FIAC AB 500-858 TF 15BAR Spare Parts
€176.92
Tax included
FIAC AB 500-858 TF 15BAR Spare Parts
Genuine Parts FIAC for piston Air Compressors and spare parts for the repair or replacement of components of the Air Compressor AB 500/858 TF 15BAR Code: 1525600000.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
FIAC AB 500-858 TF 15BAR Spare Parts
Genuine Parts FIAC for piston Air Compressors and spare parts for the repair or replacement of components of the Air Compressor AB 500/858 TF 15BAR Code: 1525600000.
In the following table, look for the type of the air compressor and the respective parts of the code .
| AB 500/858 TF 15BAR Code: 1525600000 serial nr. 120814986 | ||
| # | Part Num. | Description |
| 1 | 3021110000 | Pump unit NEW VERSION |
| 2 | 4056140000 | Press. Switch kit |
| 2.1 | 7082690000 | Joint |
| 2.2 | 7090070000 | Plug |
| 2.3 | 7251290000 | Pressure switch |
| 2.4 | 7328690000 | |
| 2.5 | 7328700000 | Infeed cable |
| 3 | 4080520000 | Screw kit |
| 4 | 4151450000 | Motor/pulley kit - QUOTE ON DEMAND |
| 5 | 4170200000 | Belt guard kit |
| 6 | 5010460008 | Base |
| 7 | 5159660008 | Tank |
| 9 | 7085020000 | Joint |
| 10 | 7085030000 | Joint |
| 12 | 7085390000 | Joint |
| 13 | 7090050000 | Plug |
| 15 | 7110150000 | Pressure gauge |
| 16 | 7130460000 | Tap |
| 17 | 7130160000 | Discharge tap |
| 18 | 7190150000 | Non return valve |
| 19 | 7192330000 | Safety valve |
| 20 | 7230010000 | Rilsan hose |
| 21 | 7231210000 | Rubber hose |
| 22 | 7370680000 | Belt |
| 23 | 7458990000 | Belt guard Support |
| Pump Unit AB 808 | ||
| # | Part Num. | Description |
| 1 | 5071020008 | Crankcase |
| 2 | 7650080000 | Front cover |
| 3 | 7060150000 | Bearing |
| 4 | 5041490008 | Crankshaft - DISCONTINUED |
| 5 | 7060060000 | Bearing |
| 6 | 7650070000 | Rear cover |
| 7 | 7090090000 | Plug |
| 8 | 7180060000 | Oil level gauge |
| 9 | 7051520000 | Key |
| 10 | 7575460000 | Cylinder |
| 11 | 4231230000 | Valve Plate |
| 11.1 | x | Plate |
| 11.2 | x | Valve |
| 11.3 | x | Valve |
| 11.4 | x | gasket |
| 12 | 5030610008 | Head |
| 13 | 4086830000 | Breather pipe plug kit |
| 14 | 7232220000 | Intermediate Aftercooler |
| 15 | 5130110008 | Aftercooler |
| 16 | 7043050000 | Stirrup |
| 17 | 7192350000 | Safety Valve |
| 18 | 7081190000 | Joint |
| 19 | 7201240000 | Flywheel |
| 20 | 7650090000 | Lower cover |
| 21 | 4082280000 | Gasket kit |
| 21.1 | x | Gasket |
| 21.2 | x | Gasket |
| 21.3 | x | Gasket |
| 21.4 | x | Gasket |
| 21.5 | x | Oil seal |
| 21.6 | x | Gasket |
| 21.7 | x | Gasket |
| 22 | 4080920000 | Screw kit |
| 22.1 | x | Screw |
| 22.2 | x | Screw |
| 22.3 | x | Screw |
| 22.4 | x | Washer |
| 22.5 | x | Screw |
| 22.6 | x | Washer |
| 22.7 | x | Screw |
| 22.8 | x | Screw |
| 22.9 | x | Screw |
| 23 | 4080290000 | Intake filter kit |
| 23.1 | x | Filter cover |
| 23.2 | x | Filter base |
| 23.3 | 7210690000 | Filtering element |
| 23.4 | x | Screw |
| 24 | 4080850000 | LP Conn.rod/Piston Kit biella/pistone BP |
| 24.1 | 4080840000 | Low pression ring ki Kit fasce bassa pressione |
| 24.2 | 7220340000 | Piston |
| 24.3 | 7050270000 | Piston pin |
| 24.4 | x | Internal snapring |
| 24.5 | 5050580008 | Con rod |
| 25 | 4080860000 | HP conn.rod/piston Kit biella/pistone AP |
| 25.1 | 4080080000 | High pressure ring k Kit fasce alta pressione |
| 25.2 | 7220120000 | Piston |
| 25.3 | 5050580008 | Con rod |
| 25.4 | 7050130000 | Piston pin |
| 25.5 | x | Internal snapring |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Fiac websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Fiac brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
AB500/858 TF 15 BAR
6 Items
