Annovi & Reverberi Parts for Pressure Washer AR1005
Genuine Parts Annovi & Reverberi for to repair damaged parts for Pressure Washer Blue Clean AR1005 - 24386.
In the following tables, look for the spare part and its respective code.
| Pressure Washer Blue Clean AR1005 - 24386 | ||
| Pressure Washer 1005 Casing | ||
| # | Part Num. | Description |
| 1 | 3600140 | Wheel |
| 2 | 3600180 | Washer |
| 3 | 3600010 | Protection |
| 4 | 3600020 | Protection |
| 5 | 2000110 | Screw |
| 6 | 3600040 | Protection |
| 7 | 3600190 | Antivibration |
| 8 | 3600121 | Frame |
| 9 | 380240 | Nut |
| 10 | 3600200 | Protection |
| 11 | 2060200 | Screw |
| 12 | 2100300 | Screw |
| 13 | 3600321 | Protection |
| 14 | 2500330 | Pipe Cleaner |
| 15 | 2360340 | Colonnetta |
| 16 | 3082130 | Kit For Water |
| 17 | 50019 | Knob |
| 18 | 50037 | Screw |
| 19 | 1060120 | Nut |
| 20 | 2021780 | Screw |
| 21 | 3600031 | Protection |
| 22 | 3600291 | Sump |
| 23 | 850250 | Screw |
| 24 | 3600410 | Pipe Cleaner |
| 25 | 42113 | Pre-Assembly Cap |
| 26 | 3600250 | Tank |
| 27 | 2000230 | Filter |
| 28 | 3600070 | Holds Accessories |
| 29 | 2360360 | Screw |
| 30 | 2060200 | Screw |
| 31 | 3600060 | Holds Accessories |
| 32 | 2100300 | Screw |
| 33 | 3580090 | Knob |
| 34 | 3600130 | Frame |
| 35 | 3580180 | Knob |
| 36 | 3600050 | Holds Accessories |
| Pump 1005 | ||
| 1 | 3200110 | Stopper |
| 2 | 1200690 | O-Ring |
| 3 | 2769050 | Complete Valve |
| 4 | 800410 | Screw |
| 5 | 1381550 | Washer |
| 6 | 3200020 | Head |
| 7 | 180101 | O-Ring |
| 8 | 820361 | Stopper |
| 9 | 51219 | Pressure Switch |
| 10 | 3160510 | Junction |
| 11 | 1780140 | Ring |
| 12 | 1780720 | Tenuta Water |
| 13 | 3200130 | Piston Guide |
| 14 | 3200142 | Gasket |
| 15 | 3200260 | Ring |
| 16 | 770590 | O-Ring |
| 17 | 3200120 | Piston Guide |
| 18 | 3200010 | Pump Housing |
| 19 | 1780490 | Bearing |
| 20 | 1260790 | Ring |
| 21 | 1780550 | Ring |
| 22 | 395081 | O-Ring |
| 23 | 3200090 | Disk |
| 24 | 3200080 | Level Indicator |
| 25 | 3200070 | Support |
| 26 | 1200430 | Screw |
| 27 | 880130 | Stopper |
| 28 | 1260110 | Nut |
| 29 | 1260100 | Washer |
| 30 | 1260210 | Piston |
| 31 | 1260091 | Disk |
| 32 | 1260460 | Oil Seal |
| 33 | 480480 | O-Ring |
| 34 | 3200060 | Piston |
| 35 | 3200040 | Piston Rod |
| 36 | 1780050 | Plug |
| 37 | 2760280 | O-Ring |
| 38 | 3200030 | Cover |
| 39 | 820510 | O-Ring |
| 40 | 880581 | Stopper |
| 41 | 3200220 | Screw |
| 42 | 3200270 | Tree |
| 43 | 3200230 | Tongue |
| 44 | 1321190 | Bearing |
| 45 | 1260750 | Ring |
| 46 | 3209200 | Pre-Assembly Head |
| 47 | 23081 | Pre-Assembly Pump |
| 48 | 3200430 | Stopper |
| 49 | 3232 | Manometer |
| 50 | 1123960 | Junction |
| A | 2186 | Kit Valves |
| B | 42467 | Piston Kit |
| C | 42468 | Kit Oil Seals |
| E | 42469 | Kit Kept Water |
| F | 42470 | Gasket Kit |
| G | 2745 | Kit Support Rings |
| Valve 1005 | ||
| 1 | 1560580 | stopper |
| 2 | 540290 | screw |
| 3 | 1660210 | nut |
| 4 | 1560400 | knob |
| 5 | 1560420 | screw |
| 6 | 1080070 | plug |
| 7 | 2260330 | driving |
| 8 | 2260140 | disk |
| 9 | 1560350 | spring |
| 10 | 2260340 | disk |
| 11 | 2260060 | piston |
| 12 | 2260100 | O-ring |
| 13 | 2260040 | piston guide |
| 14 | 740290 | O-ring |
| 15 | 394280 | O-ring |
| 16 | 2260450 | shutter |
| 17 | 2260190 | O-ring |
| 18 | 2260080 | office |
| 19 | 1260740 | O-ring |
| 20 | 390080 | O-ring |
| 21 | 1540272 | screw |
| 22 | 1560150 | O-ring |
| 23 | 1560100 | shutter |
| 24 | 1560140 | spring |
| 25 | 180101 | O-ring |
| 26 | 24246 | Valve |
| 27 | 2260170 | Valve Body |
| 28 | 390080 | O-Ring |
| 29 | 1540471 | Collector |
| 30 | 880270 | O-Ring |
| 31 | 2260420 | Screw |
| 32 | 480440 | O-Ring |
| 33 | 1560900 | Junction |
| 34 | 1540630 | O-Ring |
| 35 | 1560510 | Nut |
| 36 | 1560500 | Junction |
| 37 | 1560520 | Spring |
| 38 | 1250280 | Sphere |
| 39 | 480480 | O-Ring |
| 40 | 1560490 | Hose |
| F | 42598 | Gasket Kit |
| Engine 1005 | ||
| 1 | 1381980 | Headphones |
| 2 | 1682270 | Switch |
| 3 | 1261570 | Screw |
| 4 | 1261560 | Screw |
| 5 | 1080190 | O-Ring |
| 6 | 1760640 | Cable |
| 7 | 1382380 | Gland |
| 8 | 1701070 | Box |
| 9 | 1700590 | Nut |
| 10 | 880270 | O-Ring |
| 11 | 2021480 | Fairlead |
| 12 | 1269100 | Clamp |
| 13 | 1940410 | O-Ring |
| 14 | 1470130 | Screw |
| 15 | 1700080 | Plate |
| 16 | 50068 | Gasket |
| 17 | 44511 | Engine |
| 18 | 1700740 | Mini-Contactor |
| 19 | 1381940 | Frame |
| 20 | 1261551 | Screw |
| Accessories 1005 | ||
| 1 | 41046 | Gun |
| 2 | 3600650 | Lance |
| 3 | 3600480 | Nozzle (0°) |
| 4 | 3600490 | Nozzle (15°) |
| 5 | 3600500 | Nozzle (25°) |
| 6 | 3600510 | Nozzle (40°) |
| 7 | 3600400 | Nozzle (Low Pressure) |
| 8 | 1271960 | High Pressure Hose |
| 9 | 2000770 | O-Ring |
