Rurmec RH 3200 Rotary Hammer Spare Parts
€1.22
Tax included
Rurmec RH 3200 Rotary Hammer Spare Parts
We are RURMEC original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you to purchase the most suitable spare part to quickly solve any maintenance or repair issues for Rotary Hammer RT 24.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Rurmec RH 3200 Rotary Hammer Spare Parts
We are RURMEC original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you to purchase the most suitable spare part to quickly solve any maintenance or repair issues for Rotary Hammer RH 3200 - 354.001.In the following table, look for the model of the Rotary Hammer and the respective parts of the code.
| Rurmec ROTARY HAMMER RH 3200 - 354.001 Spare Parts | ||
| # | Part Num. | Description |
| 1 | 354.101 | FRONT CAP |
| 2 | 354.102 | RING SPRING 19X2MM |
| 3 | 354.103 | CHUCK COVER |
| 4 | 354.104 | STOPPER 21X32X6 |
| 5 | 354.105 | GUIDE WASHER |
| 6 | 354.106 | COMPRESSION SPRING 1.5 |
| 7 | 354.107 | SCREW M5X25 |
| 8 | 354.108 | SIDE HANDLE |
| 9 | 354.109 | SCREW M8X110 |
| 10 | 354.110 | HANDLE HOLDER |
| 11 | 354.111 | BARREL |
| 12 | 354.112 | WASHER 31,1X41,3X1,5 |
| 13 | 354.113 | DAMPER |
| 14 | 354.179 | NEEDLE BEARING HK0810 |
| 15 | 354.115 | SPRING 1.8 |
| 16 | 354.116 | SLEEVE |
| 17 | 354.117 | 0-RING 44X1,6 |
| 18 | 354.118 | O-RING 49X1.5 |
| 19 | 354.119 | SCREW M4X16 |
| 20 | 354.120 | CRANK HOUSING COVER |
| 21 | 354.121 | STEEL BALL C 7.14 |
| 22 | 354.122 | TOOL HOLDER ASSEMBLED |
| 23 | 354.123 | OIL SEAL |
| 24 | 354.124 | RETAINING RING 28.4X30.3X1.5 |
| 25 | 354.125 | SLEEVE |
| 26 | 354.126 | IMPACT BOLT |
| 27 | 354.127 | RING |
| 28 | 354.128 | CUSHION RING |
| 29 | 354.129 | COVER |
| 30 | 354.130 | O-RING 16X3.5 |
| 31 | 354.131 | O-RING 27.3X2 |
| 32 | 354.132 | WASHER 29,3X33,6X1 |
| 33 | 354.133 | SPRING 1.6 |
| 34 | 354.134 | LINK GEAR |
| 35 | 354.135 | O-RING 28X1.3 |
| 36 | 354.136 | PIN 6X22 |
| 37 | 354.137 | PISTON DH 3200 |
| 38 | 354.138 | O-RING 22,4X3,1 OF THE PISTON |
| 39 | 354.139 | CYLINDER |
| 40 | 354.140 | O-RING 24X1 |
| 41 | 354.141 | CONNECTING ROD |
| 42 | 354.142 | BEVEL GEAR |
| 43 | 354.143 | SCREW M5X20 |
| 44 | 354.144 | SELECTOR SPRING |
| 45 | 354.145 | SELECTOR SUPPORT |
| 46 | 354.146 | SELECTOR FIXING PLATE |
| 47 | 354.147 | SCREW M4X12 |
| 48 | 354.148 | SELECTOR O-RING 21,7X1,9 |
| 49 | 354.149 | SELECTOR KNOB |
| 50 | 354.150 | VENT PLATE |
| 51 | 354.151 | O-RING 18.5X1.5 |
| 52 | 354.152 | FELT |
| 53 | 354.153 | COVER |
| 54 | 354.154 | O-RING 33X1,9 |
| 55 | 354.155 | GEAR CASE |
| 56 | 354.156 | CRANCK SHAFT |
| 57 | 354.157 | BALL BEARING 6002 |
| 58 | 354.158 | O-RING 15 |
| 59 | 354.159 | CONICAL SPRING 1,2 |
| 60 | 354.160 | CLUTCH CAM |
| 61 | 354.161 | DRIVE GEAR Z-29 |
| 62 | 354.162 | WASHER 8,2X23X6,1 |
| 63 | 354.163 | O-RING 8 |
| 64 | 354.164 | WASHER 16,4X26,3 |
| 65 | 354.165 | WASHER 4X4X10 |
| 66 | 354.166 | BEVEL GEAR |
| 67 | 354.167 | BEARING COLLAR |
| 68 | 354.168 | BALL BEARING 6001 |
| 69 | 354.169 | CLUTCH ASSEMBLED |
| 70 | 354.170 | O-RING 10 |
| 71 | 354.171 | BALL BEARING 608 |
| 72 | 354.172 | OIL SEAL |
| 73 | 354.173 | GEARCASE COVER |
| 74 | 354.174 | O-RING 29X2 |
| 75 | 354.175 | OIL SEAL 12X22X4,5 |
| 76 | 354.176 | OIL SEAL |
| 77 | 354.177 | BALL BEARING 6000 |
| 78 | 354.178 | BEARING WASHER 10.1X20.7X0.5 |
| 79 | 354.179 | NEEDLE BEARING HK0810 |
| 80 | 354.180 | ARMATURE + FAN DH 3200 |
| 81 | 354.181 | ST SCREW 4,2X65 |
| 82 | 354.182 | BALL BEARING 627 |
| 83 | 354.183 | GASKET |
| 84 | 354.184 | BAFFLE |
| 85 | 354.185 | FIELD ASSY DH 3200 |
| 86 | 354.186 | HOUSING MOTOR |
| 87 | 354.187 | BRUSHE HOLDER |
| 88 | 354.188 | ST SCREW 3,2X8 |
| 89 | 354.189 | CARBON BRUSHE SET |
| 90 | 354.190 | BRUSH SPRING |
| 91 | 354.191 | REAR COVER |
| 92 | 354.192 | SCREW ST 4.2X16 |
| 93 | 354.193 | CHOKE COIL UNIT |
| 94 | 354.194 | LEAD UNIT 1 |
| 95 | 354.195 | LEAD UNIT 2 |
| 96 | 354.196 | SELECTOR SPRING 0.6 |
| 97 | 354.197 | CHANGE LEVER CPL. |
| 98 | 354.198 | OIL SEAL 25X35X7 |
| 99 | 354.199 | NEEDLE BEARING HK3012 |
| 100 | 354.200 | STEEL BALL C 5.5 |
| 101 | 354.201 | HANDLE |
| 102 | 354.202 | SCREW M5X35 |
| 103 | 354.203 | O-RING 41X1.4 |
| 105 | 354.205 | F/R CHANGE LEVER |
| 110 | 354.210 | SWITCH BUTTON |
| 111 | 354.211 | SWITCH HOLER CPL |
| 112 | 354.212 | SWITCH |
| 113 | 354.213 | HANDLE COVER |
| 115 | 354.215 | CORD DH 3200 |
| 116 | 354.216 | CORD GUARD |
| 118 | 354.218 | STRAIN RELIEF |
| 119 | 354.219 | BUSH |
| 120 | 354.220 | STRAIN RELIEF |
