AR Farmer's Division Parts for Pressure Washer BLITZ 8.13 - 8740
€30.06
Tax included
AR Farmer's Division Parts for Pressure Washer BLITZ 8.13 - 8740
AR Farmer's Division Original spare parts at the most competitive prices on the web, we are a service center with repair service able to advise you to purchase the most suitable spare part to quickly resolve any maintenance or repair issues for Pressure Washer BLITZ 8.13 - 8740.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
AR Farmer's Division Parts for Pressure Washer BLITZ 8.13 - 8740
AR Farmer's Division Original spare parts at the most competitive prices on the web, we are a service center with repair service able to advise you to purchase the most suitable spare part to quickly resolve any maintenance or repair issues for Pressure Washer BLITZ 8.13 - 8740.
In the following tables, look for the spare part and its respective code.
| AR Farmer's Division Pressure Washer BLITZ 8.13 - 8740 | ||
| Casing 8.13 - 8740 Pag.1 | ||
| # | Part Num. | Description |
| 1 | 1260270 | Casing Yellow |
| 2 | 1261551 | Screw |
| 3 | 180030 | Screw |
| 4 | 1260710 | Handle |
| 5 | 1260311 | Fan Cover |
| 6 | 1269110 | Tank |
| 7 | 1261040 | Casing Yellow |
| 8 | 1260470 | Screw |
| 9 | 1260830 | Foot |
| 10 | 1260290 | Bonnet Yellow |
| 11 | 1260780 | Screw |
| Pump 8.13 - 8740 Pag.2 |
||
| 1 | 1260760 | Screw |
| 2 | 1269101 | Cover |
| 3 | 1260040 | Oil Seal |
| 4 | 1260480 | Stopper |
| 5 | 1260010 | Body Pump |
| 6 | 1269121 | Pre-Assembly Head |
| 7 | 1260050 | Bush |
| 8 | 1260170 | Shaft |
| 9 | 1320370 | Bearing |
| 10 | 1260770 | Ring |
| 11 | 1260790 | Ring |
| 12 | 1260750 | Ring |
| 13 | 1380520 | Tongue |
| 14 | 1260080 | Plug |
| 15 | 1260070 | Piston |
| 16 | 1260091 | Disk |
| 17 | 480480 | O-Ring |
| 18 | 1260120 | Piston |
| 19 | 1260100 | Washer |
| 20 | 1260110 | Nut |
| 21 | 1260060 | Piston Rod |
| 22 | 1260162 | Stopper |
| 23 | 960160 | O-Ring |
| 24 | 1269050 | Valve Complete |
| 25 | 880830 | O-Ring |
| 26 | 1272820 | Head |
| 27 | 1260420 | O-Ring |
| 28 | 1260440 | Water Seal |
| 29 | 1260460 | Oil Seal |
| 30 | 1381550 | Washer |
| 31 | 680570 | Screw |
| 32 | 180101 | O-Ring |
| 33 | 820361 | Stopper |
| 34 | 1980740 | Stopper |
| 35 | 740290 | O-Ring |
| 36 | 1260141 | Ring |
| 37 | 1271650 | Water Seal |
| 38 | 1260151 | Piston Guide |
| A | 1864 | Valve Kit |
| B | 2628 | Piston Kit |
| C | 1865 | Oil Seals Kit |
| E | 1866 | Kit Held Water |
| F | 2040 | Seal Kit |
| Valve 8.13 - 8740 Pag.3 |
||
| 1 | 1981780 | Knob |
| 2 | 1980470 | Screw |
| 3 | 1980300 | Nut |
| 4 | 1980390 | Insert |
| 5 | 1980220 | Disk |
| 6 | 1271070 | Spring |
| 7 | 1080041 | Piston |
| 8 | 1080401 | Ring |
| 9 | 1080250 | O-Ring |
| 10 | 1080070 | Plug |
| 11 | 1980210 | Piston Guide |
| 12 | 880830 | O-Ring |
| 13 | 740290 | O-Ring |
| 14 | 800560 | O-Ring |
| 15 | 1080190 | O-Ring |
| 16 | 1271160 | Piston |
| 17 | 1080121 | Venue |
| 18 | 1260570 | Washer |
| 19 | 390080 | O-Ring |
| 20 | 1540272 | Screw |
| 21 | 1270790 | License Plate |
| 22 | 395370 | Washer |
| 23 | 395270 | Screw |
| 24 | 1260530 | Cover |
| 25 | 1260520 | Index |
| 26 | 1270080 | Valve Body |
| 27 | 770140 | O-Ring |
| 28 | 1180140 | O-Ring |
| 29 | 1260540 | Suction Fitting |
| 30 | 1260560 | Washer |
| 31 | 880270 | O-Ring |
| 32 | 2260420 | Screw |
| 33 | 2980 | Valve Complete |
| 34 | 1260660 | Filter |
| 35 | 1270940 | Junction |
| 36 | 1279211 | Pre-Assembly Combiset |
| 37 | 1271170 | Ring |
| 38 | 480480 | O-Ring |
| 39 | 1260670 | Junction |
| 40 | 720030 | O-Ring |
| 41 | 1262940 | Bush |
| 42 | 1250270 | Spring |
| 43 | 1250280 | Sphere |
| 44 | 880840 | O-Ring |
| 45 | 1264090 | Spring |
| 46 | 1269041 | Injector |
| 47 | 1264080 | Stopper |
| 48 | 1269010 | Knob |
| 49 | 1981770 | Stopper |
| 50 | 1264060 | Piston |
| 51 | 1460430 | O-Ring |
| 52 | 1540170 | Shutter |
| 53 | 1080091 | Spring |
| 54 | 394280 | O-Ring |
| 55 | 1200690 | O-Ring |
| 56 | 1270091 | Injector |
| 57 | 1260820 | O-Ring |
| 58 | 1264070 | Ring |
| F | 2715 | Seal Kit |
| Motor 8.13 - 8740 Pag.4 |
||
| 1 | 1260300 | Fan |
| 2 | 1260970 | Sealing |
| 3 | 1260360 | Standoff |
| 4 | 1260960 | Shield |
| 5 | 1260950 | Bearing |
| 6 | 1269100 | Clamp |
| 7 | 1260400 | Gasket |
| 8 | 1261560 | Screw |
| 9 | 1260340 | Box |
| 10 | 4585 | Engine |
| 11 | 1263790 | Switch |
| 12 | 1271950 | Cable Clamp |
| 13 | 1269090 | Cable Clamp |
| 14 | 1266810 | Capacitor |
| 15 | 1340280 | Band |
| 16 | 1271880 | Screw |
| 17 | 1262370 | Deck Fill |
| 18 | 1270950 | Cable |
| Accessories 8.13 - 8740 Pag.5 |
||
| 1 | 40925 | Gun |
| 2 | 40112 | Lance + Nozle |
| 3 | 1262443 | High Pressure Tube |
| 4 | 2000770 | O-Ring |
For old model we suggest to change gun and lance
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Annovi & Reverberi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Annovi & Reverberi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
ARSG BLITZ 8.13 - 8740
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10/15 BUSINESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N AR:
- AR S/N START WITH ( 1 or 2 ) and have 5 DIGITS
