Annovi & Reverberi Parts for Pressure Washer AR1001
€19.96
Tax included
Annovi Reverberi Parts for Pressure Washer AR1001
Annovi Reverberi Original spare parts for to make maintenance, replacement of damaged parts or repair electrical or mechanical components of the Pressure Washer Blue Clean AR1001 - 24384.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Annovi & Reverberi Parts for Pressure Washer AR1001
Annovi & Reverberi Original spare parts for to make maintenance, replacement of damaged parts or repair electrical or mechanical components of the Pressure Washer Blue Clean AR1001 - 24384.
In the following tables, look for the spare part and its respective code.
| Pressure Washer AR Blue Clean AR1001 - 24384 Pag.1 |
||
| Casing 1001 | ||
| # | Part Num. | Description |
| 1 | 3600140 | Wheel |
| 2 | 3600180 | Washer |
| 3 | 3600010 | Protection |
| 4 | 3600020 | Protection |
| 5 | 2000110 | Screw |
| 6 | 3600040 | Protection |
| 7 | 3600190 | Antivibration |
| 8 | 3600121 | Frame |
| 9 | 320350 | Screw |
| 10 | 3600200 | Protection |
| 11 | 2060200 | Screw |
| 12 | 2100300 | Screw |
| 13 | 3600321 | Protection |
| 14 | 2500330 | Pipe Cleaner |
| 15 | 2360360 | Screw |
| 16 | 3082130 | Kit For Water |
| 17 | 50019 | Knob |
| 18 | 50037 | Screw |
| 19 | 1060120 | Nut |
| 20 | 2021780 | Screw |
| 21 | 3600031 | Protection |
| 22 | 3600281 | Sump |
| 23 | 3600330 | Screw |
| 24 | 1270960 | Pipe Cleaner |
| 25 | 42113 | Pre-Assembly Cap |
| 26 | 3600250 | Tank |
| 27 | 2000230 | Filter |
| 28 | 3600070 | Holds Accessories |
| 29 | 2060200 | Screw |
| 30 | 3600060 | Holds Accessories |
| 31 | 2100300 | Screw |
| 32 | 3580090 | Knob |
| 33 | 3600130 | Frame |
| 34 | 3580180 | Knob |
| 35 | 3600050 | Holds Accessories |
| 36 | 2360760 | Knob |
| Pump 1001 Pag.2 |
||
| 1 | 2900120 | Junction |
| 2 | 740290 | O-Ring |
| 3 | 2901060 | Injector |
| 4 | 800560 | O-Ring |
| 5 | 1080091 | Spring |
| 6 | 2901070 | Shutter |
| 7 | 1460430 | O-Ring |
| 8 | 1344850 | Head |
| 9 | 1349055 | Valve |
| 10 | 1344770 | Spacer |
| 11 | 1465720 | O-Ring |
| 12 | 1344800 | Stopper |
| 13 | 1344790 | Fork |
| 14 | 850850 | Screw |
| 15 | 42579 | Valve Kit Adjustment |
| 16 | 1349203 | Pre-Assembly Head |
| 17 | 1342701 | Office |
| 18 | 600180 | O-Ring |
| 19 | 1460151 | Piston |
| 20 | 2021900 | Piston |
| 21 | 1080190 | O-Ring |
| 22 | 600180 | O-Ring |
| 23 | 1080401 | Ring |
| 24 | 820510 | O-Ring |
| 25 | 740290 | O-Ring |
| 26 | 1344870 | Piston Guide |
| 27 | 1343450 | Disk |
| 28 | 1460190 | Spring |
| 29 | 1980220 | Disk |
| 30 | 2500550 | Cotter Pin |
| 31 | 1344881 | Insert |
| 32 | 1980740 | Stopper |
| 33 | 1060120 | Nut |
| 35 | 3233 | Manometer |
| 36 | 1344890 | Stopper |
| 37 | 2560870 | O-Ring |
| 38 | 2460180 | O-Ring |
| 39 | 770260 | O-Ring |
| 40 | 1344750 | Piston Guide |
| 41 | 1260440 | Tenuta Water |
| 42 | 1344760 | Ring |
| 43 | 1344050 | Pump Housing |
| 44 | 1260050 | Bushing |
| 45 | 1040710 | O-Ring |
| 46 | 1344060 | Cover |
| 47 | 1260780 | Screw |
| 48 | 1349281 | Pre-Assembly Pump |
| 49 | 1349000 | Stopper |
| 50 | 880111 | Tongue |
| 51 | 1341070 | Bearing |
| 52 | 480890 | Ring |
| 53 | 111120 | Ring |
| 54 | 1341080 | Ring |
| 55 | 1340060 | Piston Rod |
| 56 | 1340080 | Plug |
| 57 | 1340070 | Piston |
| 58 | 1260460 | Oil Seal |
| 59 | 600180 | O-Ring |
| 60 | 1341010 | Disk |
| 61 | 1342740 | Piston |
| 62 | 1341020 | Washer |
| 63 | 850670 | Screw |
| 64 | 1340170 | Tree |
| 65 | 1120680 | O-Ring |
| 66 | 600180 | O-Ring |
| 67 | 2022040 | Rod |
| 68 | 2021630 | Spring |
| 69 | 2021650 | Washer |
| 70 | 1260820 | O-Ring |
| 71 | 1344830 | Junction |
| 72 | 42580 | Retrofit Kit TSS |
| 73 | 1560520 | Spring |
| 74 | 1250280 | Sphere |
| 75 | 480480 | O-Ring |
| 76 | 1982520 | Hose |
| A | 42566 | Kit Valves |
| B | 2623 | Piston Kit |
| C | 1876 | Kit Oil Seals |
| D | 42567 | Kit Kept Water |
| F | 42568 | Gasket Kit |
| Engine 1001 Pag.3 |
||
| 1 | 1342040 | Fan Cover |
| 2 | 1260300 | Fan |
| 3 | 1340350 | Seal |
| 4 | 1260760 | Screw |
| 5 | 1340320 | Shield |
| 6 | 1340340 | Bearing |
| 7 | 1269100 | Clamp |
| 8 | 1340780 | Gasket |
| 9 | 1682270 | Switch |
| 10 | 2102600 | Headphones |
| 11 | 1342261 | Box |
| 12 | 1760450 | Cable |
| 13 | 1263520 | Condenser |
| 14 | 1342080 | Band |
| 15 | 2029752 | Pre-Assembly Box TSS |
| 16 | 2022201 | Fork |
| 17 | 44480 | Engine |
| Accessories 1001 Pag.4 |
||
| 1 | 40925 | Gun |
| 2 | 3600650 | Lance |
| 3 | 3600440 | Nozzle (0 °) |
| 4 | 3600450 | Nozzle (15 °) |
| 5 | 3600460 | Nozzle (25 °) |
| 6 | 3600470 | Nozzle (40 °) |
| 7 | 3600400 | Nozzle (Low Pressure) |
| 8 | 3600620 | High Pressure Hose |
| 9 | 2000770 | O-Ring |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Annovi & Reverberi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Annovi & Reverberi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
