Makita Spare Parts for Wall Chaser SG180/2
€3.08
Tax included
Makita Spare Parts for Wall Chaser SG180/2
Makita genuine spare parts or replacement parts for to repair Wall Chaser 1800W 180 mm Makita SG180/2.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Wall Chaser SG180/2
Makita genuine spare parts or replacement parts for to repair Wall Chaser 1800W 180 mm Makita SG180/2.In the following table, look for the model of Groover and the respective parts of the code.
| Wall Chaser Makita SG180/2 | ||
| # | Part Num. | Description |
| 1 | B19471 | SCREWM5 X 50 X SG180 |
| 2 | B50815 | GEARBOX BOX SG150 |
| 3 | B51003 | RING 35X2.5 X SG180 |
| 4 | B06712 | MOTOR COVER X SG180 |
| 5 | B53488 | RING 31,42X2,62 X SG180 |
| 9 | B05116 | INSULATED WASHER X SG180 |
| 10 | B22681 | BALL BEARING 6000 2RS |
| 11 | B41418 | DEFLECTOR X SG150 |
| 12 | B33415 | SCREW M5 X 20 X SG150 |
| 13 | B30379 | PLATE 0.2 X SG150 |
| 13 | B30387 | PLATE 0.3 X SG150 |
| 13 | B30361 | PLATE 0.15 X SG150 |
| 14 | B27854 | SCREW M5 X 45 X SG180 |
| 15 | B58032 | ARMATURE X SG180 |
| 16 | B21600 | FAN X SG180 |
| 17 | B65011 | GEAR X SG180 |
| 18 | B06711 | ARMATURE SET X SG180 |
| 23 | B30148 | RING 46X2 X SG2150 |
| 24 | B64881 | SPINDLE X SG180 |
| 26 | B47100 | SCALE X SG180 |
| 27 | B11528 | BOLT M 8 X 25 X SG150 |
| 30 | B11122 | BOLT M 8 X 90 X SG150 |
| 31 | B11189 | WASHER 8.4 X SG150 |
| 32 | B10777 | ROLLER X SG150 |
| 33 | B11247 | TUBE X SG150 |
| 34 | B18952 | NUT M8 X SG150 |
| 35 | B10983 | BOLT M 8 X 16 X SG150 |
| 36 | B29934 | EXTERNAL FLANGE X SG150 |
| 37 | B30486 | RING 3 X SG150 |
| 38 | B55376 | RING 5 X SG180 |
| 39 | B10678 | RING 10 X SG150 |
| 40 | B55384 | RING 21 X SG180 |
| 41 | B06343 | COVER DISC X SG180 |
| 42 | B44669 | SUCTION JOIN X SG180 |
| 43 | B08482 | SIDE HANDLE X SG150 |
| 44 | B21071 | WASHER M8 X SG150 |
| 45 | B36137 | SCREW M4 X 80 X SG150 |
| 46 | B45856 | FIELDS X SG180 |
| 47 | B58701 | MOTOR HOUSING X SG180 |
| 48 | B45872 | CARBON BRUSH X SG150 (single) |
| 49 | B52894 | CARBON BRUSHE HOLDER X SG150 |
| 50 | B38299 | CARBON BRUSHE HOLDER COVER X SG180 |
| 51 | B21030 | SCREW M3.9 X 13 X SG150 |
| 52 | B31096 | TUBE X SG150 |
| 53 | B09506 | WASHER X SG150 |
| 55 | B26948 | WASHER 13 X SG150 |
| 56 | B30981 | BOLT M 7 X 12 X SG150 |
| 57 | B31070 | WASHER 7.4 X SG150 |
| 58 | B10801 | SUPPORT X SG150 |
| 59 | B48611 | COMPLETE HANDLE X SG150 |
| 60 | B35055 | CONTROLLER X SG150 |
| 61 | B42721 | SCREW M3.9 X 19 X SG150 |
| 62 | B44941 | SCREW M4,8 X 38 X SG150 |
| 63 | B20990 | ScCREW M3.9 X 16 X SG150 |
| 64 | B17913 | TERMINAL X 2702 |
| 65 | B31468 | SWITCH X SG150 |
| 67 | B25221 | CABLE ARMOR X SG150 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
