21 | 5.012.0116 | CRANK HANDLE KIT + 5 SCREWS FOR HW HOSE REEL |
| 22 | 4.008.0517 | HALF CRANK CRANK SIDE |
| 23 | 3.099.0158 | IDLE RING 3/8 CH20 REF. E4890003 |
| 24 | 4.008.0516 | HALF CRANK INLET SIDE |
| 31 | 4.018.0090 | HOSE 1/4 21MPa L=590 R1 FOR FKX STARTER W/PIN/OR/SEEGER |
| 32 | 5.012.0122 | HOSE HOLDER KIT + HANDLE SCREWS + FKX PIN |
| MOTOR PUMP PT'02 110h100 230/50D.12 9'16 TS IN.1,8 (X FKX) Pag.2 | ||
| 1 | 5.009.0213 | SWITCH ASSEMBLY 0/1 BEEP 12(10)A + TRANSPARENT PROTECTION |
| 2 | 3.406.0004 | PG.11 TEARPROOF CABLE GLAND |
| 4 | 3.002.0135 | TC-TC SELF-TAPPING SCREW 2.9X13 UNI 6954 ZNT |
| 5 | 3.404.0017 | CAPACITATOR 25mF 450V D.39X94 F/M |
| 6 | 4.008.0618 | LOWER RUBBER SEAL FOR ELECTRIC BOX |
| 7 | 4.008.0583 | FAN COVER FOR '96 MOTOR WITHOUT GRILLE |
| 8 | 3.099.0049 | STOP RING D.23 FOR FAN |
| 9 | 4.008.0714 | LOWERED PARTNER FAN h24 BLACK |
| 10 | 5.006.0171 | '02 CASING D110H100 230/50 2P (THERMAL WIRES) FOR FKX |
| 11 | 3.001.0033 | RADIAL BEARING BALLS 6003 2RS (17x35x10) |
| 12 | 5.005.0049 | ROTOR SHAFT D.55 H.100 CYL. |
| 13 | 3.002.0115 | TCEI SCREW M5X35 TRILOBAL ZNT |
| 14 | 5.009.0166 | FRONT MOTOR FLANGE 110'96 PART |
| 15 | 3.201.0008 | OIL SEAL RING D.17X35X7 |
| 16 | 3.001.0030 | RADIAL BALL BEARING 6303 (17X47X14) |
| 17 | 4.005.0169 | PLATE 9'16 CYLINDRICAL BORE PISTON D.12 |
| 18 | 3.001.0003 | AS4565 AXIAL BEARING BEARING |
| 19 | 3.001.0025 | NEEDLE ROLLER CAGE TYPE AXK4565 - STEEL- |
| 20 | 4.007.0001 | THRUST SHOE D.65X30X6 (C10PB) FINISHED |
| 21 | 5.009.0452 | STOP/PISTON ASSEMBLY D.12 GROUND PARTNER |
| 22 | 3.200.0014 | GASKET OR 85 X 2.5 NITRILE |
| 23 | 4.007.0025 | SPRING RECALL X PISTON D.14-12 ESP.07 |
| 24 | 5.009.0516 | MICRO SWITCH ASSEMBLY + TS CABLE MACH USA/EU |
| 25 | 4.006.0270 | TOTAL STOP VALVE CONNECTOR COMP. '02 |
| 26 | 4.006.0269 | BRASS SPACER FOR SPRING V. COMP. '03 |
| 27 | 4.007.0284 | ROD RETURN SPRING V. COMP. '02 D.7.3 L=11 THREAD D.1.3 |
| 28 | 3.200.0021 | OR SEAL 6.75x1.78 NBR SH.70 |
| 29 | 4.008.0782 | MICRO SWITCH CONTROL ROD FOR NEW V. COMP. |
| 30 | 4.007.0305 | TSPEI SCREW M3x25 A2-70 AISI304 W/3M-SCOTCH-GRIP 2353 |
| 31 | 4.006.0272 | SEAL SEAT WITH SPACER |
| 32 | 3.200.0113 | OR SEAL 15.08x2.62 NBR SH.70 |
| 33 | 4.007.0298 | TS SPRING V. COMP. '02 110h100 D.6.6-10.2 L 22.7 THREAD 1.8 |
| 34 | 4.006.0268 | PISTON DIAM. 11 IN BRASS FOR COMP. VALVE '02 |
| 35 | 3.200.0059 | OR SEAL 7.66x1.78 NBR SH.82 |
| 36 | 4.608.0326 | ANTI-EXTRUSION RING DIM. 8x11 x1.5 |
| 37 | 4.006.0273 | EXTERNAL PISTON SEAT AND CHECK VALVE |
| 38 | 3.200.0118 | OR SEAL 14x1.78 NBR SH.90 |
| 39 | 3.200.0029 | OR SEAL 18.72x2.62 SH.70 REF. 3075 |
| 42 | 5.009.0503 | HOSE CONNECTOR FOR DETERGENT SUCTION M10 WITH O-RING |
| 44 | 3.005.0001 | BALL D.5 STAINLESS STEEL 420 (precision grade G 500) |
| 45 | 4.007.0014 | EXTERNAL SPRING FOR DETERGENT CHECK VALVE D.4.5/6 L=7 THREAD D.0.3 STAINLESS STEEL |
| 46 | 4.005.0217 | GUIDE BODY D.12 COMP. VALVE '02 W/O WATER INLET REGULATION M20 |
