Castelgarden Spare Parts for Petrol Hedge Trimmer XH 60
€6.54
Tax included
Castelgarden Spare Parts for Petrol Hedge Trimmer XH 60
Distribution and Sale at attractive prices of Castelgarden Original Spare Parts. We guarantee low prices and a professional Licensed Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue fo Petrol Hedge Trimmer Castelgarden XH60/252961003/C19-2020.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Castelgarden Spare Parts for Petrol Hedge Trimmer XH 60
Distribution and Sale at attractive prices of Castelgarden Original Spare Parts. We guarantee low prices and a professional Licensed Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue fo Petrol Hedge Trimmer Castelgarden XH60/252961003/C19-2020.
Open file PDF in this page to view all the spare parts for the Hedge Trimmer XH 60.
| Hedge Trimmer Castelgarden XH60/252961003/C19-2020 | ||
| Engine A Pag.1 | ||
| # | Part Num. | Description |
| 2 | 123878109/0 | Screw |
| 3 | 183082003/0 | Starter Cup assembly |
| 7 | 118802744/0 | Flywheel |
| 8 | 123878081/0 | Screw |
| 9 | 123657017/0 | Washer |
| 10 | 123657013/0 | Washer |
| 11 | 119035164/0 | Oil seal |
| 13 | 123685020/0 | Crankase |
| 14 | 114215222/0 | Ball bearing |
| 15 | 123020033/1 | Crankshaft |
| 17 | 123280077/0 | Crankase gasket |
| 19 | 119035165/0 | Oil seal |
| 21 | 123445268/0 | Clutch hub |
| 23 | 183215010/0 | Ass. Clutch |
| 25 | 123878111/0 | Screw |
| 26 | 123065045/0 | Spark plug cable |
| 27 | 123878081/0 | Screw |
| 28 | 123657013/0 | Washer |
| 29 | 123657017/0 | Washer |
| 30 | 118802743/0 | Ignityion coil assy |
| 31 | 123160063/0 | Spacer |
| 32 | 123652505/0 | Washer |
| 33 | 123235008/0 | Neddle bearing |
| 34 | 183590007/0 | Piston assembly |
| 37 | 123204016/0 | Piston ring |
| 38 | 123280078/0 | Cylinder gasket |
| 39 | 123878081/0 | Screw |
| 40 | 118802742/0 | Muffler |
| 42 | 123600078/0 | Heat guard |
| 43 | 3210024 | Spark plug |
| 44 | 123071023/0 | Cylinder |
| 45 | 123280080/0 | Intake manifold gasket |
| 47 | 118801419/0 | Intake manifold |
| 48 | 112789195/0 | Screw |
| 49 | 118801420/0 | Spark plug cover |
| 50 | 123600080/0 | Cylinder cover |
| 51 | 118801421/0 | Carburetor gasket |
| 52 | 118801422/0 | Carburetor |
| 53 | 118801423/0 | Air Filter Base |
| 54 | 123878114/0 | Screw |
| 55 | 118801424/0 | Air filter |
| 56 | 118801427/0 | Air Filter Cover, Gray |
| 57 | 118802164/0 | Air lever, black |
| 57 | 118802165/0 | Air lever, Blue |
| 58 | 118804984/0 | Engine Short Block |
| 59 | 118804985/0 | Cylinder - Piston assembly |
| Engine B Pag.2 | ||
| 1 | 123300014/0 | Front handle |
| 2 | 123878121/0 | Screw |
| 3 | 118801430/0 | Muffler cover grey |
| 4 | 123430606/0 | Spring |
| 6 | 123657017/0 | Washer |
| 8 | 123784008/0 | Handle support case |
| 9 | 123430607/0 | Spring |
| 10 | 118801431/0 | Cap, Gray |
| 11 | 123878121/0 | Screw |
| 13 | 118801432/0 | Knob |
| 14 | 123700065/0 | Left Handle |
| 15 | 118801433/0 | Spring |
| 16 | 123315099/0 | Lock Lever |
| 17 | 118801435/0 | Safety lever, blue |
| 18 | 123430609/0 | Spring |
| 19 | 118801437/0 | Blue Throttle Lever |
| 20 | 123700066/0 | Right handle |
| 21 | 123303007/0 | Switch |
| 22 | 123202008/0 | Lock handle |
| 23 | 123878115/0 | Screw |
| 24 | 123657023/0 | Rubber |
| 25 | 123044223/0 | Bush |
| 26 | 123878124/0 | Screw |
| 27 | 118801438/1 | Fuel Tank |
| 28 | 123275031/0 | Rubber |
| 29 | 118801439/0 | Tank cap |
| 36 | 183520009/0 | Intake filter |
| 37 | 123867028/0 | Fuel pipe |
| 38 | 1232940080 | Wire guide plate |
| 40 | 123867029/0 | Fuel pipe |
| 41 | 123275032/0 | Rubber Grommet |
| 42 | 118801440/0 | Starting handle |
| 43 | 123234007/0 | Starting rope |
| 45 | 118801450/0 | Blue Starter Assembly |
| 46 | 123430610/0 | Starter spring |
| 47 | 123604013/0 | Starter Pulley |
| 48 | 112728445/0 | Screw |
| 49 | 118801443/0 | Cylinder Cover grey |
| 50 | 112735654/0 | Screw |
| 51 | 118801446/0 | Engine cover |
| 53 | 118801447/0 | Throttle cable |
| 54 | 118801448/0 | Cable retainer |
| 55 | 112726389/0 | Screw |
| 56 | 118804986/0 | Handle assembly |
| 57 | 118804987/0 | Fuel tank assembly |
| 57 | 118804987/1 | Fuel tank assembly |
| 57 | 118805247/0 | Fuel tank assembly |
| Blade Assembly Pag.3 | ||
| 1 | 123050010/0 | Clutch drum |
| 2 | 123657013/0 | Washer |
| 3 | 123657017/0 | Washer |
| 5 | 123685022/0 | Engine support assembly |
| 6 | 123657013/0 | Washer |
| 7 | 123657017/0 | Washer |
| 8 | 123878081/0 | Screw |
| 9 | 123280082/0 | Crankcase Gasket |
| 11 | 112379520/0 | Greaser nipple |
| 12 | 114215222/0 | Ball bearing |
| 15 | 123570052/0 | Pinion |
| 16 | 114215223/0 | Bearing |
| 17 | 123664000/0 | Sprocket |
| 18 | 123041502/0 | Connecting rod |
| 21 | 123685023/0 | Engine support assembly |
| 22 | 123878081/0 | Screw |
| 24 | 123878118/0 | Screw |
| 26 | 123878110/0 | Screw |
| 27 | 123878113/0 | Screw |
| 28 | 123294006/0 | Lower blade guide |
| 29 | 123044222/0 | Bush |
| 30 | 123305004/0 | Blade |
| 31 | 123120014/0 | Nut |
| 32 | 123600081/0 | Blade protection |
| 33 | 123294007/0 | Upper blade guide |
| 35 | 123085002/0 | Blade cover |
| 36 | 118804982/0 | Engine Support Assembly |
| 37 | 118804983/0 | Klingen |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Castelgarden websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Castelgarden brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
