FASA Parts for Pressure Cleaner Rap 110
Lavor original spare parts for to replace broken parts for to fix Cold Water High Pressure Cleaner Rap 110 - 8.109.0030CFix Your Pressure Cleaner Rap 110. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
FASA Parts for Pressure Cleaner Rap 110
Lavor original spare parts for to replace broken parts for to fix Cold Water High Pressure Cleaner Rap 110 - 8.109.0030C
Fix Your Pressure Cleaner Rap 110. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following tables, look for the spare part and its respective code.
| Cold Water Pressure Cleaner FASA Rap 110 - 8.109.0030C Pag.1 | ||
| Pos. | Part Num. | Description |
| * | 50010801C | MOTOP.SP.PT'03EVO 230/50 C/TERM.-TSC-SP.SCHUKO 4'45 (7630PF-KC) |
| 001 | 5.011.0338 | ASSEMBLY BLUE COVER/GREY FRONT COVER(RAL.7016)ONE-R |
| 002 | 4.008.1186 | AIR CONVEYOR FOR U76 (LIGHT) |
| 003 | 4.008.1860 | GREY LOW HANDLE ONE RAL.7016 (PANT.432C) |
| 004 | 4.008.1861 | GREY ACCESSORY HOLDER ONE RAL.7016 (PANT.432C) |
| 005 | 4.013.0778 | GREY BACK COVER ONE RAL.7016 (PANT.432C) |
| 006 | 7.100.2035 | MANUAL ONE/SMART/FAST/DIVE + CE LAVOR |
| 007 | 5.001.0801C | MTP PT'03EVO 230/50 TSC-THERMAL 4'45 (7630PF-KC) SCHUKO PLUG |
| 010 | 6.001.0076 | GUN S'16 WITH INTEGRAL QUICK JOINT |
| 011 | 4.018.0106 | HOSE 1/4 18MPa L=3000 M22x1,5 D.15-RAPID FIX W/SPIRAL SLEEVE |
| 014 | 6.002.0326 | LANCE S'02V D.0,9 PINK RAL.3015 (PANT.706C) |
| 021 | 6.002.0358 | FOAM SPRAYER (D.4) W/TRANSPARENT TANK |
| 022 | 3.100.0082C | BLACK QUICK COUPLING INLET CONNECTOR (THREAD=9.5) |
| 023 | 5.011.0293 | ASSEMBLY BLACK WHEEL/BLUE WHEEL COVER FAST/ONE (RAL.5015) |
| 024 | 4.008.1862 | GREY BACK BASE FOR TROLLEY ONE/SMART RAL.7016 (PANT.432C) |
| 025 | 4.008.1863 | GREY FRONT BASE FOR TROLLEY ONE/SMART RAL.7016 (PANT.432C) |
| 50010801C - MOTOP.SP.PT'03EVO 230/50 C/TERM.-TSC-SP.SCHUKO 4'45 (7630PF-KC) Pag.2 | ||
| .. | 50090972C | GRUPPO CORPO GUIDA C/TSC-SP.SCHUKO M.13KG S/ASP. +TESTATA (PT'03EVO) |
| 001 | 5.009.0978 | 7630PF-KC MOTOR PT'03 230/50 W/CAPACITOR-THERMAL 17AM-D 140G |
| 002 | 4.008.1164 | RING FOR FLANGE X MOTOR U96AF/ U76 -C- |
| 003 | 6.005.0311 | THRUST RING KIT (PT'03 U76) |
| 004 | 4.007.0205 | PIN 10X70 |
| 005 | 5.009.0728 | 4'45 WOBBLE PLATE ASSEMBLY W/CROWN Z 62 (PT'03) |
| 006 | 4.007.0328 | THRUST BEARING 35X55X12 PT'03 |
| 007 | 5.009.0972C | BODY GUIDE W/TSC-SCHUKO PLUG NO SUCTION +HEAD PT'03EVO |
| 50090972C - GRUPPO CORPO GUIDA C/TSC-SP.SCHUKO M.13KG S/ASP. +TESTATA Pag.3 | ||
| . | 50070264C | CORPO GUIDA PT'03EVO C/TSC S/ASP. MOLLA 13KG C/CAVO SP.SCHUKO |
| .. | 50080261 | TESTATA PT'03EVO D.12 |
| 001 | 5.009.0972C | BODY GUIDE PT'03EVO W/TSC-SCHUKO PLUG WITHOUT SUCTION |
| 002 | 6.005.0282 | KIT 348 SPACER FOR WATER SEAL |
| 003 | 5.008.0261 | PT'03EVO HEAD D.12 |
| 50070264C - CORPO GUIDA PT'03EVO C/TSC S/ASP. MOLLA 13KG C/CAVO SP.SCHUKO Pag.4 | ||
| 001 | 6.005.0590 | KIT COMPLETE TS PT'03 (AH) |
| 002 | 6.005.0281 | KIT 256 VALVE GUIDE RID. W/O SUCTION PT'03C |
| 003 | 6.005.0226 | KIT 209 O-RING |
| 004 | 4.005.0299 | PISTON BODY GUIDE PT'03EVO |
| 005 | 6.005.0181 | KIT 167 LW PISTON |
| 006 | 4.007.0314 | PIN 3,5x30 ZNT |
| 007 | 4.012.0174C | CABLE H05VV-F 2X1 MT.5,4 F/F SCHUKO PLUG W/FASTON COVER |
| 50080261 - TESTATA PT'03EVO D.12 Pag.5 | ||
| 001 | 4.005.0298 | PT''03EVO PARTNER HEAD |
| 002 | 6.005.0133 | KIT 124 O-RING WATER SEAL PARTNER D.12 |
| 003 | 6.005.0588 | KIT LW VALV.ASP./MAND.+TAPPI PT' 03EVO |
