Makita Spare Parts for Angle Grinder GA9030S
Makita Original spare parts sourced directly from the manufacturer, with after-sales assistance at the best price on the web for to repair Angle Grinder GA9030S.
In the following table, look for the model of the Angle Grinder and the respective parts of the code.
| MAKITA GA9030S | ||
| # | Part Num | Description |
| 1 | 419133-4 | PIECE CAP FOR GA9020 |
| 2 | 233292-8 | COMPRESSION SPRING 12 |
| 3 | 266012-5 | SCREW M5 X 35 HR160DW |
| 4 | 419144-9 | RUBBER PROTECTION FOR GA9020 |
| 5 | 142754-4 | GEAR HOUSING FOR GA9020 |
| 6 | 252194-9 | NUT M8 FOR GA9020 |
| 7 | 227490-4 | GEAR 12 FOR GA9020 |
| 8 | 211132-0 | BALL BEARING 6301DD |
| 9 | 262085-6 | RUBBER RING 38 9079S |
| 10 | 267299-2 | WASHER 20 FOR GA9020 |
| 11 | 962211-4 | RETAINING RING R42 |
| 12 | 240081-4 | FAN 80 FOR GA9020 |
| 13 | 517828-4 | ARMATURE FOR GA9030 |
| 14 | 681630-2 | WASHER FOR 9029-9029SF |
| 15 | 210075-3 | 6200DDW BEARING FOR GA9020 |
| 16 | 419135-0 | DEFLECTOR FOR GA9020 |
| 17 | 526193-0 | STATOR FOR GA9030 |
| 18 | 266352-1 | 5X65 SCREW MT901 |
| 19 | 154786-9 | MOTOR CASING FOR GA9040S |
| 20 | 643710-2 | BRUSH HOLDER CAP XHM1500 |
| 21 | 194992-4 | CARBON BRUSHES CB-204 (201, 202) |
| 22 | 862126-4 | |
| 23 | 233375-4 | COMPRESSION SPRING 7 FOR GA9040S |
| 24 | 419260-7 | LOCKOUT BUTTON FOR GA9040S |
| 25 | 646788-4 | RESISTOR FOR GA9020S |
| 26 | 686036-9 | TERMINAL FOR GA9020 |
| 27 | 651178-8 | SWITCH 1362.0112 |
| 28 | 645088-9 | CAPACITIZER FOR GA9020 |
| 29 | 421936-4 | VIBRATION ABSORPTION INSERT |
| 30 | 188123-5 | REAR HANDLE For GA9040S |
| 31 | 266192-7 | 4 x 14 SCREW FOR HR4001C/HR4010C |
| 32 | 687169-3 | HP1620 CABLE CLAMP |
| 33 | 265999-8 | 4 x 25 SCREW |
| 34 | 665630-0 | |
| 35 | 682560-0 | CABLE SLEEVE FOR HM1202C/9079S |
| 36 | 188123-5 | REAR HANDLE For GA9040S |
| 37 | 213062-1 | RING 9 X BSR730 |
| 38 | 256491-5 | PIN 5 FOR GA9020 |
| 39 | 263002-9 | RUBBER PIN 4 |
| 40 | 211480-7 | BEARING 6000ZZ |
| 41 | 252429-8 | NUT M15-23 FOR GA9040S |
| 42 | 232163-6 | WASHER 20 X 9047F 9049F |
| 43 | 232163-6 | WASHER 20 X 9047F 9049F |
| 44 | 267798-4 | LOCK WASHER FOR GA9040S |
| 45 | 227492-0 | GEAR 53C FOR GA9040S |
| 46 | 265120-9 | SCREW M5X16 FOR GA9020 |
| 47 | 285724-1 | BEARING RETAINER 50 GA9020 |
| 48 | 267167-9 | WASHER 15 X 9047F 9049F |
| 49 | 211285-5 | BEARING 6203DDW FOR GA9020 |
| 50 | 213760-7 | SEAL 78 HR2010 |
| 51 | 318377-2 | BEARING BOX GA9020 |
| 52 | 265541-5 | SCREW M6X22 FOR GA9020 |
| 53 | 154777-0 | SHAFT FOR GA9040S |
| 54 | 265158-4 | M8X25 SCREW FOR GA9020 |
| 55 | 122891-0 | DISC COVER FOR GA9020 |
| 56 | 122444-5 | INTERNAL FLANGE 9079S |
| 57 | 224543-0 | FLANGE 9047F 9049F 9049SF |
| 58 | 261131-2 | NYLON WASHER 89 FOR GA9040S |
