Castelgarden XH 55 Hedge Trimmer XH 55 Spare Parts
€1.56
Tax included
Castelgarden XH 55 Hedge Trimmer XH 55 Spare Parts
Distribution and Sale at attractive prices of Castelgarden Original Spare Parts. We guarantee low prices and a professional Licensed Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue fo Hedge Trimmer Castelgarden XH 55 - 252800003/09.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Castelgarden XH 55 Hedge Trimmer XH 55 Spare Parts
Distribution and Sale at attractive prices of Castelgarden Original Spare Parts. We guarantee low prices and a professional Licensed Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue fo Hedge Trimmer Castelgarden XH 55 - 252800003/09.In the following table, look for the model of the Chaisaw and the respective parts of the code.
| CASTELGARDEN XH 55 (2010) 252800003/09 Spare Parts Pag.1 | ||
| # | Part Num. | Description |
| 1 | 6981116 | Outfit, Screws |
| 2 | 6981154 | Washer |
| 3 | 6981158 | Deflector |
| 4 | 6981159 | Engine Cover Orange |
| 5 | 6981115 | Outfit, Screws |
| 6 | 6981160 | Muffler |
| 7 | 6981041 | Muffler Protection |
| 8 | 6981113 | Outfit, Screws |
| 9 | 6981163 | Spark Plug |
| 10 | 6981116 | Outfit, Screws |
| 11 | 6981043 | Guard assy |
| 12 | 6981004 | Cylinder Gasket |
| 13 | 6981015 | Washer, Piston Pin |
| 14 | 6981014 | Piston Pin |
| 15 | 6981013 | Piston Ring |
| 16 | 6981012 | Piston Assy |
| 17 | 6981003 | Cylinder - Piston Ass'Y |
| 18 | 6981017 | Needle Bearing |
| 19 | 6981016 | Crankshaft |
| 20 | 6981096 | Flywheel Key |
| 21 | 6981110 | Needle Bearing |
| 22 | 6981008 | Seal Ring |
| 23 | 6981006 | Rear Crank Case |
| 24 | 6981031/1 | Starter Cup |
| 27 | 6981007 | Crankcase Gasket |
| 28 | 6981126 | Centring Pin |
| 29 | 6981005 | Front Crank Case |
| 30 | 118800390/0 | Flywheel Assy From 01 September 2008 |
| 30 | 6981002 | Flywheel Assy To 31 August 2008 |
| 31 | 6981102 | Outfit, Screws |
| 32 | 6981128 | Washer |
| 33 | 6981143 | Nut |
| 34 | 6981034 | Spring |
| 35 | 6981276 | Washer |
| 36 | 6981032 | Clutch Unit |
| 37 | 6981035 | Screw |
| 38 | 6981116 | Outfit, Screws |
| 39 | 6981033 | Washer |
| 41 | 118800391/0 | Electronic Coil From 01 September 2008 |
| 41 | 6981204 | Electronic Coil To 31 August 2008 |
| 42 | 6981023 | Cover, Spark Plug |
| 43 | 6981133 | Cable Retainer |
| 44 | 6981022 | Switch Wires |
| 45 | 6981205 | Support |
| 46 | 6981116 | Outfit, Screws |
| 49 | 6981118 | Outfit, Screws |
| 50 | 6981203 | Brake Band |
| 51 | 6981202 | Brake Spring |
| 52 | 6981198 | Cover |
| 53 | 6981201 | Lever |
| 54 | 6981200 | Screw |
| 55 | 6981199 | Nut |
| 56 | 6981197 | Flange |
| 57 | 6981144 | Screw |
| 58 | 6981164 | Clutch Drum |
| 59 | 6981038 | Fuel Hose |
| 60 | 6981039 | Grommet Assy |
| 61 | 6981313 | Fuel Tank Assy |
| 62 | 6981091 | Cap Ass'Y, Fuel Tank |
| 63 | 6981101 | Outfit, Screws |
| 65 | 4253292 | Intake Filter |
| CASTELGARDEN XH 55 (2010) 252800003/09 Pag.2 | ||
| # | Part Num. | Description |
| 1 | 6981116 | Outfit, Screws |
| 2 | 6981161/1 | Starter Assy |
| 4 | 6981025 | Spring |
| 5 | 6981026 | Starter Pulley |
| 6 | 6981029 | Starter cord |
| 7 | 6981027 | Starter Handle |
| 8 | 6981138 | Washer |
| 9 | 6981145 | Screw |
| 11 | 6981011 | Intake Manifold Gasket |
| 12 | 6981010 | Intake Manifold |
| 13 | 6981018 | Intake Carburator Gasket |
| 14 | 6981266 | Outfit, Screws |
| 15 | 123054012/0 | Carburettor To 31 August 2005 |
| 15 | 123054012/1 | Carburettor assembly From 01 September 2005 |
| 16 | 6981137 | Air Lever |
| 17 | 6981136 | Starter Valve |
| 18 | 6981268 | Screw |
| 19 | 6981131 | Air Filter Holder |
| 20 | 6981104 | Outfit, Screws |
| 23 | 6981020 | Air Filter |
| 24 | 6981134 | Filter Cover |
| 25 | 6981132 | Screw |
| Cutting Blade Pag.3 | ||
| # | Part Num. | Description |
| 1 | 6981193 | Right Handgrip |
| 2 | 6981192 | Earth Cable |
| 3 | 6981191 | Coil-Switch Cable |
| 4 | 6981194 | Stop Switch |
| 5 | 6981188 | Throttle Cable |
| 6 | 6981186 | Spring |
| 7 | 6981187 | Throttle Lever |
| 8 | 6981182 | Spring |
| 9 | 6981183 | Gearshift |
| 10 | 6981185 | Hook |
| 11 | 6981184 | Throttle Rod |
| 12 | 6981189 | Spring |
| 13 | 6981190 | Safety Lever |
| 14 | 6981195 | Left Handgrip |
| 15 | 6981180 | Right Support |
| 16 | 6981142 | Nut |
| 17 | 6981165 | Case |
| 18 | 6981181 | Left Support |
| 19 | 6981155 | Washer |
| 20 | 6981152 | Washer |
| 21 | 6981148 | Screw |
| 22 | 6981156 | Washer |
| 23 | 6981153 | Washer |
| 24 | 6981140 | Screw |
| 25 | 6981139 | Needle Bearing |
| 26 | 6981175 | Pinion |
| 27 | 6981176 | Gear Assy |
| 28 | 6981151 | Ring |
| 29 | 6981177 | Connecting Rod |
| 30 | 6981177 | Connecting Rod |
| 31 | 6981110 | Needle Bearing |
| 32 | 6981169 | Shoe |
| 33 | 6981179 | Case |
| 34 | 6981100 | Outfit, Screws |
| 35 | 6981287 | Knob |
| 37 | 6981281 | Screw |
| 38 | 6981166 | Plate |
| 39 | 6981280 | Nut |
| 40 | 6981171 | Bottom Blade |
| 41 | 6981170 | Top Blade |
| 42 | 6981168 | Blade Holder |
| 43 | 6981167 | Blade Guard |
| 44 | 6981173 | Screw |
| 45 | 6981172 | Washer |
| 46 | 6981279 | Nut |
| 47 | 6981196 | Front Handle |
| 48 | 6981150 | Screw |
| 49 | 6981155 | Washer |
| 50 | 6981152 | Washer |
| 51 | 6981142 | Nut |
| 52 | 6981174 | Blade Cover |
| 53 | 6981149 | Screw |
| 54 | 6981155 | Washer |
| 55 | 6981152 | Washer |
| 56 | 6981147 | Screw |
