Lavor Original Parts for Pressure Cleaner RIO 1108 - 8.052.0801
€75.47
Tax included
Lavor Original Parts for Pressure Cleaner RIO 1108 - 8.052.0801
Lavor original spare parts for to replace broken parts for to fix Cold Water High Pressure Cleaner RIO 1108 220-230/50 TS -G- -LAVOR - 8.052.0801.Fix Your Pressure Cleaner EAGLE 24. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Lavor Original Parts for Pressure Cleaner RIO 1108 - 8.052.0801
Lavor original spare parts for to replace broken parts for to fix Cold Water High Pressure Cleaner RIO 1108 220-230/50 TS -G- -LAVOR - 8.052.0801.
In the following tables, look for the spare part and its respective code.
| 80520801 - IDRO RIO 1108 220-230/50 TS -G- -LAVOR- Pag.1 | ||
| # | Part Num. | Description |
| 0 | 8052X801 | IDRO RIO 1108 230V 50Hz TS (SILVER) BASE DA FINIRE |
| 001 | 4.013.0305 | YELLOW UPPER COVER FKX (PANT.108C) |
| 002 | 4.008.0867 | HANDLE |
| 004 | 4.008.0869 | LANCE HOLDER |
| 005 | 4.008.0789 | HOSE REEL TIGER |
| 006 | 4.008.0868 | DETERGENT TANK |
| 007 | 4.608.0180 | DIESEL TANK CAP |
| 008 | 5.009.0611 | INLET JOINT WITH GASKET |
| 009 | 7.100.1726 | INSTRUCTION MANUAL FKX-XTR-FUEGO LAVOR |
| 010 | 3.700.0036 | GUN 29Mpa-140°C-21lt/min G3/8M- M22 |
| 011 | 4.618.0049 | HOSE 1/4 R1 210BAR L=8000 3/8"F |
| 012 | 6.002.0260 | LANCE H/L PRESSURE 1.15-Y- |
| 013 | 3.100.0062 | QUICK COUPLING WITH VALVE (3029) |
| 018 | 5.012.0222 | FAST COUPLING KIT + CAP + ACCESSORY HOLDER |
| 8052X801 - IDRO RIO 1108 230V 50Hz TS (SILVER) BASE DA FINIRE - Pag.2 | ||
| 0 | 50010824 | MOTOP.PT'03 110h100ALL 230-240/50 D.12 9GR35 TS IN.1,7 (FKX) -40050260- |
| 0 | 50090304 | ASSIEME VALVOLA REGOLAZIONE PRESSIONE X POMPA ULKA (MOLLA L=20) |
| 002 | 3.100.0075 | CONIC CONNECTION M 1/8 F D.4 CURVED FOR GASOIL HOSE VITON O- |
| 003 | 4.012.0102 | CABLE L=600 SEC.0,75 IEC227-3/1979 |
| 004 | 4.608.0145 | RILSAN GASOIL HOSE X PARANA' L=500 |
| 005 | 4.005.0194 | BOILER COVER FKX |
| 006 | 4.007.0303 | TUBE D.40 L=325 FE 37 PREZINCED |
| 007 | 4.008.1169 | GREY CAP FOR ELECTRIC BOX FKX |
| 008 | 3.401.0178 | SWITCH 0/1 BLACK BOTTON IP55 12/10 |
| 010 | 3.404.0094 | CAPACITOR 32mF 450V |
| 012 | 3.405.0011 | TERMINAL BOARD PA 32/6 |
| 014 | 4.008.0446 | ELECTRICAL BOX BASE |
| 015 | 3.403.0012 | ELECTRICAL BOARD |
| 020 | 4.007.0180 | BOILER STAY M6X352 |
| 023 | 3.304.0056 | Burner MOTOR.230/50 W/FAN,FLANGE,CABLE L=850,NOISE SUPPRRESSOR,COVER |
| 024 | 4.008.0658 | THERMORESISTANT FELT BOTTOM PLATE X FKX/PARANA' |
| 025 | 4.008.0450 | THERMORESISTANT PAD |
| 026 | 4.007.0158 | BOILER PAD |
| 027 | 4.007.0311 | WASHER 16,6x26 |
| 028 | 4.007.0307 | JUNCTION |
| 029 | 5.609.0260 | MAX PRESSURE VALVE 250BAR 1/8 |
| 030 | 4.005.0186 | BOILER BASE PLATE X FKX (LIKEDIE CASTING ) |
| 031 | 4.007.0185 | SPACER FOR FIXING CLAMP |
| 034 | 5.009.1126 | TRASF.ACC.230-240/50-60 C/PIPET.FKX-RIO (EMC) +CAVO C/TERRA ESTERNA+ |
| 035 | 4.008.0848 | GASKET NEW TRANSFORMER FKX |
| 037 | 4.006.0187 | NOZZLE HOLDER PIN |
| 038 | 3.104.0008 | DIESEL NOZZLE 0.60 60/A MONEL FILTER |
| 039 | 3.099.0296 | COMPLETE ELECTRODE DEFLECTORDID.2 FKX |
| 040 | 5.013.0027 | DISK HEAD HOLDER |
| 041 | 4.604.0011 | COIL D.202 |
| 042 | 5.013.0050 | BODY BOILER |
| 043 | 5.009.0304 | ADJUSTING VALVE SET (SPRING L=20) |
| 044 | 4.008.0465 | PVC PIPE |
| 046 | 3.099.0110 | D.12 CLAMP |
