Makita Spare Parts for Rotary Hammer HR2601
€19.64
Tax included
Makita Spare Parts for Rotary Hammer HR2601
MAKITA Original spare parts at the most competitive prices on the web, we are a service center with repair service able to advise you to purchase the most suitable spare part to quickly solve any maintenance or repair issues for Rotary Hammer SDS PLUS HR2601.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Rotary Hammer HR2601
MAKITA Original spare parts at the most competitive prices on the web, we are a service center with repair service able to advise you to purchase the most suitable spare part to quickly solve any maintenance or repair issues for Rotary Hammer SDS PLUS HR2601.
In the following table, look for the model of the Rotary Hammer and the respective parts of the code.
| Rotary Hammer Makita HR2601 | ||
| # | Part Num. | Description |
| 1 | 286288-8 | CAP 35 HR2601 |
| 2 | 451533-2 | FRONT COVER HR2601 |
| 3 | 325813-1 | RING 21 HR2601 |
| 4 | 346177-0 | GUIDE WASHER HR2601 |
| 5 | 233916-6 | SPRING 21-29 X HR2020 |
| 6 | 233989-9 | CIRCLIP 14 HR2601 |
| 7 | 346221-3 | WASHER 16 HR2601 |
| 8 | 122878-2 | SIDE HANDLE CPL HR2601 |
| 9 | 346181-9 | LEAF SPRING 50 HR2601 |
| 10 | 266349-0 | SCREW M8x50 HR2601 |
| 11 | 451539-0 | GRIP BASE HR2601 |
| 12 | 313179-1 | RACK HR2601 |
| 13 | 451540-5 | LOCK BUTTON HR2601 |
| 14 | 233360-7 | COMPRESSION SPRING 4 X MT952 |
| 15 | 154935-8 | HANDLE 36 HR2601 |
| 16 | 140268-7 | GEAR BOX HR2601 |
| 17 | 331890-3 | CUP SLEEVE HR2601 |
| 18 | 211294-4 | BEARING 6806LLU HR2601 |
| 19 | 232152-1 | LEAF SPRING 6832 |
| 20 | 325785-0 | PUSH CORN HR2601 |
| 21 | 234147-0 | COMPRESSION SPRING 5 HR2601 |
| 22 | 253308-3 | WASHER 6 43SB / 6510b-2 / 5016N |
| 23 | 213381-5 | O-RING 21 NEW HR3510 / 20 |
| 24 | 451531-6 | LEVER B HR2601 |
| 25 | 451532-4 | COVER LEVER HR2601 |
| 26 | 216022-2 | STEEL BALL 7 |
| 27 | 216019-1 | STEEL BALL 3 X 6960DW |
| 28 | 140265-3 | TOOL HOLDER HR2601 |
| 29 | 332139-4 | FLANGE HR2601 |
| 30 | 227360-7 | GEAR 51 HR2601 Substituited by da 227360-7 |
| 33 | 234148-8 | COMPRESSION SPRING 31 HR2601 |
| 34 | 267153-0 | WASHER 30 HR2601 |
| 35 | 257932-4 | WASHER RETAINING 30 HR2601 |
| 36 | 267153-0 | WASHER 30 HR2601 |
| 37 | 325783-4 | BUSH 9B HR2601 |
| 38 | 325789-2 | SWING A HR2601 |
| 39 | 325792-3 | WASHER 10 HR2601 |
| 40 | 234149-6 | COMPRESSION SPRING 20 HR2601 |
| 41 | 325793-1 | SUPPORT RING B HR2601 |
| 42 | 213073-6 | RING 9 X HR2020 |
| 43 | 233979-2 | CIRCLIP 28 HR2601 |
| 44 | 325784-2 | STRIKER HR2601 |
| 45 | 213258-4 | O-RING 17.5 X HR2210 / 20 |
| 46 | 310345-1 | PISTON CYLINDER HR2601 |
| 47 | 346036-8 | GUIDE PLATE BHR261D |
| 48 | 324215-8 | PIN X X PISTON HR2020 |
| 49 | 234098-7 | COMPRESSION SPRING 14 BHR261D |
| 50 | 210028-2 | BEARING 606ZZ |
| 56 | 227243-1 | GEAR 10 HR2601 |
| 57 | 331815-7 | CAM CLUTCH B HR2601 |
| 58 | 219020-5 | SWASH BEARING 10 HR2601 |
| 59 | 267234-0 | FLAT WASHER 8 X HR2020 |
| 60 | 310344-3 | BEARING BOX HR2601 |
| 61 | 211032-4 | BEARING X 1902 |
| 62 | 266437-3 | SCREW M4x16 FRENAFIL X HR4001C |
| 63 | 285735-6 | RETAINING BEARING HR2601 |
| 64 | 227719-8 | GEAR 26 HR2601 |
| 65 | 213728-3 | RING 68 X BHR261D |
| 66 | 346222-1 | PLATE HR2601 |
| 67 | 265353-6 | SCREW M 4 X 12 X 4341FCT |
| 68 | 443153-6 | FELT HR2601 |
| 69 | 140267-9 | CASING INTERNAL HR2601 |
| 70 | 213407-3 | SEAL 26 X 3901 |
| 71 | 213133-4 | SEAL OIL 12 X HR2800 |
| 72 | 262569-4 | SLEEVE 9 HR2601 |
| 73 | 211097-6 | BEARING 5604R |
| 74 | 961006-2 | RETAINING RING S10 |
| 75 | 240121-8 | FAN 65 HR2601 |
| 76 | 515359-7 | ARMATURE 240V |
| 77 | 681652-2 | INSULATION WASHER X JR180D |
| 78 | 210023-2 | BEARING 9910/11 |
| 79 | 267804-5 | WASHER 15 HR2230 |
| 80 | 346180-1 | WEIGHT HOLDER GUIDE HR2601 |
| 81 | 256246-8 | PIN 6 LS1216F |
| 82 | 165593-5 | COUNTER WEIGHT HR2601 |
| 83 | 266361-0 | SCREW 4 X 30 X 9554NB |
| 84 | 451527-7 | BAFFLE HR2601 |
| 85 | 626634-7 | FIELD ASS'Y HR2601 |
| 86 | 451536-6 | MOTOR HOUSING HR2601 |
| 89 | 194074-2 | CARBON BRUSH CB-325 X 9554NB |
| 90 | 638655-7 | BRUSHE HOLDER HR2601 |
| 91 | 266556-5 | SCREW 3X12 HR26001 |
| 92 | 266361-0 | SCREW 4 X 30 X 9554NB |
| 95 | 682566-8 | CORD GUARD X HR2450 |
| 97 | 650625-6 | SWITCH HR2601 |
| 99 | 687682-1 | CORD CLAMP X JS1000 |
| 100 | 266385-6 | 4x14 SCREW FOR GA9020 |
| 101 | 266326-2 | SCREW 4x18 X MT601 |
| 102 | 451528-5 | HANDLE COVER HR2601 |
| 103 | 266326-2 | SCREW 4x18 X MT601 |
| 104 | 267447-3 | WASHER 14 HR2601 |
| 105 | 233992-0 | CIRCLIP 15 HR2601 |
| 106 | 267437-6 | WASHER 17 HR2601 |
| 107 | 424364-2 | RUBBER WASHER 16 HR2601 |
| 999 | 195105-0 | SERVICE KIT HR2300 |
