Makita Spare Parts for Angle Grinder GA4540
€17.62
Tax included
Makita Spare Parts for Angle Grinder GA4540
Makita Genuine spare parts or replacement parts for to repair Angle Grinder GA4540.- New transmission system elastic II Super Joint System (SJS)
- Gear box new design and impact resistant
- Start slow and constant speed under load
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Angle Grinder GA4540
Makita Genuine spare parts or replacement parts for to repair Angle Grinder GA4540.
In the following table, look for the model of the Angle Grinder and the respective parts of the code.
| Angle Grinder GA4540 | ||
| # | Part Num. | Description |
| 1 | 168705-9 | GEAR CASE GA |
| 2 | 252186-8 | NUT M6 X 9554NB |
| 3 | 253077-6 | ROND.P. 6 4300 / 01BV |
| 4 | 227591-8 | GEAR FOR 10 GA |
| 5 | 211142-7 | BEARING 6001LLB X GD0800C |
| 6 | 318835-8 | COVER GEAR BOX |
| 10 | 253084-9 | FLAT WASHER 12 8419B/5016NB |
| 11 | 240134-9 | FAN 60 GA |
| 12 | 515364-4 | ARMATURE ASSY |
| 13 | 681656-4 | INSULATION GD0810C |
| 14 | 253823-7 | FLAT WASHER 7 X JS1600 |
| 15 | 210027-4 | BALL BEARING 627DDW X 9561CV |
| 16 | 421738-8 | LABYRINTH RUBBER RING 22 X 9561CV |
| 22 | 453367-9 | BAFFLE PLATE |
| 23 | 266258-3 | SCREW 4 X 70 X 9564 |
| 24 | 344871-8 | RETAINER GD0800C |
| 25 | 626649-4 | FIELD GA SERIES |
| 27 | 194074-2 | CARBON BRUSHE SET CB-325 X 9554NB |
| 28 | 266007-8 | SCREW M3 X10 HP2030 |
| 29 | 643769-9 | CARBON BRUSHE HOLDER |
| 30 | 453366-1 | MOTOR HOUSING |
| 31 | 266326-2 | SCREW 4x18 X MT601 |
| 32 | 687169-3 | STRAIN RELIEF HP1620 |
| 33 | 638949-0 | SWITCH BLOCK |
| 35 | 682559-5 | SAVE CABLE X 6822 |
| 36 | 266326-2 | SCREW 4x18 X MT601 |
| 38 | 453364-5 | BACK COVER FOR GA |
| 40 | 651418-4 | SWITCH ST115A-40 X 9541 |
| 42 | 233071-4 | COMPRESSION SPRING 4 X 9541 |
| 43 | 453847-5 | SWITCH LEVER |
| 44 | 453368-7 | SWITCH KEY |
| 46 | 453369-5 | BUTTON |
| 47 | 234057-1 | COMPRRESSION SPRING 6 GA5021C |
| 48 | 266361-0 | SCREW 4 X 30 X 9554NB |
| 49 | 213032-0 | RING 4 X GA4530 |
| 50 | 256535-1 | PLUG FOR 6 GA |
| 51 | 263002-9 | RUBBER PLUG 4 |
| 52 | 210026-6 | BALL BEARING 696ZZ |
| 53 | 961005-4 | RETAINING RING S9 |
| 54 | 253180-3 | FLAT WASHER 10 X 6221DW |
| 55 | 310508-9 | JOINT SLEEVE GA |
| 56 | 346556-2 | C PLATE FOR GA |
| 57 | 227592-6 | SPIRAL BEVEL GEAR FOR 38 GA |
| 58 | 313228-4 | COUPLING GA |
| 59 | 210302-8 | BALL BEARING 6903ZZ FOR GA |
| 60 | 253744-3 | FLAT WASHER 12 24B / 12N / 14 |
| 61 | 263002-9 | RUBBER PLUG 4 |
| 62 | 213641-5 | RING 51 GA |
| 63 | 318837-4 | BEARING BOX |
| 64 | 265490-6 | SCREW M4 X 16 X 9561CV |
| 65 | 211129-9 | BALL BEARING NSK 6201DD |
| 66 | 267279-8 | FLAT WASHER 21 X HR2450FT |
| 67 | 443124-3 | FELT RING 17 GD0600 |
| 68 | 285854-8 | BEARING RETAINER 20-33 |
| 70 | 326130-2 | SPINDLE GA |
| 72 | 123144-0 | DISC GUARD GA SERIES |
| 73 | 224415-9 | RECIEVE WASHER 42 GA95010 |
| 74 | 224554-5 | CLAMP WASHER 14-45 X 9541 |
| 500 | 666855-9 | POWER CORD |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
