at the most competitive prices on the web, we are a service center with repair service able to advise you to purchase the most suitable spare part to quickly resolve any maintenance or repair issues for Dustless Cutter Dry Cutting Ø 180 mm 4157KB.
In the following table, look for the model of Dustless Cutter and the respective parts of the code.![]()
| Dustless Cutter Dry Cutting 4157KB | ||
| # | Part Num. | Description |
| 2 | 911546-0 | HEAD SCREW CILIND. M4x25 |
| 3 | 911273-9 | SCREW M5x50 X 2414NB |
| 4 | 181044-0 | CARBON BRUSHES CB-153 (CB-152.154) |
| 5 | 643650-4 | PLUG BRUSH |
| 6 | 152925-5 | HOUSING MOTOR X 4157KB |
| 7 | 651165-7 | SWITCH X 4157KB |
| 8 | 266020-6 | SCREW M4 X 12 |
| 9 | 682503-2 | SLEEVE PROTECTING_COVER X HM1500 |
| 11 | 687001-1 | CLAMP cable tie |
| 12 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 13 | 410201-6 | COVER HANDLE X 4157KB |
| 14 | 210005-4 | BALL BEARING 608DDW |
| 15 | 681625-5 | INSULATING WASHER HK1810 |
| 16 | 596068-7 | STATOR X 4157KB |
| 17 | 266046-8 | SCREW M5x50 HR2010 |
| 18 | 510040-5 | ARMATURE X 4157KB |
| 19 | 415603-1 | VANE X 4157KB |
| 21 | 213102-5 | DUST WASHER 12 |
| 22 | 211129-9 | BALL BEARING NSK 6201DD |
| 26 | 931402-8 | NUT M8 X LS1013 |
| 27 | 911106-8 | SCREW M4X8 |
| 28 | 341415-5 | PLATE BLOC.SR21 / 2300 |
| 30 | 267003-9 | FLAT WASHER 8 X 4157KB |
| 33 | 152926-3 | BOX ING. CPL X 4157KB |
| 35 | 212052-1 | BEARING 1010 FOR 8050 |
| 37 | 226532-1 | GEAR 39 X 4157KB |
| 38 | 257064-7 | RING 15 X SR2100 |
| 39 | 962153-2 | RETAINING RING R35 |
| 40 | 211228-7 | BALL BEARING 6202DD |
| 41 | 324256-4 | TREE X SR2100 |
| 43 | 317187-4 | BEARING BOX X 4157KB |
| 44 | 911126-2 | SCREW M4x16 |
| 45 | 213319-0 | SEAL OIL 20 X 4157KB |
| 46 | 344758-4 | RING X 4157KB |
| 53 | 224375-5 | FLANGE INTERNAL 40 X 4157KB |
| 54 | 224275-9 | FLANGE EST.40 SR21 / 23/26 |
| 55 | 266283-4 | SCREW M 8 X 20 X 4157KB |
| 56 | 911106-8 | SCREW M4X8 |
| 57 | 931402-8 | NUT M8 X LS1013 |
| 58 | 341415-5 | PLATE BLOC.SR21 / 2300 |
| 60 | 267003-9 | FLAT WASHER 8 X 4157KB |
| 61 | 251858-2 | BOLT M6x15 SR16 / 21/230 |
| 62 | 317160-4 | GUIDE XTILT 4157KB |
| 63 | 252103-8 | NUT X JR3020 |
| 64 | 911108-4 | SCREW M4X8 X 5103R |
| 65 | 344762-3 | INDICATOR X 4157KB |
| 66 | 265075-8 | SCREW M5 X 5704R |
| 67 | 344763-1 | PLATE ANGLE X 4157KB |
| 68 | 266227-4 | SCREW M 8 X 28 X 4157KB |
| 69 | 256442-8 | PIN 6-7 X 4157KB |
| 70 | 265965-5 | SCREW M8 X 24 X 5704R |
| 71 | 163409-8 | DEPTH GUIDE 'X 4157KB |
| 72 | 345192-1 | BASE X 4157KB |
| 73 | 266180-4 | SCREW M 5 X 12 X 4157KB |
| 74 | 912212-2 | SCREW 5 X 12 X LC1230 |
| 75 | 266180-4 | SCREW M 5 X 12 X 4157KB |
| 76 | 265085-5 | SCREW M4 X 8 X 4157KB |
| 77 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 78 | 158925-3 | BOX DUST SX X 4157KB |
| 79 | 344761-5 | MASS X 4157KB |
| 80 | 151564-8 | COVER BOX POL. 4157KB |
| 81 | 421362-7 | HOOD X 5017RKB |
| 82 | 188823-7 | BOX DUST SX X 4157KB P25 |
| 83 | 911263-2 | HEAD SCREW CILIND. M5x40 P01 |
| 85 | 213621-1 | RING 46 X P01 4157KB |
| 86 | 241513-4 | FAN 92 X SR2100 / 2300 P07 |
| 87 | 645200-1 | CAPACITOR P01 |
| 88 | 654542-2 | TERMINAL 2P X 4157KB P05 |
| 89 | 961055-9 | RETAINING RING S15 P01 |
