Makita Spare Parts for Rotary Hammer HR2631FT
Distribution and Sale at attractive prices of MAKITA Original Spare Parts. We guarantee low prices and a professional Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Rotary Hammer HR2631FT.
In the following table, look for the model of the Rotary Hammer and the respective parts of the code.
| Rotary Hammer HR2631FT | ||
| # | Part NUm. | Description |
| 8 | 122878-2 | GRIP ASS'Y HR2601 |
| 9 | 346181-9 | LEAF SPRING 50 HR2601 |
| 10 | 266349-0 | SCREW M8X50 HR2601 |
| 11 | 451539-0 | GRIP BASE HR2601 |
| 13 | 141765-6 | LOCK BUTTON HR2630T |
| 14 | 233360-7 | COMPRESSION SPRING 4 X MT952 |
| 15 | 154935-8 | GRIP 36 HR2601 |
| 16 | 142970-8 | GEAR BOX HR2631F |
| 17 | 331890-3 | CUP SLEEVE HR2601 |
| 18 | 211294-4 | BALL BEARING 6806LLU HR2601 |
| 19 | 232286-0 | SPRING PLATE HR2630T |
| 20 | 346833-2 | GEARBOX PLATE B X HR2630T |
| 21 | 346832-4 | CHANGE PLATE A X HR2630T |
| 22 | 213278-8 | RING 13 X HR2020 |
| 23 | 455392-6 | HR2630T CHANGE LEVER |
| 24 | 455394-2 | HR2630T CHANGE LEVER CAP |
| 25 | 455391-8 | COVER X HR2630T |
| 27 | 216019-1 | STEEL BALL 3 X DHR24 * / HR26 ** |
| 28 | 140266-1 | TOOL HOLDER GUIDE HR2611FT |
| 29 | 332139-4 | FLANGE HR2601 |
| 30 | 227360-7 | GEAR 51 HR2601 |
| 33 | 234148-8 | COMPRESSION SPRING 31 HR2601 |
| 34 | 267153-0 | WASHER 30 HR2601 |
| 35 | 257932-4 | WASHER 30 HR2601 |
| 36 | 267153-0 | WASHER 30 HR2601 |
| 37 | 325783-4 | SLEEVE 9B HR2601 |
| 38 | 325791-5 | IMPACT BOLT B HR2611FT |
| 39 | 325792-3 | WASHER 10 HR2601 |
| 40 | 234149-6 | COMPRESSION SPRING 20 HR2601 |
| 41 | 325793-1 | HOLDER RING B HR2601 |
| 42 | 213073-6 | RING 9 X HR2020 |
| 43 | 233979-2 | SPRING RING 28 HR2601 |
| 44 | 325784-2 | STRIKER HR2601 |
| 45 | 213258-4 | O-RING 17.5 X HR2210 / 20 |
| 46 | 310345-1 | PISTON CYLINDER HR2601 |
| 47 | 346036-8 | GUIDE PLATE BHR261D |
| 48 | 324215-8 | PIN X HR2020 |
| 49 | 234098-7 | COMPRESSION SPRING 14 BHR261D |
| 50 | 210137-7 | BEARING 606ZZ |
| 51 | 257336-0 | EXT U-6 RETAINING RING |
| 52 | 253186-1 | FLAT WASHER 7 X 420S |
| 53 | 233360-7 | SPRING COMPRESSION 4 X MT952 |
| 54 | 346831-6 | LOCK PLATE HR2630T |
| 55 | 326448-1 | SHAFT X HR2630T |
| 56 | 227359-2 | GEAR 10 X HR2630T |
| 57 | 332125-5 | CLUTCH CAM HR2630T |
| 58 | 219023-9 | SWASH BEARING 10 10 HR2631F |
| 59 | 257321-3 | RING 8 MT870 |
| 60 | 310344-3 | BEARING BOX HR2601 |