| 047 | 3.551.0014 | GASOIL PUMP |
| 048 | 5.011.0043 | GASOIL FILTER GROUP |
| 049 | 3.411.0001 | ELECTROLYTIC PIPE D.4 |
| 050 | 4.608.0038 | RUBBER PROTECTION FOR THERMIC |
| 051 | 3.403.0003 | THERMAL PROTECTOR L01.090.05.700 |
| 052 | 4.606.0002 | DELIVERY CONNECTION |
| 053 | 4.007.0322 | TUBE FKX L=42 |
| 054 | 4.008.0449 | THERMORESISTANT COUPLING BOW 17X23XL40 |
| 055 | 5.001.0824 | MOTORPUMP.PT'03 110h100AL 230-240/50 D.12 9°35 TS W/SUCTION |
| 057 | 4.614.0003 | ELECTRODE D.2 FKX PARANA' |
| 058 | 4.008.0503 | BAND IN CERAMIC FIBER |
| 059 | 3.099.0124 | RING LOCKER X SHAFT D.42 UNI 7435 |
| 060 | 4.007.0256 | BASE FKX |
| 061 | 5.009.0637 | BOILER CAP KIT |
| 062 | 4.012.0392 | CAVO H05VV-F 3X1,5 MT.7,5 SP.SCHUKO ANTISPRUZZO F/F |
| 063 | 4.008.0916 | GASOIL TANK |
| 063 | 6.005.0148 | KIT 135 BLACK TANK FKX WITH CAP |
| 064 | 6.005.0190 | WHEEL KIT |
| 065 | 4.008.0922 | COVER FOR MOTOR FAN (MOTOR'96) |
| 50090304 - ASSIEME VALVOLA REGOLAZIONE PRESSIONE X POMPA ULKA (MOLLA L=20) - Pag.3 | ||
| 001 | 4.006.0259 | PORTAGOMMA A VITE X REGOLAZ. GASOLIO FKX |
| 002 | 4.006.0260 | DADO 10x1 ES.13 PER REGOLAZ. GASOLIO FKX |
| 003 | 4.007.0306 | SPRING FOR PRESS.REG.VALVE FKXD.5,4-7,8 L=20 WIRE 1,8 |
| 004 | 3.200.0050 | O-RING 5.28X1.78 |
| 005 | 4.008.0856 | VALVOLA SFERICA PER REGOLAZION E BY-PASS FKX-PARANA' |
| 006 | 4.006.0254 | BY-PASS DIESEL VALVE |
| 007 | 3.200.0021 | OR GASKET 6,75x1,78 RIF.106 |
| 008 | 3.100.0057 | CONNECTION D.4X1/8"M VITON O-RING |
| 50010824 - MOTOP.PT'03 110h100ALL 230-240/50 D.12 9GR35 TS IN.1,7 (FKX) -40050260- Pag.4 | ||
| 0 | 50090703C | GRUPPO CORPO GUIDA C/TS-ASP.-M.13KG (40050260) +TESTATA (PT'03) |
| 001 | 6.005.0387 | KIT 353 LW FAN + RING |
| 002 | 5.002.0151 | HOUSING '02 D110 H100AL 230-240/50 2P (FKX) |
| 003 | 6.005.0087 | THRUST RING KIT (PT'03 INDUCTION/U88) |
| 003 | 3.001.0033 | BALL BEARING 6003 2RS (17x35x10) |
| 004 | 5.005.0071 | ROTOR FOR 110H100AL |
| 005 | 4.005.0219 | FRONT FLANGE D.110 PT'03 |
| 006 | 3.201.0008 | OIL SEALING RING D. 17X35X7 |
| 007 | 3.001.0030 | BALL BEARING |
| 008 | 4.005.0218 | WOBBLE PLATE 9'35 PT'03 |
| 009 | 6.005.0087 | THRUST RING KIT (PT'03 INDUCTION/U88) |
| 010 | 5.009.0703C | BODY GUIDE+HEAD ASSEMBLED TS WITH SUCTION (SPRING 13KG) -PT |
| 50090703C - GRUPPO CORPO GUIDA C/TS-ASP.-M.13KG (40050260) +TESTATA (PT'03) - Pag.5 | ||
| 0 | 50070187C | CORPO GUIDA PT'03 PIST.D.12 C/ TS-ASP.-VALV.COMP.-M.13KG |
| 0 | 50080182C | TESTATA PT'03 D.12 -C- |
| 001 | 5.007.0187C | PISTON BODY GUIDE PT'03 WITH TS/COMP.VALVE/SPRING 13KG/SUCTI |
| 002 | 6.005.0282 | KIT 257 O-RING SEAL |
| 003 | 5.008.0182C | PUMP HEAD PARTNER '03 D.12 |
| 50070187C - CORPO GUIDA PT'03 PIST.D.12 C/ TS-ASP.-VALV.COMP.-M.13KG - Pag.6 | ||
| 001 | 5.009.0716 | COMPLETED VALVE TS PT'03 CABLEL=530 SPRING 13KG (WHITE FAST |
| 002 | 6.005.0277 | KIT 252 |
| 003 | 6.005.0226 | KIT 209 O-RING |
| 004 | 6.005.0079 | KIT 79 LW OIL SEALS |
| 005 | 4.005.0263C | PISTON BODY GUIDE PT'03 WITH SUCTION VALVE |
| 005 | 4.008.1176 | GASKET PISTON BODY GUIDE-HEADPT'03 29.7X12.9X2.7 |
| 006 | 6.005.0181 | KIT 167 LW PISTON |
| 50080182C - TESTATA PT'03 D.12 -C- Pag.7 | ||
| 001 | 6.005.0184 | KIT 170 LW HEAD VALVE KIT |
| 002 | 4.005.0210C | '03 PARTNER HEAD |
| 003 | 6.005.0133 | KIT 124 O-RING WATER SEAL PARTNER D.12 |
