Makita Spare Parts for Jigsaw 4324

We have the original Makita Parts, the diagram and parts list and tool repair that help you need to get your tools running like new again.

Fix Your Jigsaw 4324. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
ITEM CODE: 682502-4
Quantity
on 7/10 Business Days Approx

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Makita Spare Parts for Jigsaw 4324

Fix Your Jigsaw 4324. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following table, look for the model of jackhammers and the respective parts of the code.
Makita 4324

4324 - SEGHETTO ALTERNATIVO 65MM
# Part Num. Description
2 682502-4 CORD GUARD 8-85 3707/N1923B 6408
3 645006-7 NOISE SUPPRESSOR 240V LS1013
4 651286-5 SWITCH SGEL206C-5 BO5041/711
6 216008-6 STEEL BALL 4 5008MB/JV101D
7 233151-6 COMPRESSION SPRING 4 4304T X 4305T
8 961011-9 E-RING JIS E-4 EA3201
9 272239-7 LEVER X 4324 4329
10 183051-9 HOUSING SET 4324
11 687063-9 STRAIN RELIEF UH4570/55/5580/6 4304T
12 265995-6 PT SCREW 4X18 UH4570/55/65/55 6408 / 6221DW
13 643552-4 BRUSH HOLDER CB-13-20 BO3710/1
14 191627-8 CARBON BRUSH CB-64 BO3710/11 (56.57)
15 620409-6 CONTROLLER
16 210025-8 BALL BEARING 627LLB 4324
17 515718-5 ARMATURE ASSY 4326
18 210005-4 BALL BEARING 608 DDW
19 152600-3 BEARING CASE COMPLETE 4324
20 344683-9 PUSH PLATE 4324
21 344614-8 BALANCE PLATE 4322
22 256254-9 PIN 3 4322
23 153260-4 GEAR COMPLETE 4324
24 313082-6 SLIDEr GUIDE 4322
25 213038-8 O RING 5 4322
26 257683-9 COLLAR SLEEVE 4322
27 344613-0 SLIDER 4322
28 232183-0 LEAF SPRING 4324
29 922107-1 CAP HD SCREW M4X8 4320/JV101D
30 313083-4 BLADE CRAMP 4323 4322
31 323748-0 SAFETY WIRE 4322
32 416476-5 DUST COVER 4322
33 313086-8 SLIDER SUPPORT 4324
34 423307-1 POLY URETANE SPONGE SEAL 4322
35 344686-3 SEAL PLATE 4324
36 266177-3 CAP HD SCREW M3X10/JV101D 6914DW
37 961002-0 RETAINING RING S6 M9502R
38 416703-0 DUST SEAL X 4324
39 633408-9 FIELD - STATOR 220 X 4322
41 152601-1 RETAINER COMPLETE 4324
42 256117-9 PIN X 4324
43 343540-8 CLAMP X 4320
44 163397-9 BASE 4322
45 344685-5 CLAMP PLATE X 4324
46 922128-3 HEX SOCKET BOLT M4X16 EH7500 4300BA
47 265995-6 PT SCREW 4X18 UH4570/55/65/55 6408 / 6221DW
48 266048-4 PT SCREW M 4 X 40 X 4334D
49 819063-3 MAKITA LABEL
51 241881-5 FAN 52 X 6408
1001 A-85628 JIG SAW BLADEB10 PACK/5PCS Clean cut wood blades for
fast fine cut in wood and plastics, especially suited to plywood.
1002 783201-2 HEX. WRENCH 3 4604D
5006 654091-9 NON INSULATED TERMINAL GD0801 BO5021
5008 345441-6 BASE PLATE 4329
5009 912107-9 COUNTERSUNK HEAD SCREW M4X8
