Makita Wall Chaser SG181 Spare Parts

€409.72
Tax included

Makita Wall Chaser SG181 Spare Parts

Makita genuine spare parts or replacement parts for to repair SG181 - WALL CHASER 2150W 180MM.
ITEM CODE: B09172
Quantity
Usually Ships in: 7/10 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Makita Wall Chaser SG181 Spare Parts

Makita genuine spare parts or replacement parts for to repair SG181 - WALL CHASER 2150W 180MM.

In the following table, look for the model of Groover and the respective parts of the code.
Makita SG181 - WALL CHASER 2150W 180MM
Makita SG181 - WALL CHASER 2150W 180MM
# Part Num. Description
1 B09172 ARMATURE
2 B22681 BALL BEARING 6000 2RS
3 B08306 SCREW 5X20
4 B08890 GEAR BOX
5 B33415 SCREW M5 X 20 X SG150
6 B07450 SCREW M4.8 X 80 X SG150
7 B30387 PLATE 0.3 X SG150
8 B30148 RING 46X2 X SG2150
9 B09171 SPINDLE CPL
17 B07756 SCREW 4X90
20 B11122 BOLT M 8 X 90 X SG150
21 B11189 WASHER 8.4 X SG150
22 B10777 ROLLER X SG150
23 B11247 TUBE X SG150
24 B18952 NUT M8 X SG150
25 B10983 BOLT M 8 X 16 X SG150
26 B29934 OUTER FLANGE X SG150
27 B30486 RING 3 X SG150
29 B08845 FLANGE B
30 B08847 FLANGE A
31 B06879 SCREW M8X70
32 B07692 DISC GUARD
33 B08482 SIDE HANDLE X SG150
35 B21071 WASHER M8 X SG150
37 B08042 BAFFLE
38 B73536 FIELD ASSY
39 B50807 MOTOR CASING X SG150
41 B45872 CARBON BRUSH X SG150 (single)
42 B52894 CARBON BRUSH HOLDER X SG150
43 B38299 CARBON BRUSH HOLDER COVER X SG180
44 B21030 SCREW M3.9 X 13 X SG150
45 B30981 BOLT M 7 X 12 X SG150
46 B31070 WASHER 7.4 X SG150
47 B10801 SUPPORT X SG150
48 B26948 WASHER 13 X SG150
49 B09506 TENSION ROLLER  X SG150
50 B31096 TUBE X SG150
51 B48611 COMPLETE HANDLE X SG150
53 B44941 SCREW M4.8 X 38 X SG150
54 B71787 ELECTRONIC BOARD
55 B31468 SWITCH X SG150
57 B17913 CLAMP X 2702
58 B25221 CORD GUARD SG150
