Alpina Spare Parts for Hedge Trimmer HTJ 550
€1.87
Tax included
Alpina Spare Parts for Hedge Trimmer HTJ 550
Alpina original spare parts, sourced from the manufacturer, at the best price on the web, for to Make Maintenance or Replacement of Broken parts of the Hedge Trimmer HTJ 550/252900000-14-2016.Fix Your Hedge Trimmer HTJ 550. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Guarantee
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Alpina Spare Parts for Hedge Trimmer HTJ 550
Alpina original spare parts, sourced from the manufacturer, at the best price on the web, for to Make Maintenance or Replacement of Broken parts of the Hedge Trimmer HTJ 550/252900000-14-2016.
In the following table, look for the model of the Petrol Hedgecutter and the respective parts of the code.
| Hedgecutter HTJ 550/252900000-14-2016 Engine Pag.1 | ||
| # | Part Num. | Description |
| 1 | 123120012/0 | Nut |
| 2 | 123878109/0 | Screw |
| 5 | 183082003/0 | Starter Cup |
| 7 | 118802744/0 | Flywheel |
| 8 | 123878110/0 | Screw |
| 9 | 123657017/0 | Washer |
| 10 | 123657013/0 | Washer |
| 11 | 119035164/0 | Seal Ring |
| 12 | 112610002/0 | Snap Ring |
| 13 | 123685020/0 | Crank Case |
| 14 | 114215221/0 | Ball Bearing |
| 17 | 123280077/0 | Crankcase Gasket |
| 18 | 123685021/0 | Crank Case |
| 19 | 119035165/0 | Seal Ring |
| 20 | 123657019/0 | Washer |
| 21 | 123445268/0 | Hub |
| 22 | 123657020/0 | Washer mm 6x12 |
| 23 | 183215010/0 | Clutch Ass.Y |
| 26 | 123878111/0 | Screw |
| 27 | 123065045/0 | Spark Plug Cable |
| 31 | 118802743/0 | Ignition Coil Ass'Y - Euro 2 |
| 32 | 123160063/0 | Spacer |
| 33 | 123652505/0 | Washer |
| 34 | 123235008/0 | Needle Bearing |
| 35 | 123202006/0 | Circlip |
| 36 | 183590007/0 | Piston Assy |
| 37 | 123590012/0 | Piston |
| 38 | 123204016/0 | Piston Ring |
| 39 | 123280078/0 | Cilynder Gasket |
| 40 | 123878112/0 | Screw |
| 41 | 118802742/0 | Muffler |
| 42 | 123280079/0 | Muffler Gasket |
| 43 | 123600078/0 | Guard |
| 45 | 123071023/0 | Cilynder |
| 46 | 123280080/0 | Intake Manifold Gasket |
| 47 | 123120013/0 | Nut |
| 48 | 123073518/0 | Intake Manifold |
| 49 | 123878113/0 | Screw |
| 50 | 123600079/0 | Grommet |
| 51 | 123600080/0 | Cylinder Cover |
| 52 | 123280081/0 | Carburetor Gasket |
| 53 | 123054036/0 | Carburetor |
| 54 | 123040005/0 | Air Cleaner Base |
| 55 | 123878114/0 | Screw |
| 56 | 123220011/0 | Air Filter |
| Hedgecutter HTJ 550/252900000-14-2016 Engine Pag.2 | ||
| 1 | 123300014/0 | Front Handle |
| 2 | 123878121/0 | Screw |
| 3 | 118801430/0 | Muffler Cover,Grey |
| 4 | 123430606/0 | Spring |
| 5 | 123657022/0 | Washer |
| 6 | 123657017/0 | Washer |
| 7 | 123878120/0 | Screw |
| 8 | 123784008/0 | Case |
| 9 | 123430607/0 | Spring |
| 10 | 123790023/0 | Spring Cap,Black |
| 11 | 123878121/0 | Screw |
| 12 | 123109588/0 | Cover |
| 13 | 118801432/0 | Knob |