| 48 | 5.609.0041 | EXTERNAL CHECK VALVE ASSEMBLY + O-RING |
| 49 | 4.007.0324 | EXTERNAL CHECK VALVE SPRING D.4.8-6 L=20 0.6 STAINLESS STEEL THREAD |
| 51 | 5.009.0560 | INJECTOR ASSEMBLY D.1.8 + O-RING |
| 52 | 3.200.0017 | OR SEAL 9.13x2.62 SH.70 REF. 109 |
| 53 | 3.200.0013 | GASKET OR 11.1 X 1.78 REF.114 |
| 54 | 3.201.0014 | OIL SEAL RING D.12x20X5/7 |
| 55 | 3.002.0094 | TCEI SCREW M6X30 ZNT TRILOBAL |
| 56 | 5.009.0101 | INTAKE/DELIVERY VALVE CAP WITH O-RING MOUNTED |
| 57 | 5.009.0005 | LAVOR DELIVERY SUCTION VALVE 1 |
| 58 | 3.200.0019 | OR SEAL 12.42x1.78 SH.90 |
| 59 | 4.006.0109 | 1/8 GAS TAPERED CAP L=6.5 |
| 62 | 3.200.0018 | GASKET OR 9.92X2.62 SHORE90 |
| 64 | 4.008.0657 | PARTNER OIL SEAL SPACER D.12 |
| 65 | 4.006.0247 | PARTNER SEAL SUPPORT RING D.12 HIGH |
| 66 | 4.008.0695 | ANTI-EXTRUSION RING 12X18X1 FOR PARTNER D.12 |
| 67 | 3.201.0020 | WATER SEAL RING D.12X18X5 NBR SH.90 (SP2898N) |
| 68 | 5.009.0015 | COMPLETE SUCTION VALVE TOP |
| 69 | 4.005.0187 | PARTNER '01 HEAD FOR PISTONS D.12 FINISHED |
| 70 | 3.002.0130 | TCEI SCREW M6X70 CL.12.9 UNI5931 DACROMET |
| 71 | 4.008.0031 | WATER INTAKE FILTER ORDER D.16 TAPERED |
| 72 | 4.008.0376 | ENGINE ELECTRIC BOX COVER (D.50 CONDENSER) |
| 74 | 4.008.0356 | PARTNER '96 ELECTRIC BOX FOR INTERNAL UNIT WITH FRAME |
| 82 | 5.006.0165 | ENGINE '02 D110H100 230/50 2P THERMAL WIRES FOR FKX |
| 83 | 5.007.0181 | GUN GUIDE BODY D.12 + INJECTOR 1.7 W/O REG. TS INLET M20 X 110h100 |
| 84 | 5.008.0160 | PARTNER HEAD D.12 W/O REG. |
| 87 | 3.406.0011 | RING NUT FOR PG.11 TEAR-RESISTANT |
| IDRO FKX 1123 230V 50Hz TS BASE DA FINIRE Pag.3 | ||
| 1 | 4.007.0183 | Nozzle holder pin nut for Jet Fire '98 |
| 2 | 3.100.0075 | M 1/8" tapered female diameter 4" curved connector, code E2L39C02 |
| 3 | 4.012.0102 | Brush motor cable length 850 mm, 0.75 mm cross-section, IEC227-3/1979, without fasteners |
| 4 | 4.608.0145 | Parana' Rilsan diesel delivery pipe length 540 mm |
| 5 | 4.005.0194 | COVER X FKX BOILER (DIE CAST) ESP.05 |
| 6 | 4.007.0303 | Diameter 40 mm pipe length 325 mm, pre-galvanized steel 37 |
| 7 | 4.008.0447 | FKX electrical box cover - black |
| 8 | 5.009.0213 | External switch assembly 0/1 beep, 12(10)A + transparent cover |
| 9 | 3.002.0106 | Self-tapping screw TC-TC 3.9X16 UNI 6954 ZNT |
| 10 | 3.404.0017 | CAPACITATOR 25mF 450V D.39X94 F/M |
| 11 | 3.004.0002 | FLAT WASHER 4.3X9 Th. 0.8 ZNT UNI6592 |
| 12 | 3.405.0011 | TERMINAL BLOCK PA 32/6 |
| 13 | 4.008.0127 | MULTIPLE CABLE GLAND FOR FIRE ELECTRIC BOX |
| 14 | 4.008.0446 | ELECTRICAL BOX BASE FKX |
| 15 | 3.403.0012 | ELECTRIC BOARD 230/50 FKX |
| 16 | 3.002.0132 | SELF-TAPPING SCREW TC-TC 3.5X9.5 UNI 6954 ZNT |
| 17 | 3.002.0080 | SCREW T.C. M4x12 Trilobal Cross Cut Zinc Plated |
| 18 | 3.004.0003 | Spring Washer, External Toothing, Diameter 4x8, Thickness 0.5, DIN6798A, Zinc Plated |
| 19 | 4.008.0470 | Fan Motor Cover, FKX |
| 20 | 4.007.0180 | TIE ROD FOR FIRE '98 BOILER, M6x352, Zinc Plated |
