Makita Spare Parts for Concrete Planer PC5001C

We have the Makita original Spares for Concrete Planer PC5001C, the diagram, parts list and tool repair that help you need to get your tools running like new again.

Fix Your Concrete Planer PC5001C. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

ITEM CODE: 266459-3

266459-3
417771-6
234057-1
318158-4
424051-3
264010-3
227520-1
211088-7
267352-4
962107-9
240094-5
518685-3
681660-3
267281-1
210044-4
421720-7
266325-4
419961-7
528819-0
140019-8
194547-5
643750-0
866331-5
188630-8
266326-2
631799-2
418518-1
651922-3
654575-7
687124-5
682574-9
233117-6
418519-9
158402-5
450184-8
213977-2
256505-0
263002-9
210033-9
233950-6
227521-9
257171-6
911003-8
285728-3
210241-2
253853-8
213624-5
345464-4
325625-2
141021-4
911256-9
911024-0
240114-5
346045-7
911115-7
922312-0
424526-2
424525-4
743341-8
743340-0
224554-5
273529-1
922441-9
450190-3
152179-4
321436-3
922311-2
253011-6
346042-3
346043-1
346044-9
265844-7
341840-0
253828-7
122853-8
410047-0
783203-8
140073-2
B-12289

Quantity

Usually Ships in: 7/10 Business Days Approx.

Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Description
Product Details
Attachments

Makita Spare Parts for Concrete Planer PC5001C

Fix Your Concrete Planer PC5001C. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following table, look for the model of Concrete Planer and the respective parts of the code.

PC5001C - CONCRETE PLANER D.125mm + BASE Pag.1
#	Part Num.	Description
1	266459-3	TAPPING SCREW 5X25, 5477NB PC5000C
2	417771-6	PIN CAP, 9557NB 9554NB
3	234057-1	COMPRESSION SPRING 6 GA5021C
4	318158-4	GEAR HOUSING GA 5010
5	424051-3	RUBBER RING 26 GA5021C
6	264010-3	HEX NUT M7 X GA5010
7	227520-1	SPIRAL BEVEL GEAR 11, GA6010Z GA6020
8	211088-7	BALL BEARING 6000 9527PB-9528PB
9	267352-4	FLAT WASHER 22 GA5010
10	962107-9	RET. RING (INT) R-30, GA5020 - GA5010
11	240094-5	FAN 70 GA5010
12	518685-3	ARMATURE ASS'Y 240V
13	681660-3	INSULATION WASHER X PV7000C
14	267281-1	FLAT WASHER 8 X GA9010C
15	210044-4	BALL BEARING 608DDW
16	421720-7	RUBBER RING 5604R
17	266325-4	TAPPING SCREW M 4 X 70 X MT952
18	419961-7	BAFFLE PLATE GA5010
19	528819-0	FIELD ASS'Y, PC5000C - GA5021C
20	140019-8	MOTOR HOUSING CPL., PC5001C - PC5000C
21	194547-5	CARBON BRUSH SET, CB-253 251/250
22	643750-0	BRUSH HOLDER CAP
23	866331-5	NAME PLATE PC5001C
24	188630-8	HANDLE SET, PC5000C
25	266326-2	TAPPING SCREW PT 4X18, 5007MG MT601
26	631799-2	CONTROLLER, PC5000C - GA5021C
27	418518-1	SLEEVE, JR3070CT - GA9010C
28	651922-3	SWITCH TG71B HR4041C
29	654575-7	TERMINAL BLOCK, PC5000C - 5704R
30	266326-2	TAPPING SCREW PT 4X18, 5007MG - MT601
31	687124-5	STRAIN RELIEF, JV0600K - MT953
32	682574-9	CORD GUARD 10-90, PC5000C
34	233117-6	COMPRESSION SPRING, 6 AF502,SH01W - GA7010C
35	418519-9	SWITCH BASE, GA7011C - GA9010C
36	158402-5	SWITCH LEVER A PC5000C - GA5021C
38	450184-8	LENZ, PC5000C
39	213977-2	O-RING 7 X GA5010
40	256505-0	SHOULDER PIN 5, GA5020 - GA5010
41	263002-9	RUBBER PIN 4
42	210033-9	BALL BEARING 696ZZ X 2107FK
43	233950-6	RING SPRING 11, GA4030 - GA5010
44	227521-9	SPIRAL BEVEL GEAR 35A, GA6010Z - PC5000C
45	257171-6	RING 12 X PC5000C
46	911003-8	P.H. SCREW M3X6, FD02W - 6096DW
47	285728-3	BEARING RETAINER 39 GA5010 - GA5020
48	210241-2	* BALL BEARING 6202DDW
49	253853-8	FLAT WASHER 15 X HR1800
50	213624-5	O-RING 48 X GA5010
51	345464-4	LABYRINTH RING, GA4030 - 9554NB
52	325625-2	SPINDLE A, PC5000C
53	141021-4	SKIRT B CPL., PC5000C
54	911256-9	P.H. SCREW M5X35, 6300LR
55	911024-0	PAN HEAD SCREW M3X14, LP1812C - PC5000C
56	240114-5	FAN 85 PC5000C0
57	346045-7	SEPARATOR PC5000C
58	911115-7	P.H. SCREW M4X10, PC5000C - HR4000C
59	922312-0	H.S.H. BOLT M6X12, 2414NB
60	424526-2	DUST COVER CAP PC5000C See Data Sheet T. CT148-1
61	424525-4	DUST COVER CAP PC5000C See the Technical Sheet T. CT148-1
62	743341-8	BRUSH B, PC5000C See the Technical Sheet T. CT148-1
63	743340-0	BRUSH A PC5000C See at the Technical Sheet T. CT148-1
64	224554-5	LOCK NUT 14-45, 9005B - 9541
65	273529-1	GRIP, PC5001C
66	922441-9	H.S.H. BOLT M8X25, LS1016L
67	450190-3	SPACER B PC5000C
68	450190-3	SPACER B PC5000C
69	152179-4	FRONT ROLLER X PC1100
70	321436-3	FRONT ROLLER SHAFT XPC1100
71	922311-2	H.S.H. BOLT M6X12, 5077B - PC5001C
72	253011-6	FLAT WASHER 6 LS1400
73	346042-3	ROLLER HOLDER L, PC5001C
74	922311-2	H.S.H. BOLT M6X12, 5077B - PC5001C
75	922311-2	H.S.H. BOLT M6X12, 5077B - PC5001C
76	346043-1	ROLLER HOLDER R, PC5001C
77	346044-9	BASE HOLDER CPL., PC5001C
78	265844-7	H.S.H.BOLT M6X20, AN923
79	922311-2	H.S.H. BOLT M6X12, 5077B - PC5001C
80	341840-0	BASE X PC1100
81	253828-7	FLAT WASHER 10, 2012NB - GA5020C-6021C
Accessories Pag.2
500	122853-8	DUST BAG ASS'Y, PC5000C
501	410047-0	WRENCH HOLDER, GV5000
502	782425-7	LOCK NUT WRENCH 28, PC5000C
503	783203-8	HEX WRENCH 5, 4131
504	140073-2	STEEL TOOL CASE, PC5000C
505	194921-7	DUST COVER BRUSH SET, PC5000C
506	A-94998	DIAMOND WHEEL, PC5001C
507	B-12289	OFFSET DIAMOND WHEEL 125, PC5001C
