Annovi Reverberi Parts for Pressure Washer AR767
Annovi Reverberi Genuine Parts and Accessories, Tech Service, repair and after-sales service with great professional skills necessary to follow you and advise you on the purchase of spare parts that are most suitable for solving your repair and maintenance problems for Pressure Washer Blue Clean AR767 - 12364.
In the following tables, look for the spare part and its respective code.
| Pressure Washer Blue Clean AR767 - 12364 | ||
| Casing 767 Pag.1 | ||
| # | Part Num. | Description |
| 1 | 2500045 | Blue Casing |
| 2 | 2500340 | Stopper |
| 3 | 2500310 | Knob |
| 4 | 2500050 | Hook |
| 5 | 2500240 | Bowl |
| 6 | 1680880 | Washer |
| 7 | 2500320 | Wheel |
| 8 | 2500330 | Pipe Cleaner |
| 9 | 2500100 | Plate |
| 10 | 1260470 | Screw |
| 11 | 2100300 | Screw |
| 12 | 2600100 | Gland |
| 13 | 2100300 | Screw |
| 14 | 2500020 | Handle |
| 15 | 2500130 | Rubber |
| 16 | 880280 | Screw |
| 17 | 2180300 | Washer |
| 18 | 2500120 | Axle |
| 19 | 2500110 | Tank |
| 20 | 2500010 | Basis |
| 21 | 42113 | Pre-Assembly Cap |
| 22 | 2500330 | Pipe Cleaner |
| 23 | 2000230 | Filter |
| 24 | 2509000 | Pre-Assembly Base |
| Pump 757 Pag.2 |
||
| 1 | 1260760 | Screw |
| 2 | 1269101 | Cover |
| 3 | 1260040 | Oil Seal |
| 4 | 1260780 | Screw |
| 5 | 1980740 | Stopper |
| 6 | 740290 | O-Ring |
| 7 | 1260012 | Pump Body |
| 8 | 1266740 | Oil Seal |
| 9 | 1260790 | Ring |
| 10 | 1320370 | Bearing |
| 11 | 1320330 | Bushing |
| 12 | 1260460 | Oil Seal |
| 13 | 1260450 | Tenuta Water |
| 14 | 1260420 | O-Ring |
| 15 | 1320351 | Piston Guide |
| 16 | 1780720 | Tenuta Water |
| 17 | 1320340 | Ring |
| 18 | 820361 | Stopper |
| 19 | 180101 | O-Ring |
| 20 | 1320020 | Head |
| 21 | 1381550 | Washer |
| 22 | 680570 | Screw |
| 23 | 960160 | O-Ring |
| 24 | 1260162 | Stopper |
| 25 | 1269050 | Complete Valve |
| 26 | 880830 | O-Ring |
| 27 | 1343160 | Junction |
| 28 | 3226 | Manometer |
| 29 | 1260180 | Tree |
| 30 | 1320370 | Bearing |
| 32 | 1260790 | Ring |
| 33 | 1260750 | Ring |
| 34 | 1380520 | Tongue |
| 35 | 1320140 | Piston Rod |
| 36 | 1260070 | Piston |
| 37 | 1260080 | Plug |
| 38 | 1260091 | Disk |
| 39 | 480480 | O-Ring |
| 40 | 1260211 | Piston |
| 41 | 1260100 | Washer |
| 42 | 1260110 | Nut |
| 43 | 1269284 | Pre-Assembly Head |
| A | 1864 | Kit Valves |
| B | 2629 | Piston Kit |
| C | 1865 | Kit Oil Seals |
| E | 42479 | Kit Kept Water |
| F | 2040 | Gasket Kit |
| Valve 767 Pag.3 |
||
| 1 | 2500210 | Knob |
| 2 | 392840 | Screw |
| 3 | 1980300 | Nut |
| 4 | 2500540 | Insert |
| 5 | 1980220 | Disk |
| 6 | 1271070 | Spring |
| 7 | 1080041 | Piston |
| 8 | 1080070 | Plug |
| 9 | 1080401 | Ring |
| 10 | 1080250 | O-Ring |
| 11 | 1080070 | Plug |
| 12 | 1980210 | Piston Guide |
| 13 | 740290 | O-Ring |
| 14 | 800560 | O-Ring |
| 15 | 880830 | O-Ring |
| 16 | 1271170 | Ring |
| 17 | 1080190 | O-Ring |
| 18 | 1271160 | Piston |
| 19 | 1980200 | Office |
| 20 | 1470210 | O-Ring |
| 21 | 1540272 | Screw |
| 22 | 390080 | O-Ring |
| 23 | 1540660 | Valve Body |
| 24 | 1140450 | O-Ring |
| 25 | 1460430 | O-Ring |
| 26 | 1540170 | Shutter |
| 27 | 1080091 | Spring |
| 28 | 394280 | O-Ring |
| 34 | 1560490 | Hose |
| 35 | 480480 | O-Ring |
| 36 | 1250280 | Sphere |
| 37 | 1560520 | Spring |
| 38 | 1540570 | Junction |
| 39 | 1540300 | Nut |
| 41 | 1540280 | Collector |
| 42 | 1540630 | O-Ring |
| 44 | 880270 | O-Ring |
| 45 | 2260420 | Screw |
| 46 | 480440 | O-Ring |
| 47 | 1560900 | Junction |
| 48 | 1461470 | Junction |
| 50 | 1340260 | Filter |
| 51 | 1123960 | Junction |
| 52 | 1981190 | Screw |
| 53 | 1260820 | O-Ring |
| 54 | 1540881 | Piston |
| 55 | 1981320 | Spring |
| 56 | 2022201 | Fork |
| 57 | 2029753 | Pre-Assembly Box TSS |
| 58 | 660191 | O-Ring |
| 59 | 880840 | O-Ring |
| 60 | 1540870 | Stopper |
| 61 | 22075 | Complete Valve |
| 62 | 1120681 | O-Ring |
| 63 | 42458 | Kit TSS |
| 64 | 1080192 | O-Ring |
| F | 42451 | Gasket Kit |
| Engine 767 Pag.4 |
||
| 1 | 1260300 | Fan |
| 2 | 1260970 | Estate |
| 3 | 480621 | Screw |
| 4 | 1260961 | Shield |
| 5 | 1260950 | Bearing |
| 6 | 1269100 | Clamp |
| 7 | 1260400 | Gasket |
| 8 | 1261560 | Screw |
| 9 | 1272010 | Box |
| 11 | 1272370 | Switch |
| 12 | 1271950 | Cable Clamp |
| 13 | 1269090 | Cable Clamp |
| 14 | 2360400 | Condenser |
| 15 | 1340280 | Band |
| 16 | 1260810 | Screw |
| 18 | 1270950 | Cable |
| 19 | 4553 | Engine |
| 20 | 1271660 | Fan Cover |
| 21 | 1261570 | Screw |
| Accessories 767 Pag.5 |
||
| 1 | 40925 | Gun |
| 2 | 40112 | Lancia + Head |
| 3 | 1271960 | High Pressure Hose |
| 4 | 2000770 | O-Ring |
