Makita Multi-Tool TM3010C Parts
€6.29
Tax included
Makita Multi-Tool TM3010C Parts
Makita Original spare parts sourced from the manufacturer, at the lowest price on the web, with after-sales service, for to make maintenance or repair deteriorated parts for Multi-Tool TM3010C.Features
- Ergonomic soft grip coating
- Regulator speed
- Constant speed under load
- Slow start
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Multi-Tool TM3010C Parts
Makita Original spare parts sourced from the manufacturer, at the lowest price on the web, with after-sales service, for to make maintenance or repair deteriorated parts for Multi-Tool TM3010C.In the following table, look for the model of the Multi-Tool and the respective parts of the code.
| Multi-Tool TM3010C Parts | ||
| # | Part Num. | Description |
| 1 | 454634-5 | UPPER HEAD COVER |
| 1-1 | 455272-6 | UPPER HEAD COVER |
| 2 | 319059-9 | LEVER |
| 3 | 313268-2 | TURN BLOCK |
| 4 | 911102-6 | PAN HEAD SCREW M4X6 |
| 5 | 232282-8 | LEAF SPRING |
| 6 | 266424-2 | TAPPING SCREW 4X20 |
| 6-1 | 265D38-8 | TAPPING SCREW 4X20 |
| 7 | 268306-4 | PIN 5 |
| 8 | 326346-9 | HOLDER BOLT |
| 8-1 | 327176-1 | HOLDER BOLT |
| 9 | 266424-2 | TAPPING SCREW 4X20 |
| 9-1 | 265D38-8 | TAPPING SCREW 4X20 |
| 10 | 454635-3 | LOWER HEAD COVER |
| 11 | 213343-3 | O RING 35 |
| 11-1 | 213A08-3 | O RING 35 |
| 12 | 326347-7 | BEARING BOX |
| 13 | 961003-8 | RETAINING RING S-7 |
| 14 | 211392-4 | SPHERE BEARING 706 |
| 14-1 | 210164-4 | SPHERE BEARING 706 |
| 15 | 253133-2 | FLAT WASHER 7 |
| 16 | 313245-4 | BALANCER |
| 17 | 211092-6 | BALL BEARING 629DDW |
| 18 | 285857-2 | BEARING RETAINNER |
| 19 | 240140-4 | FAN 46 |
| 20 | 517683-4 | ARMATURE ASSEMBLY 220-240V |
| 20 | INC. 19,21-26 | |
| 21 | 681636-0 | INSULATION WASHER |
| 22 | 267426-1 | FLAT WASHER 7 |
| 23 | 210023-2 | BALL BEARING 627DDW |
| 24 | 267756-0 | WAVE WASHER 6 |
| 25 | 688174-3 | MAGNET SLEEVE |
| 25-1 | 688117-5 | MAGNET SLEEVE |
| 26 | 259039-2 | SELF LOCK 6 |
| 27 | 453828-9 | BAFFLE PLATE |
| 28 | 266415-3 | TAPPING SCREW 4X55 |
| 28-1 | 265D37-0 | TAPPING SCREW 4X55 |
| 29 | 623558-8 | STATOR FIELD TM3000C |
| 30 | 453823-9 | MOTOR HOUSING |
| 31 | 453761-5 | SWITCH KNOB |
| 32 | 453825-5 | SWITCH LEVER |
| 33 | 234263-8 | COMPRESSION SPRING 5 |
| 34 | 651609-7 | SWITCH SS106A-7-1 |
| 35 | 643839-4 | BRUSH HOLDER 6X9 |
| 36 | 266492-5 | TAPPING SCREW 3X8 |
| 36-1 | 265D33-8 | TAPPING SCREW 3X8 |
| 37 | 194722-3 | CARBON BRUSH CB-459 |
| 37-1 | 195026-6 | CARBON BRUSH SET CB-459 |
| 38 | 654532-5 | TERMINAL BLOCK 1P |
| 39 | 687681-3 | STRAIN RELIEF |
| 40 | 266326-2 | TAPPING SCREW 4X18 |
| 40-1 | 265B67-9 | TAPPING SCREW 4X18 |
| 41 | 665399-6 | POWER SUPPLY CORD 1.0-2-5.0 |
| 42 | 682569-2 | CORD GUARD 8-85 |
| 43 | 814T82-4 | TM3010C NAME PLATE |
| 44 | 620234-5 | CONTROLLER |
| 45 | 453824-7 | REAR COVER |
| 46 | 266424-2 | TAPPING SCREW 4X20 |
| 46-1 | 265D38-8 | TAPPING SCREW 4X20 |
| 47 | 142208-1 | CRANK HOUSING COMPLETE |