| 21 | 3.004.0010 | Spring Washer, External Toothing D.6X11 Th. 0.7 DIN6798A ZNT |
| 22 | 3.003.0011 | M6 MEDIUM NUT UNI 5588 CL8 ZNT |
| 23 | 3.304.0056 | 230/50 BURNER MOTOR COMPLETE WITH FAN, FLANGE, CABLES, COVER (FKX) |
| 24 | 4.008.0658 | THERMAL RESISTANT BOTTOM IN FELT |
| 25 | 4.008.0450 | THERMORESISTENT BOTTOM HARD FKX ESP.00 |
| 26 | 4.007.0158 | BOILER BOTTOM FOR NUOVA FIRE |
| 27 | 4.007.0200 | WASHER 20.2X26X3 Fe37 |
| 28 | 6.005.0319 | COIL CONNECTOR WITH HOSE CONNECTOR |
| 29 | 5.609.0260 | SAFETY VALVE G1/8 M D.6 200BAR MTM (00036020) |
| 30 | 4.005.0186 | FKX BOILER BASE (DIE-CAST) |
| 31 | 4.007.0185 | SPACER FOR FIXING CLAMP FOR JET FIRE PUMP '98 |
| 32 | 3.004.0026 | WASHER FLAT D.4.3X12 ZNT UNI6593 |
| 33 | 3.002.0179 | SELF-TAP SCREW TC-TC 3.9X50 ZNT |
| 34 | 6.005.0157 | EXTERNAL IGNITION TRANSFORMER 230-240/50-60 COFI ELECTRONIC |
| 35 | 5.611.0097 | HIGH VOLTAGE CABLE L=280 WITH PROTECTION FOR COFI ELECTRONIC TRANSFORMER |
| 36 | 4.008.0459 | RUBBER CAP FOR FKX TRANSFORMER (SILICONE) |
| 37 | 4.006.0187 | NOZZLE HOLDER PIN FOR FKX BOILER |
| 38 | 3.104.0008 | DIESEL NOZZLE 0.60 60 H MONEL FILTER (HAGO) |
| 39 | 6.005.0307 | FKX DEFLECTOR WITHOUT ELECTRODES |
| 40 | 5.013.0027 | NOZZLE HOLDER DISC FOR FKX |
| 41 | 4.604.0037 | COIL D.202 L=15m FOR NUOVA FIRE |
| 42 | 5.013.0026 | BOILER BODY WITH BRACKET FOR FIRE '98, PAINTED |
| 43 | 5.009.0304 | VALVE ADJUSTMENT PRESSURE REGULATION X PUMP ULKA (Spring L=20) |
| 44 | 4.008.0465 | EXTERNAL BLACK PVC FUEL-PROOF PIPE D.9X6 L=280 |
| 45 | 3.002.0146 | TCEI SCREW 4X35 TRILOBAL ZNT |
| 46 | 3.099.0110 | CLAMP D.12 CLAMP PAS 012 FOR GAS PUMP FASTENING. (SCREWLESS) |
| 47 | 3.551.0014 | DIESEL PUMP ULKA EP 5 48W 230/50 C / OR R4 |
| 48 | 5.611.0043 | EXTERNAL FKX/RIO DIESEL FILTER UNIT (nylon filter) |
| 49 | 3.411.0001 | ELECTROGLASS TUBE DIAMETER 4 (VSM 040) |
| 50 | 4.608.0038 | RUBBER PROTECTION FOR FIRE THERMAL UNIT |
| 51 | 3.403.0003 | THERMAL PROTECTION L01.080.05. UL CABLES L=1200 |
| 52 | 4.606.0002 | FLOW CONNECTOR WITH HOLE FOR THERMOSTAT |
| 53 | 4.007.0184 | PIPE FOR DELIVERY SLEEVE PARANA' L=40 |
| 54 | 4.008.0449 | SOFT HEAT-RESISTANT SLEEVE 31X56 THK 3 FKX |
| 55 | 6.005.0656 | MOTOP. PT'02 110x100 230/50 D.12 9'16 TS IN.1.7 (FKX) |
| 56 | 4.006.0181 | WATER INLET SPACER FKX / PARANA' |
| 58 | 4.008.2631 | HEAT-RESISTANT CERAMIC FIBER BAND 120X635 THICKNESS 4 |
| 59 | 3.099.0124 | CIRCLIP FOR SHAFT D.42 UNI 7435 |
| 60 | 4.007.0256 | SHAPED SUPPORT FOOT FKX |
| 61 | 4.008.0748 | BOILER COVER FOR FKX REGULATION |
| 62 | 4.008.0749 | AIR REGULATION BUTTERFLY FOR FKX |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s LAVOR websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to LAVOR brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Lavor FKX1123 - 8.052.0602
6 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10/15 BUSINESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N LAVOR:
- LAVOR S/N START WITH (8. ) and have 8 DIGITS
