Annovi & Reverberi Parts for Pressure Washer AR1015

€11.93
Tax included

Annovi & Reverberi Parts for Pressure Washer AR1015

Annovi & Reverberi repair center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Pressure Washer Blue Clean AR1015 - 23659.

Pressure Washer Blue Clean AR1015 - 23659
ITEM CODE: 1829
Quantity
Usually Ships in: 10/15 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Annovi & Reverberi Parts for Pressure Washer AR1015

Annovi & Reverberi repair center

 and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Pressure Washer Blue Clean AR1015 - 23659.

In the following tables, look for the spare part and its respective code.
Pressure Washer Blue Clean AR1015 - 23659

Pressure Washer AR Blue Clean 1015 - 23659
Casing 1015 Pag.1
# Part Num. Description
1 50601 Gasket
2 51387 Hood
3 1262790 Pipe Cleaner
4 1341030 Filter
5 50531 Junction
6 1123960 Junction
7 51219 Pressure Switch
8 50641 Frame
9 50447 Spring
10 50627 Wheel
11 50628 Protection
12 3260170 Junction
Pump 1015 Pag.2
1 960090 Stopper
2 960160 O-Ring
3 1389051 Complete Valve
4 880830 O-Ring
5 880581 Stopper
6 820510 O-Ring
7 820150 Screw
8 1381850 Washer
9 1381071 Head
10 180101 O-Ring
11 820361 Stopper
12 1980740 Stopper
13 740290 O-Ring
15 1381580 Manometer
16 960110 Ring
17 1382740 Tenuta Water
18 1380090 Piston Guide
19 961240 O-Ring
20 880330 Tenuta Water
21 1383130 Ring
22 1382770 Pump Housing
23 1980740 Stopper
24 880130 Stopper
25 2280240 Bearing
26 640030 O-Ring
27 1380120 Thickness 0.10 Mm
27 1380130 Thickness 0.20 Mm
27 1380530 Thickness 0.25 Mm
27 1382810 Thickness 0.05 Mm
28 1380050 Support
29 850370 Screw
30 2280060 Tree
31 1380520 Tongue
32 840370 Bearing
33 180340 Ring
34 1380040 Support
35 962010 Nut
36 962000 Washer
37 1380940 Piston
38 1380950 Disk
39 600180 O-Ring
40 1080401 Ring
41 1380920 Piston
42 1380060 Plug
43 1383050 Piston Rod
44 1780510 O-Ring
45 1260430 Ring
46 1780690 Disk
47 1260250 Level Indicator
48 1140450 O-Ring
49 1789010 Cover
50 1343510 Screw
51 1389270 Pre-Assembly Head
52 20897 Pre-Assembly Pump
A 2864 Kit Valves
B 2757 Piston Kit
C 1855 Kit Oil Seals
E 1857 Water Seals Kit
G 1829 Kit Support Rings
Valve 1015 Pag.3
1 1560580 Stopper
2 540290 Screw
3 1660210 Nut
4 1560400 Knob
5 1080070 Plug
6 1560420 Screw
7 1560410 Driving
8 1560440 Disk
9 1560350 Spring
10 1080610 Disk
11 1080660 Plug
12 1080540 Piston
13 391000 O-Ring
14 1080640 Ring
15 1560150 O-Ring
16 1560100 Shutter
17 1560140 Spring
18 180101 O-Ring
19 1540272 Screw
21 1560010 Valve Body
22 1080550 Ring
23 480480 O-Ring
24 1560280 Washer
25 1560320 Piston
26 880270 O-Ring
27 1560051 Junction
28 390080 O-Ring
29 1560510 Nut
30 1560530 Junction
31 1560520 Spring
32 1250280 Sphere
33 480480 O-Ring
34 1560490 Hose
35 1540020 Collector
36 1540120 Washer
37 1540090 Junction
38 1560290 Washer
39 20082 Complete Valve
F 2611 Gasket Kit
Engine 1015 Pag.4
1 50068 Gasket
2 1700080 Plate
3 1940410 O-Ring
4 1700960 Mini-Contactor
5 1261570 Screw
6 2360590 Card
7 1460460 Screw
8 1700590 Nut
9 2021480 Fairlead
10 51219 Pressure Switch
11 1341140 Gasket
12 2360730 Switch
13 880270 O-Ring
14 1382380 Gland
15 1261560 Screw
16 1080190 O-Ring
17 1701070 Box
18 1700640 Cable
19 44496 Engine
Accessories 1015 Pag.5
1 41052 Gun
2 3160170 High Pressure Hose
3 40826 Lance
4 3086 Nozzle
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Annovi & Reverberi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Annovi & Reverberi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Annovi Reverberi 1015 - 23659
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10/15 BUSINESS DAYS APPROX.
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N AR:
AR S/N START WITH ( 1 or 2 ) and have 5 DIGITS
New

Download

Diagram Annovi AR1015

Diagram Annovi AR1015

Download (618.08KB)