| 14 | 123700065/0 | Left Handgrip substituted by 118804986/0 |
| 15 | 118801433/0 | Spring |
| 16 | 123315099/0 | Lever |
| 17 | 118801435/0 | Safety Lever,Blue |
| 18 | 123430609/0 | Spring |
| 19 | 118801437/0 | Throttle Lever, Blue |
| 20 | 123700066/0 | Right Handgrip |
| 21 | 123303007/0 | Switch |
| 22 | 123202008/0 | Retainer |
| 23 | 123878115/0 | Screw |
| 24 | 123657023/0 | Grommet |
| 25 | 123044223/0 | Bushing |
| 26 | 123878124/0 | Screw |
| 27 | 123733006/0 | Fuel Tank |
| 27A | 123733006/0-Assy | Fuel Tank Assy |
| 28 | 123275031/0 | Grommet |
| 29 | 118801439/0 | Fuel Tank Cap |
| 36 | 183520009/0 | Intake Filter |
| 37 | 123867028/0 | Tube |
| 38 | 123044008/0 | Electronic Coil |
| 39 | 123878122/0 | Screw |
| 40 | 123275032/0 | Grommet |
| 41 | 123867029/0 | Tube |
| 41A | 183520009/0-Assy | Fuel Tube Ass'y Include 36-37-40-41 |
| 42 | 118801440/0 | Starter Handle |
| 42A | 118804986/0 | Handle Assy HTJ 550 |
| 43 | 123234007/0 | Starter Cord |
| 45 | 183058040/0 | Starter Ass.Y Black |
| 46 | 123430610/0 | Starter Spring |
| 47 | 123604013/0 | Starter Pulley |
| 48 | 112728445/0 | Screw |
| 49 | 123106037/0 | Yellow Cylinder Cover |
| 50 | 112735654/0 | Screw |
| 51 | 123106039/0 | Yellow Cylinder Cover |
| 52 | 183065030/0 | Spark Plug Cable |
| 53 | 118801447/0 | Throttle Cable |
| Hedgecutter HTJ 550/252900000-14-2016 Blade Pag.3 | ||
| 1 | 123050010/0 | Clutch Drum Assy |
| 2 | 123657013/0 | Washer |
| 3 | 123657017/0 | Washer |
| 4 | 123878115/0 | Screw |
| 5 | 123685022/0 | Upper Case |
| 6 | 123657018/0 | Washer |
| 7 | 123657021/0 | Washer |
| 8 | 123878116/0 | Screw |
| 9 | 123280082/0 | Crankcase Gasket |
| 10 | 123208418/0 | Flange - DISCONTINUED |
| 11 | 112379520/0 | Grease Dispenser |
| 12 | 114215222/0 | Ball Bearing |
| 13 | 123878117/0 | Screw |
| 14 | 112610003/0 | Snap Ring |
| 15 | 123570052/0 | Pinion |
| 16 | 114215223/0 | Bearing |
| 17 | 123664000/0 | Gear Assy |
| 18 | 123041502/0 | Connecting Rod |
| 19 | 123753003/0 | Pin |
| 21 | 123685023/0 | Lower Case NEW CODE 118804982/0 ( GEAR BOX ASSY' ) |
| 22 | 123878081/0 | Screw |
| 23 | 123280083/0 | Gasket |
| 24 | 123878118/0 | Screw |
| 25 | 123208419/0 | Plate |
| 26 | 123878113/0 | Screw |
| 27 | 123294006/0 | Blade Holder |
| 28 | 123044222/0 | Bushing |
| 29 | 123305004/0 | Blade |
| 30 | 123120014/0 | Nut |
| 31 | 123600081/0 | Blade Guard |
| 32 | 123294007/0 | Blade Holder |
| 33 | 123208420/0 | Bracket |
| 34 | 123085002/0 | Blade Cover |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Alpina websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Alpina brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Alpina HTJ550 - 252900000
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10/15 BUSINESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N ALPINA:
- STIGA GROUP S/N START WITH (1 or 2) and have 9 DIGITS
