Makita Spare Parts for Rotary Hammer HR2230
€4.86
Tax included
Makita Spare Parts for Rotary Hammer HR2230
Makita genuine spare parts or replacement parts for to repair Rotary Hammer SDS-PLUS HR2230.Fix Your Rotary Hammer SDS-PLUS HR2230. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Rotary Hammer HR2230
Fix Your Rotary Hammer SDS-PLUS HR2230. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.In the following table, look for the model of Rotary Hammer and the respective parts of the code.
| HR2230 - ROTARY HAMMER 710W 22mm | ||
| # | Part Num. | Description |
| 1 | 286263-4 | CAP 35 X HR2020 |
| 2 | 233940-9 | RING SPRING 19 FOR HR2432 |
| 3 | 417629-9 | CHUCK COVER X HR2020 |
| 4 | 257241-1 | RING 21 X HR2020 |
| 5 | 345187-4 | GUIDE WASHER X HR2020 |
| 6 | 233916-6 | CONICAL COMP. SPRING 21-29 X HR2020 |
| 7 | 921923-8 | HEX. BOLT M 8 X 120 X HR2020 |
| 8 | 345280-4 | WASHER X HP2051F |
| 9 | 417630-4 | GRIP BASE X HR2020 |
| 10 | 158057-6 | GRIP 36 CPL HR2230 |
| 13 | 162244-1 | CHANGE LEVER HR2230 |
| 14 | 233459-8 | COMPRESSION SPRING 3 HR1830 |
| 15 | 419192-8 | LOCK BUTTON HR1830 |
| 16 | 213278-8 | O-RING 13 X HR2020 |
| 17 | 158305-3 | GEAR HOUSING COMPLETE HR2230 |
| 18 | 266351-3 | TAPPING SCREW 4 X 35 X 9557PB |
| 19 | 153290-5 | NEEDLE BEARING COMPLETE X HR2020 |
| 20 | 233918-2 | RING SPRING 28 X HR2020 |
| 21 | 267805-3 | WASHER 30 HR2230 |
| 22 | 233328-3 | COMPRESSION SPRING 31 X HR2020 |
| 23 | 227019-6 | SPUR GEAR 51 X HR2020 |
| 24 | 216022-2 | STEEL BALL 7 |
| 25 | 158575-4 | TOOL HOLDER COMPLETE HR2230 |
| 26 | 267229-3 | FLAT WASHER 28 X HR2020 |
| 27 | 331769-8 | SLEEVE 9 FOR HR2230 |
| 28 | 324669-9 | IMPACT BOLT BHR240 |
| 29 | 324402-9 | RING 10 X HR2450FT |
| 30 | 421955-0 | CUSHION RING 13 |
| 31 | 324216-6 | RING X HR2020 |
| 32 | 213073-6 | RING 9 X HR2020 |
| 33 | 233917-4 | RING SPRING 28 X HR2020 |
| 34 | 324214-0 | STRIKER X HR2020 |
| 35 | 213227-5 | O-RING 16 X HK0500 |
| 36 | 317517-9 | PISTON CYLINDER X HR2020 |
| 37 | 267104-3 | FLAT WASHER 12 X HR2400 |
| 38 | 324215-8 | PISTON JOINT X HR2020 |
| 39 | 267104-3 | FLAT WASHER 12 X HR2400 |
| 40 | 213727-5 | O-RING 63 FOR BHR240 |
| 41 | 211012-0 | BALL BEARING X 9524NB |
| 42 | 267212-0 | FLAT WASHER 12 X 6916DW |
| 43 | 233347-9 | COMPRESSION SPRING 12 X HR2020 |
| 44 | 331734-7 | CLUTCH CAM HR2230 |
| 45 | 227182-5 | SPUR GEAR 10 HR2230 |
| 46 | 219014-0 | SWASH BEARING 10 X HR2020 |
| 47 | 226656-3 | HELICAL GEAR 26 X HR2230 |
| 48 | 266273-7 | HEX. SOCKET HEAD BOLT M4X12 4604D |
| 49 | 345179-3 | BEARING RETAINER X HR2020 |
| 50 | 267234-0 | FLAT WASHER 8 X HR2020 |
| 51 | 211032-4 | BALL BEARING X 1902 |
| 52 | 324212-4 | RING 8 X HR2020 |
| 53 | 961011-9 | STOP RING E-4 |
| 54 | 233388-5 | COMPRESSION SPRING 5 X HR2020 |
| 55 | 346035-0 | CHANGE PLATE HR2230 |
| 56 | 158308-7 | INNER HOUSING COMPLETE HR2230 |
| 57 | 443126-9 | FELT X BHR240 |
| 58 | 213407-3 | O RING 26 X 3901 |
| 59 | 213077-8 | OIL SEAL X HR2230 |
| 60 | 210059-1 | BALL BEARING 6000 HR2010 |
| 61 | 267213-8 | FLAT WASHER 10 HR2430 |
| 62 | 240092-9 | FAN 64 HR2230 |
| 63 | 515284-2 | ARMATURE ASS'Y 240V HR2230 |
| 64 | 681670-0 | INSULATION WASHER |
| 65 | 210023-2 | BALL BEARING 9910/11 |
| 66 | 267804-5 | WAVE WASHER 1515 HR2230 |
| 67 | 266415-3 | TAPPING SCREW 4X55 HR2230 |
| 68 | 344871-8 | RETAINER X GD0800C |
| 69 | 419716-0 | BUFFLE PLATE HR2230 |
| 70 | 626574-9 | FIELD 240V HR2230 |
| 71 | 419720-9 | MOTOR HOUSING HR2230 |
| 72 | 863508-3 | LABEL MOD. HR2230 |
| 73 | 194074-2 | CARBON BRUSH CB-325 X 9554NB |
| 74 | 638500-6 | BRUSH HOLDER UNIT HR2230 |
| 75 | 650588-6 | SWITCH C3VA-2L-C HR2230 |
| 76 | 814954-3 | HR2230 NAME PLATE |
| 77 | 682566-8 | CORD GUARD 10 X HR2450 |
| 79 | 687260-7 | STRAIN RELIEF X GA5010 |
| 80 | 266324-6 | TAPPING SCREW 4X22 X MT601 |
| 82 | 419717-8 | HANDLE COVER HR2230 |
| 83 | 266324-6 | TAPPING SCREW 4X22 X MT601 |
| 84 | 266324-6 | TAPPING SCREW 4X22 X MT601 |
| 999 | 195263-2 | SERVICE KIT HR2230 / 2470 |
