DeWalt DC213 Type 1 Parts
€3.33
Tax included
DeWalt DC213 Type 1 Rotary Hammer Spare Parts
DEWALT, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for DC213 Cordless Rotary Hammer Type 1.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
DeWalt DC213 Type 1 Rotary Hammer Spare Parts
DEWALT, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for DC213 Cordless Rotary Hammer Type 1.Open PDF Drawing in this page to check spare parts you need.
| DeWalt DC213 Type 1 Rotary Hammer Drill Spare Parts | ||
| Pos. | Codice | Description |
| 101 | 323489-00 | CAP |
| 102 | 579212-00 | RING |
| 103 | N504215 | TUBE |
| 104 | 583890-00 | BALL 7MM |
| 105 | 578387-00 | SDS BALL PLATE (WASHER SDS 1.4MM) |
| 106 | 871690 | SPRING BEVEL |
| 107 | 590306-00 | FELT SEAL |
| 110 | 574937-00 | COVER |
| 111 | 490785-00 | SLEEVE |
| 112 | 575023-00 | SELECTOR |
| 113 | 324006-16 | SCREW |
| 114 | 478843-00 | SPRING |
| 115 | 575026-00 | CAP |
| 116 | 575024-00 | RELEASE BUTTON |
| 120 | N191970 | BATTERY COVER |
| 120 | N191969 | HOUSING REPAIR KIT |
| 121 | 330065-08 | SCREW M4x18 T20 |
| 122 | 578218-00 | SLIDER |
| 123 | 575030-00 | SPRING |
| 124 | 575032-00 | PIN MM7,34 |
| 125 | 479313-00 | SPRING |
| 126 | N191962 | HANDLE & COVER |
| 127 | 1005987-00 | CHANGE LEVER SA |
| 128 | 368832-09 | SWITCH ASSY |
| 129 | 1006234-00 | HANDLE COVER |
| 131 | 495610-00 | LEAD BROWN |
| 132 | 495610-01 | LEAD BLACK |
| 140 | 930026-01 | BUMPER |
| 160 | 493687-00 | HANDLE SIDE SA |
| 170 | 580787-00 | DEPTH STOP |
| 201 | 492807-00 | SPINDLE |
| 202 | 323711-02 | O-RING |
| 203 | 492808-00 | PIECE BEAT, DCH (SERVICE) |
| 204 | 492809-00 | GUIDE BUSH |
| 205 | N451068 | RETAINER |
| 206 | 327087-00 | WASHER |
| 207 | 323762-07 | RING |
| 210 | 590302-00 | BEARING NEEDLE |
| 211 | 488105-00 | CIRCLIP SW28 |
| 212 | 589350-00 | WASHER |
| 213 | 589346-00 | SPRING |
| 214 | 492817-00 | BUSH |
| 215 | N071966 | REPAIR KIT |
| 216 | 479478-00 | BEARING,BALL 6906 |
| 217 | 589348-00 | WASHER |
| 218 | 488390-00 | CIRCLIP SW26 1.5MM |
| 219 | 491536-00 | O-RING |
| 220 | 492820-00 | HOUSING PAIR |
| 221 | 478909-00 | SEAL - DISCONTINUED |
| 222 | N178363 | SERVICE KIT RAM (SERVICE) |
| 223 | 577168-00 | RING O DYNAMIC 13X3 |
| 224 | 492822-00 | HOLLOW PISTON, DCH (SERVICE) |
| 225 | N108992 | WASHER |
| 226 | 490286-00 | SPRING |
| 227 | 492823-00 | BALL SPINDLE |
| 228 | 492824-00 | CRANKSHAFT |
| 229 | N071966 | REPAIR KIT |
| 230 | N168103 | BEARING,BALL |
| 240 | N466046 | COMPRESSION SPRING |
| 241 | 492826-00 | COLLAR |
| 242 | 323763-10 | RING. SNAP 8 |
| 243 | N450704 | SA GEAR 3M WIDTH BEARING (SERVICE) |
| 244 | N621023 | BEARING |
| 246 | 575022-00 | PLATE, TRANSMISSION |
| 247 | 590312-00 | PIN |
| 250 | 492829-00 | MOTOR SA |
| 251 | 582865-00 | FELT FILTER |
| 252 | 323711-34 | O RING, 9 X 1.5 |
| 253 | 478898-00 | LEVER SA |
| 254 | 577802-00 | WASHER SHIM |
| 255 | 490129-00 | SCREW |
| 260 | 493511-00 | BRUSH PAIR ( X 2 ) |
| 800 | 870889-02 | RENOLIT PARAGON EP GREASE ½ - 90 GRAMS |
| 801 | 487130-04 | GLK FLUID GREASE 249 NLGI 000 (10G SERVICE) |
| 818 | 493152-00 | LABEL |
| 821 | N066648 | CARD |
| 836 | 596005-99 | SERVICE TOOLING KIT |
| 836 | 596006-99 | S.T.CIRCLIP REMOVER |
| 836 | 596007-99 | S.T.CIRCLIP INSERTER |
| 846 | N455852 | SERVICE KIT |
| 861 | 576657-00 | KITBOX |
| 866 | 1006628-00 | BATTERY 18V - 2.6AH DC213KB |
| 866 | 582627-00 | BATTERY 18V - 2.4AH DC213KA |
| 870 | N015878 | CHARGER 7.2V - 18V DC213KA |
| 870 | 1006634-00 | CHARGER 220V DC213KB |