| 61 | 211032-4 | BEARING X 1902 |
| 62 | 266437-3 | SCREW M4X16 X HR4001C |
| 63 | 285735-6 | BEARING RETAINING HR2601 |
| 64 | 227719-8 | GEAR 26 HR2601 |
| 65 | 213728-3 | RING 68 X BHR261D |
| 66 | 346222-1 | PLATE HR2601 |
| 67 | 265353-6 | SCREW M 4 X 12 X 4341FCT |
| 69 | 141573-5 | INNER HOUSING X HR2631F |
| 70 | 213407-3 | GASKET 26 X 3901 |
| 71 | 213678-2 | SEAL OIL 12 MT870 |
| 72 | 262569-4 | SLEEVE 9 HR2601 |
| 73 | 211097-6 | BEARING 5604R |
| 74 | 961006-2 | RETAINING RING S10 |
| 75 | 240121-8 | FAN 65 HR2601 |
| 76 | 515359-7 | ARMATURE 240V |
| 77 | 681670-0 | INSULATION WASHER |
| 78 | 210023-2 | BEARING 9910/11 |
| 79 | 267804-5 | WAVY WASHER 15 HR2230 |
| 80 | 346180-1 | WEIGHT HOLDER GUIDE HR2601 |
| 81 | 256246-8 | PIN 6 LS1216F |
| 82 | 165593-5 | COUNTER WEIGHT HR2601 |
| 83 | 266361-0 | SCREW 4 X 30 X 9554NB |
| 84 | 451527-7 | BAFFLE HR2601 |
| 85 | 626634-7 | STATOR FIELD HR2601 |
| 86 | 451535-8 | MOTOR HOUSING HR2611FT |
| 89 | 194074-2 | CARBON BRUSHE CB-325 X 9554NB |
| 90 | 638655-7 | CARBON BRUSHE HOLDER HR2601 |
| 91 | 266556-5 | SCREW 3X12 HR26001 |
| 92 | 266361-0 | SCREW 4 X 30 X 9554NB |
| 95 | 682566-8 | CORD GUARD X HR2450 |
| 97 | 651090-2 | TG853TB-3 SWITCH |
| 98 | 631937-6 | HR2611FT LIGHT CIRCUIT |
| 99 | 687682-1 | CABLE CLAMP X JS1000 |
| 100 | 266385-6 | SCREW 4X14 FOR GA9020 |
| 101 | 266326-2 | SCREW 4X18 X MT601 |
| 102 | 451528-5 | HANDLE COVER HR2601 |
| 103 | 266326-2 | SCREW 4X18 X MT601 |
| 104 | 194080-7 | SDS-PLUS RAPID HOLDER |
| 105 | 286263-4 | CAP 35 X HR2020 |
| 106 | 233940-9 | ELASTIC RING 19 FOR HR2432 |
| 107 | 418217-5 | HR2450FT CHUCK COVER |
| 108 | 345333-9 | STOPPER HR2450FT |
| 109 | 216022-2 | STEEL BALL 7 |
| 110 | 345187-4 | GUIDE WASHER X HR2020 |
| 111 | 233916-6 | SPRING 21-29 X HR2020 |
| 112 | 267279-8 | FLAT WASHER 21 X HR2450FT |
| 113 | 324355-2 | TOOL HOLDER |
| 114 | 216013-3 | STEEL BALL 6 |
| 115 | 231669-1 | SPRING TORSION 31 X HR2450FT |
| 116 | 345334-7 | CHANGE RING X HR2450FT |
| 117 | 418218-3 | CHANGE RING COVER X HR2450FT |
| 118 | 216018-3 | STEEL BALL 5 HP2030 |
| 119 | 345335-5 | SPRING BAND X HR2450FT |
| 120 | 267270-6 | WASHER 24 X HR2450FT |
| 121 | 233924-7 | RING SPRING 21 X HR2450FT |
| 122 | 267447-3 | WASHER 14 HR2601 |
| 123 | 234343-0 | COMPRESSION SPRING 5 HR2630T |
| 999 | 195105-0 | HR2300 SERVICE KIT |