| 47-1 | 143249-0 | CRANK HOUSING COMPLETE |
| A01 | 142257-8 | TOOL BOX COMPLETE |
| C10 | 454652-3 | LATCH |
| A01-1 | 143308-0 | TOOL BOX COMPLETE WITH LABEL |
| C10 | 454652-3 | LATCH |
| A02 | 454247-2 | PIN 4 |
| A03 | 821550-0 | CONNECTOR PLASTIC CASE (TYP E2) |
| C10 | 453974-8 | LATCH |
| A03-1 | 821550-0 | CONNECTOR PLASTIC CASE (TYP E2) |
| C10 | 453974-8 | LATCH |
| A04 | 837773-0 | INNER TRAY |
| A05 | 802B42-0 | TM3010CJ INDICATION LABEL |
| A05 | 802B46-2 | TM3010CX2J INDICATION LABEL |
| A05 | 802B52-7 | TM3010CX5J INDICATION LABEL |
| A06 | 802B43-8 | TM3010CJ PLASTIC CASE LABEL |
| A06 | 802B47-0 | TM3010CX2J PLASTIC CASE LABE L |
| A6 | 8007F7-8 | TM3010CX5J PLASTIC CASE LABE L |
| A7 | 196550-2 | DUST ATTACHMENT SET |
| C10 | 443177-2 | FELT RING 37 |
| C20 | 453832-8 | JOINT |
| C30 | 453835-2 | NOZZLE BAND A |
| C40 | 454636-1 | DUST ATTACHMENT |
| C50 | 454637-9 | DUST NOZZLE D |
| A07-1 | 199624-8 | DUST ATTACHMENT SET |
| C10 | 443177-2 | FELT RING 37 |
| C20 | 453832-8 | JOINT |
| C30 | 453835-2 | NOZZLE BAND A |
| C40 | 454636-1 | DUST ATTACHMENT |
| C50 | 454637-9 | DUST NOZZLE D |
| C60 | 422362-0 | FELT RING 47 |
| C70 | 459362-7 | SPACER |
| A08 | 196272-4 | ADAPTER A SET |
| A08-1 | 196271-6 | ADAPTER A SET |
| A09 | B-21325 | SEGMENT SAW BLADE 85 TMA00 6 |
| A09-1 | B-64799 | STARLOCK SEGMENTSAW 85 TM A045 |
| A10 | B-21331 | SEGMENT SAW BLADE 85 TMA00 |
| A10-1 | B-64836 | STARLOCK SEGMENTSAW 85 TM A049 |
| A10-2 | B-64842 | STARLOCK CUTSAW 24 TMA050 |
| A11 | B-21353 | PLUNGE CUT SAW BLADE 28 TM A009 |
| A11-1 | B-64814 | STARLOCK CUTSAW 32 TMA047 BIM |
| A11-1 | B-64842 | STARLOCK CUTSAW 24 TMA050 HCS |
| A12 | B-21369 | PLUNGE CUT SAW BLADE 32 TM A010 |
| A12-1 | B-64870 | STARLOCK CUTSAW 32 TMA053 |
| A13 | B-21381 | PLUNGE CUT SAW BLADE 32 TM A012 |
| A13-1 | B-64858 | STARLOCK CUTSAW 32 TMA051 HCS |
| A14 | B-21428 | PLUNGE CUT SAW BLADE 20 TM A016 |
| A14-1 | B-64923 | STARLOCK CUTSAW 20 TMA058 BIM |
| A14-2 | B-64923 | STARLOCK CUTSAW 20 TMA058 BIM |
| A15 | B-21434 | PLUNGE CUT SAW BLADE 10 TM A017 |
| A15-1 | B-64917 | STARLOCK CUTSAW 10 TMA057 BIM |
| A15-2 | B-64917 | STARLOCK CUTSAW 10 TMA057 BIM |
| A16 | B-21456 | SCRAPER 52 FLEXIBLE TMA019 |
| A16-1 | B-64995 | STARLOCK SCRAPERFLEXIBLE TM A66 |
| A17 | B-21490 | HM SEG SAW BLADE 85 TMA023 |
| A17-1 | B-65028 | STARLOCK SEGMENTSAW 85 TM A069 |
| A18 | B-21509 | HM SEG SAW BLADE 65 TMA024 |
| A18-1 | B-65040 | STARLOCK SEGMENTSAW 70 TM A071 |
| A19 | B-21537 | SANDING PAD |
| A19-1 | B-46202 | SANDING PAD |
| A19-2 | B-65115 | STARLOCK SANDING PAD 93 TM A078 |
| A19-3 | B-46202 | SANDING PAD |
| A19-4 | B-65115 | STARLOCK SANDING PAD 93 TM A078 |
| A20 | B-21624 | ABRASIVEPAPER DELTA RED 60 |
| A21 | B-21668 | ABRASIVEPAPER DELTA RED 240 |
| A22 | B-21630 | ABRASIVEPAPER DELTA RED 80 |
| A23 | B-22947 | ABRASIVEPAPER DELTA RED 100 |
| A24 | B-22953 | ABRASIVEPAPER DELTA RED 150 |
| A25 | 821591-6 | TOOL BOX |
| C10 | 454652-3 | LATCH |
