Castelgarden Spare Parts for Brushcutter XB 29
€1.41
Tax included
Castelgarden Spare Parts for Brushcutter XB 29
Castelgarden genuine spare parts or replacement parts for to repair Engine Brush Cutter XB 29/283720003/08-2010.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Castelgarden Spare Parts for Brushcutter XB 29
Castelgarden genuine spare parts or replacement parts for to repair Engine Brush Cutter XB 29/283720003/08-2010.
In the following table, look for the model of the Brushcutter and the respective parts of the code.
| Engine Brush Cutter XB 29/283720003/08-2010 | ||
| Engine Pag.1 | ||
| # | Part Num. | Description |
| 1 | 123071010/0 | Cylinder |
| 2 | 123280030/0 | Cylinder gasket |
| 4 | 123109539/0 | Cover |
| 5 | 123109540/0 | Cover |
| 6 | 123280032/0 | Gasket |
| 7 | 123878054/0 | Screw |
| 9 | 123106024/0 | Red Cylinder Cap |
| 10 | 123590004/0 | Piston |
| 11 | 123760001/0 | Piston pin |
| 12 | 123204007/0 | Piston ring |
| 13 | 123202002/0 | Circlip |
| 14 | 123235003/0 | Neddle Bearing |
| 15 | 114215215/0 | Ball bearing |
| 21 | 123880005/0 | Flywheel |
| 22 | 123044008/0 | Electronic Coil |
| 23 | 123053002/0 | Spark cap |
| 24 | 3210024 | Spark plug |
| 25 | 183065021/0 | Earth Cable |
| 26 | 123280033/0 | Carburetor Manifold Gasket |
| 27 | 123054022/0 | Carburetor |
| 28 | 123220009/0 | Air filter |
| 29 | 183090005/0 | Air filter cover |
| 30 | 123280028/0 | Muffler gasket |
| 31 | 183740006/0 | Muffler |
| 32 | 183215005/0 | Clutch Assy |
| 33 | 183058034/0 | Starter Assy |
| 34 | 123300007/0 | Starter handle |
| 35 | 123082002/0 | Goodwill Cup Ass |
| 36 | 183733005/0 | Tank Assy |
| 37 | 183790008/0 | Fuel Cap |
| 38 | 183520004/0 | Intake Filter |
| 39 | 123878061/0 | Screw |
| 40 | 323109571/0 | Red Spark Guard |
| 51 | 123685005/0 | Engine Cover, Clutch Side |
| 52 | 123685004/0 | Engine Cover, Starter Side |
| 53 | 119035160/0 | Sealing ring |
| 56 | 123208410/0 | Transm.Support Case |
| 59 | 123020026/0 | Crankshaft |
| 60 | 123120005/0 | Nut |
| 61 | 123280052/0 | Cylinder Manifold Gasket |
| 62 | 123073513/0 | Intake manifold |
| 63 | 123040002/0 | Air Filter Base |
| 64 | 123430586/0 | Spring |
| 65 | 123878059/0 | Screw |
| 68 | 123604008/0 | Starter Pulley |
| 69 | 123430589/0 | Spring |
| 71 | 123275022/0 | Grommet Ass.Y |
| 72 | 123784005/0 | Protection |
| 73 | 123753002/0 | Plug |
| 74 | 123878066/0 | Screw |
| 75 | 123878064/0 | Screw |
| 76 | 123878065/0 | Screw |
| 77 | 123657010/0 | Washer |
| 78 | 123878063/0 | Lives |
| 81 | 123109559/0 | Guard |
| Handle-Trasmission Pag.2 | ||
| 1 | 3L8562620/1 | Rear Handle Assy |
| 2 | 2123030 | Screw |
| 3 | 2123100 | Screw |
| 4 | 3743475 | Safety Lever |
| 5 | 3654300 | Spring |
| 6 | 3743465 | Throttle lever |
| 7 | 1L3654270/1 | Spring |
| 8 | 3612710 | Stop plate |
| 9 | 2123070 | Screw |
| 10 | 3749270 | Knob |
| 11 | 3749910 | Reduction |
| 12 | 4252540 | Throttle Cable |
| 13 | 3786030 | Wire sheath |
| 14 | 123065022/0 | Wire |
| 15 | 123065023/0 | Earth Cable |
| 16 | 8563590 | Front Handle Assy |
| 17 | 2135050 | Screw |
| 18 | 2312090 | Washer |
| 19 | 2412030 | Nut |
| 20 | 8251211 | Transmission Pipe Ass |
| 21 | 4251410 | Transmission shaft ass |
| 22 | 3642221 | Bearing Hub |
| 23 | 3L4121881/1 | Drum Clutch Assy |
| 24 | 8561600 | Support Transmission Assy |
| 25 | 3353080 | Seeger ring |
| 26 | 3112170 | Ball bearing |
| 27 | 2123140 | Screw |
| 28 | 2123150 | Screw |
| 29 | 2135160 | Screw |
| 30 | 323170000/0 | Spacer |
| 32 | 2312150 | Washer |
| 33 | 2135060 | Screw |
| 34 | 2135030 | Screw |
| 35 | 3615000 | Line Cutter |
| 36 | 112154330/0 | Nut |
| 37 | 2312150 | Washer |
| 38 | 3L8563570/1 | Safety Cover Assy |
| 39 | 4253460 | Harness |
| Gear Case Pag.3 | ||
| 1 | 3L4252770/2 | Head Ø24Mm |
| 7 | 2135050 | Screw |
| 8 | 2653090 | Screw |
| 9 | 2653460 | Screw |
| 15 | 3121180 | Sealing ring |
| 16 | 3660680 | Collar |
| 17 | 3641650 | Upper flange |
| 18 | 3612650 | Lower flange |
| 19 | 4560610 | Stabilizer |
| 23 | 6031172 | Disc 3 Tips |
| 31 | 4353240/1 | 2 Wire Head |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Castelgarden websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Castelgarden brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
XB 29/283720003/08-2010
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10/15 BUSINESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N ALPINA:
- STIGA GROUP S/N START WITH (1 or 2) and have 9 DIGITS
