Annovi & Reverberi Parts for Pressure Washer AR 440
€23.24
Tax included
Annovi Reverberi Parts for Pressure Washer AR 440
We have the original Annovi Reverberi Parts for Pressure Washer AR 440, the diagram and parts list and tool repair that help you need to get your tools running like new again.Fix Your Pressure Washer AR 440 - 12471. All Spares are original and can be supplied at Low and discounted prices. Our Parts are Genuine and with a Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Annovi Reverberi Parts for Pressure Washer AR 440
Fix Your Pressure Washer AR 440 - 12471. All Spares are original and can be supplied at Low and discounted prices. Our Parts are Genuine and with a Guarantee.
In the following tables, look for the spare part and its respective code.
| Pressure Washer AR 440 - 12471 Spare Parts |
||
| Casing Pag.1 | ||
| # | Part Num. | Description |
| 1 | 3020020 | Blue casing |
| 2 | 2900620 | Knob |
| 3 | 3020110 | Door |
| 4 | 3020040 | Door |
| 5 | 2900900 | Ball |
| 6 | 2100300 | Screw |
| 7 | 2900870 | Tube clip |
| 8 | 3020060 | Door |
| 9 | 1700140 | Detergent hose |
| 10 | 3020130 | Fitting |
| 11 | 40008 | Tank |
| 12 | 1270960 | Detergent hose |
| 13 | 2600100 | Cable gland |
| 14 | 3020010 | Base |
| 15 | 2440075 | Wheel |
| 16 | 3020070 | Plate |
| 17 | 2900500 | Screw |
| 18 | 2180330 | Rubber foot |
| 19 | 3020090 | Hub pin |
| 20 | 3020030 | Handle |
| 21 | 2100300 | Screw |
| 22 | 2900680 | Knob |
| 23 | 2900670 | Plate |
| 24 | 380420 | Ring |
| 25 | 2900660 | Hose reel rotor |
| 26 | 3020120 | Spring |
| Pump Pag.2 |
||
| 1 | 1340260 | Filter |
| 2 | 2100630 | Fitting |
| 3 | 2101000 | Screw |
| 4 | 2101450 | Flange |
| 5 | 2122 | O-ring + head |
| 6 | 550350 | O-ring |
| 7 | 850850 | Screw |
| 8 | 2109050 | Valve |
| 9 | 2200141 | Water seal |
| 10 | 2020041 | Ring |
| 11 | 1683500 | Oil seal |
| 12 | 2100030 | Piston guide |
| 13 | 2561120 | Spring |
| 14 | 2100130 | Piston |
| 15 | 2020140 | Ring |
| 16 | 850840 | O-ring |
| 17 | 2021570 | Bearing |
| 18 | 2560480 | Bushing |
| 19 | 394280 | O-ring |
| 20 | 880840 | O-ring |
| 21 | 1260760 | Screw |
| 22 | 1560520 | Spring |
| 23 | 1250280 | Ball |
| 24 | 480480 | O-ring |
| 25 | 1560490 | Hose tail |
| 26 | 1020230 | O-ring |
| 27 | 2900880 | Fitting |
| 28 | 1260740 | O-ring |
| 29 | 2900800 | Hub pin |
| 30 | 2900890 | Ring nut |
| 31 | 2900830 | Fitting |
| 32 | 2909010 | Fitting assembly |
| 33 | 1461470 | Fitting |
| 34 | 42337 | Fitting assembly |
| 35 | 42336 | TSS pump assembly |
| 36 | 2021960 | Fork |
| 37 | 2029721 | TSS box assembly |
| A | 2574 | Valve kit |
| B | 2508 | Piston kit |
| D | 2575 | Seal kit |
| Motor Pag.3 |
||
| 3 | 2102180 | Wobble plate |
| 4 | 2109270 | Pump body assembly |
| 5 | 2100980 | Screw |
| 6 | 2440160 | Plate |
| 7 | 2100110 | Gland |
| 8 | 1343400 | Cable |
| 9 | 1340350 | Seal |
| 10 | 2020850 | Washer |
| 11 | 1680250 | Fan |
| 12 | 2020570 | Screw |
| 13 | 1262400 | Washer |
| 14 | 3020050 | Box |
| 15 | 2900770 | Box |
| 16 | 2900420 | Switch |
| 17 | 2000210 | Screw |
| 18 | 2900780 | Cover |
| 19 | 1680670 | Capacitor |
| 20 | 390201 | O-ring |
| 21 | 44174 | Motor |
| Accessories Pag.4 |
||
| 1 | 40755 | Lance head |
| 2 | 1680220 | O-ring |
| 3 | 40344 | Rotopower head |
| 4 | 40487 | Lance |
| 5 | 40417 | Fixed brush |
| 6 | 40350 | Gun |
| 7 | 600180 | O-ring |
| 8 | 3020140 | High pressure hose |
| 9 | 2000770 | O-ring |
| 10 | 880840 | O-ring |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Annovi & Reverberi websites, which we consider as reliable.Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Annovi & Reverberi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Annovi Reverberi 440 - 12471
9 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10/15 BUSINESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N AR:
- AR S/N START WITH ( 1 or 2 ) and have 5 DIGITS
