Makita Spare Parts for Jigsaw 4304T
€13.85
Tax included
Makita Spare Parts for Jigsaw 4304T
We have the original Makita Spare Parts for Jigsaw 4304T, the diagram, parts list and tool repair that help you need to get your tools running like new again.Fix Your Jigsaw 4304T. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Jigsaw 4304T
We have the original Makita Spare Parts for Jigsaw 4304T, the diagram, parts list and tool repair that help you need to get your tools running like new again.
In the following table, look for the model of Jigsaw and the respective parts of the code.
| Jigsaw 4304T | ||
| # | Part Num. | Description |
| 1 | 912102-9 | SCREW 4 X 6 X 4334D |
| 2 | 182788-5 | HANDLE CPL X 4304T |
| 4 | 344331-0 | SWITCH LEVER X 4304T |
| 5 | 233101-1 | COMPRESSION SPRING 4 |
| 7 | 415880-5 | 4304T STARTING PLATE |
| 8 | 415159-4 | SPACER X 4304 |
| 9 | 651922-3 | TG71B SWITCH |
| 10 | 631678-4 | REGULATOR 200 / 220V X 4304T |
| 11 | 256221-4 | PIN 3 X JR3020 |
| 12 | 415158-6 | JR3020 SWITCH LEVER |
| 13 | 645258-0 | CAPACITOR X 4304T |
| 14 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 15 | 687063-9 | STRAIN RELIEF X 4304T |
| 16 | 682502-4 | CORD GUARD 8/85 6408 |
| 17 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 19 | 322691-0 | GEAR SHAFT X 4304/05 |
| 20 | 253139-0 | FLAT WASHER 8 |
| 21 | 212043-2 | BALL BEARING TLA810Z HR201 |
| 22 | 226428-6 | GEAR 51 X 4304/05 |
| 23 | 212043-2 | BALL BEARING TLA810Z HR201 |
| 24 | 253792-2 | FLAT WASHER 26 X 9045B / N |
| 25 | 344134-2 | PUSH PLATE X 4304 |
| 26 | 344330-2 | BALANCE PLATE |
| 27 | 344330-2 | BALANCE PLATE |
| 28 | 253792-2 | FLAT WASHER 26 X 9045B / N |
| 29 | 152454-8 | ECCENTRIC HANDLE X 4304 |
| 30 | 212010-7 | NEEDLE BEARING 607 |
| 31 | 344232-2 | CURSOR PLATE X 4304 |
| 32 | 310028-3 | CURSOR X 4304 |
| 33 | 316608-3 | SLIDER CURSOR X 4304 |
| 34 | 153389-6 | HOUSING GEAR COVER 4304 |
| 35 | 322839-4 | CONNECTOR X 4304T |
| 36 | 416351-5 | JOINT X 4304T |
| 37 | 322826-3 | TRASMISSION ROD X 4304T |
| 38 | 266034-5 | SCREW CT 4X16 |
| 39 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 40 | 152947-5 | COMPLETE BLADE GUIDE |
| 41 | 266115-5 | SCREW M4X55 X 4304T |
| 42 | 256693-3 | PIN 4 X 4304 4305 |
| 43 | 266048-4 | SCREW M 4 X 40 X 4334D |
| 45 | 168282-1 | SHAFT X 4304T - 4305T |
| 46 | 310005-5 | BLADE CLAMP X 4304T - 4305T |
| 47 | 344137-6 | SLIDING PLATE X 4304 |
| 48 | 233151-6 | SPRING 4 X 4304T X 4305T |
| 49 | 961017-7 | E-3 X 4305T RING |
| 50 | 265035-0 | SCREW M4X10 |
| 51 | 922126-7 | SCREW M4X16 HR5000K / 3850B |
| 52 | 961004-6 | RETAINING RING S8 |
| 53 | 442123-2 | GASKET X 4304 4305 |
| 54 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 55 | 253715-0 | FLAT WASHER 6 6510PBL / LVR / 43SB |
| 56 | 151595-7 | GEAR BOX 4304/4305 |
| 57 | 911111-5 | CYLINDER HEAD SCREW M4X10 |
| 58 | 253715-0 | FLAT WASHER 6 6510PBL / LVR / 43SB |
| 59 | 253811-4 | WASHER 5 X 5012B |
| 60 | 272232-1 | LEVER 65 X 4304T-4305T |
| 61 | 265434-6 | SCREW M5X24 X 4304T-4305T |
| 62 | 344332-8 | NUT M6 X 4304T-4305T |
| 63 | 211031-6 | BEARING 608LLB X 4304T |
| 64 | 240039-3 | FAN 54 |
| 65 | 517098-5 | ARMATURE X 4304 4305 |
| 66 | 681636-0 | INSULATING WASHER |
| 67 | 211021-9 | BALL BEARING 607LLB |
| 68 | 421494-0 | RUBBER RING 19 X 9521NB |
| 70 | 344333-6 | FIXING PLATE X 4304T |
| 71 | 252142-8 | NUT M5 X 4304T-4305T |
| 72 | 911109-2 | SCREW M4X8 X 4304T-4305T |
| 73 | 912202-5 | FLAT HEAD SCREW M5X8 |
| 74 | 344443-9 | BASIC PLATE X 4304 |
| 75 | 191962-4 | CARBON BRUSHES CB-419 (406.407) 418 |
| 76 | 643923-5 | BRUSH HOLDER X 6408 |
| 77 | 646067-0 | CHOKE COIL X 6408 |
| 79 | 266050-7 | SCREW PT 4X30 |
| 80 | 415532-8 | REAR COVER X 4304 |
| 82 | 415538-6 | PLUG X4304 |
| 83 | 415748-5 | HOUSING MOTOR X 4304 |
| 84 | 633288-3 | STATOR X 4304 |
| 85 | 415879-0 | AIR CAP X 4304T-4305T |
| 86 | 415878-2 | DEFLECTOR X 4304T-4305T |
| 87 | 266052-3 | SCREW PT 4X60 |
| 88 | 272231-3 | LEVER 17 X 4304 4305 |
| 89 | 231314-8 | SPRING 4 JG16 / 4301BV |
| 90 | 216008-6 | BALL 4 |
| 91 | 961018-5 | STOP RING E5 |
| 92 | 263002-9 | RUBBER PIN 4 |
| 93 | 344537-0 | PIN X 4304T, 4305T |
| 94 | 443106-5 | FELT 10-20 |
| 95 | 344784-3 | SAFETY SEAL X 4304 |
| 96 | 268074-9 | PIN 4 FOR 4304 |
| 97 | 152950-6 | ROLL CPL X 4304 |
| 98 | 253310-6 | WASHER 10 56DW / HR3850B |
| 99 | 421821-1 | DUST COVER 8 |
