Makita original spare parts for to replace broken parts or to fix Angle Grinder 9015B
Fix Your Angle Grinder 9015B. All Spares can be supplied at exceptional prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of the Angle Grinder and the respective parts of the code.![]()
| Angle Grinder 9015B | ||
| 1 | 416449-8 | LOCK BUTTON X 9015B |
| 2 | 233089-5 | COMPRESSION SPRING 12 |
| 3 | 266173-1 | SCREW PT 5X30 |
| 4 | 153374-9 | GEAR CASING CPL X9015B |
| 5 | 961003-8 | RING S7 |
| 7 | 211131-2 | BALL BEARING 6001DD |
| 8 | 317323-2 | COVER GEAR CASE X9015B-9016B |
| 9 | 240010-7 | FAN X 9015B |
| 10 | 516334-6 | ARMATURE 9015B |
| 11 | 681644-1 | INSULATING WASHER X 9227CB |
| 12 | 210005-4 | BALL BEARING 608 DDW |
| 13 | 416448-0 | CONVOYER 9015B |
| 14 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 15 | 182990-0 | HANDLE CPL X 9015B |
| 16 | 522838-8 | STATOR 9015B |
| 17 | 266029-8 | SCREW M5X65 |
| 18 | 183159-9 | MOTOR CASING X 9015B |
| 19 | 265096-0 | SCREW M 5 X 16 |
| 21 | 643750-0 | BRUSH CAP |
| 22 | 191963-2 | CARBON BRUSH CB-303 |
| 24 | 650102-8 | SWITCH TG08-1200-011 |
| 25 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 26 | 687124-5 | CABLE CLAMP MT953 |
| 28 | 682540-6 | CORD GUARD JN1601 |
| 30 | 224554-5 | EXTERNAL FLANGE 14-45 X 9541 |
| 31 | 224490-5 | INTERNAL FLANGE 42 |
| 32 | 165055-3 | HEADSET MOLA X 9542 |
| 33 | 251391-4 | SCREW M5X16 |
| 34 | 152572-2 | COMPLETE SHAFT X 9015B |
| 35 | 316991-8 | BEARING X 9015B |
| 36 | 211129-9 | BALL BEARING 6201DD NSK |
| 37 | 962151-6 | R32 RETURN RING |
| 39 | 152492-0 | HANDLE 35 X 9029-9029SF. |
| 40 | 256446-0 | PIN 6 X 9015B |
| 41 | 262086-4 | RING X 9015B-9016B |
| 42 | 442126-6 | GASKET X 9015B-9016B |
| 43 | 183053-5 | GEAR SET X 9015B |
