We have the original Spares MAKITA for Trimmer 3708, the Repair information, Exploded Diagram, parts list and tool repair that help you need to get your tools running like new again.
Fix Your Trimmer 3708. All Spares are original and can be supplied at Cheap and discounted prices. Our Spares are Genuine Parts Guaranteed.
In the following table, look for the model of Power Trimmer and the respective parts of the code.![]()
| Trimmer 3708 | ||
| # | Part Num. | Description |
| 2 | 682502-4 | CABLE SLEEVE 8/85 6408 |
| 4 | 417747-3 | TOP COVER X 3707 |
| 5 | 687127-9 | DISTANCE X 3707 |
| 6 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 7 | 687063-9 | RELIEF X 4304T |
| 8 | 643928-5 | PLUG BRUSH X9524NB |
| 9 | 191940-4 | CARBON BRUSHES CB-411 X EX 422/421 |
| 10 | 183417-3 | HOUSING UPPER MOT. X 3707 |
| 11 | 595069-2 | STATOR X 3707 |
| 12 | 266004-4 | SCREW 4x70 |
| 17 | 421494-0 | RUBBER 19 X 9521NB |
| 18 | 210017-7 | BEARING 607DDW |
| 19 | 681636-0 | INSULATION WASHER |
| 20 | 517574-9 | ARMATURE X 3707 |
| 21 | 240049-0 | FAN 48 X 3707 |
| 22 | 961055-9 | RETAINING RING S15 |
| 23 | 211236-8 | BEARING 6002DDW X 5705R |
| 24 | 651423-1 | SWITCH X 3706 |
| 26 | 654544-8 | CLAMP CABLES X X 3707 |
| 29 | 251991-0 | SCREW M 4 X 12 X 3707 |
| 30 | 417750-4 | HOLDER X 3707 |
| 31 | 266048-4 | SCREW M 4 X 40 X 4334D |
| 32 | 153347-2 | HOUSING COMPLETE X 3707 |
| 33 | 763607-0 | CALIPER 6 X 3700B / D / 3705 |
| 34 | 763606-2 | NUT CLAMP X 3700B |
| 35 | 251814-2 | WHEEL SCREW 6X18 |
| 36 | 942151-2 | WASHER 6 4101R |
| 37 | 941151-9 | WASHER 6 X HM1303 |
| 38 | 153351-1 | BASE COMPLETE 3708FC |
| 39 | 414304-8 | BASIC GUIDE LOWER X 3704 |
| 40 | 256221-4 | PIN 3 X JR3020 |
| 41 | 421566-1 | ROLLER X 3707 |
| 42 | 252103-8 | NUT X JR3020 |
| 43 | 941101-4 | FLAT WASHER 5 |
| 44 | 267214-6 | FLAT WASHER X 3707 |
| 45 | 324243-3 | SCREW HOLDER X 3707 |
| 46 | 951060-4 | JACK BAND 3/14 |
| 47 | 421818-0 | HOOD RUBBER X 3707 |
| 48 | 345229-4 | LEVER BLOCK X 3707 |
| 49 | 252646-0 | NUT M 5 X 3708FC |
| 50 | 942101-7 | SPRING WASHER 5 |
| 51 | 941101-4 | FLAT WASHER 5 |
| 52 | 911114-9 | SCREW M4 X 10 |
| 53 | 941101-4 | FLAT WASHER 5 |
| 54 | 942101-7 | SPRING WASHER 5 |
| 55 | 265740-9 | SCREW M 5 X 15 X RP1100C |
| 56 | 267248-9 | WASHER 8 X 3708FC |
| 57 | 923241-0 | SCREW Q.S.T. M5X25 |
| 58 | 253905-5 | WASHER 23 X 8035NB |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
