Alpina Spare Parts for Brushcutter STAR 41 (2007) 284120009/M
€1.41
Tax included
Alpina Spare Parts for Brushcutter STAR 41 (2007) 284120009/M
ALPINA authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Brushcutter STAR 41 (2007) 284120009/M.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Alpina Spare Parts for Brushcutter STAR 41 (2007) 284120009/M
ALPINA authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Brushcutter STAR 41 (2007) 284120009/M.
In the following table, look for the model of the Brushcutter and the respective parts of the code.
| ALPINA STAR 41 (2007) 284120009/M- Pag.1 | ||
| # | Part Num. | Description |
| 1 | 2135040 | Screw |
| 2 | 4540800 | Transmission Support |
| 4 | 2132500 | Screw |
| 5 | 2312120 | Washer |
| 6 | 3745530 | Grommet |
| 7 | 2653210 | Screw |
| 8 | 3654040 | Clutch Spring |
| 9 | 3L3660430/1 | Clutch Arm |
| 10 | 2321230 | Washer |
| 11 | 2135060 | Screw |
| 12 | 2321150 | Washer |
| 13 | 3211015 | Electronic Coil |
| 14 | 3211080 | Coil Cable |
| 15 | 3782040 | Cables protection |
| 16 | 3211415 | Earth Cable |
| 17 | 3L4251480/1 | Flywheel |
| 18 | 2670120 | Nut |
| 19 | 2135050 | Screw |
| 20 | 3121070 | Seal ring |
| 21 | 3745130 | Cable grommet |
| 22 | 8521010 | Motor Case Assy |
| 23 | 3151010 | Flywheel Kay |
| 25 | 3116100 | Needle Bearing |
| 27 | 8250840 | Crankshaft |
| 28 | 3112240 | Needle Bearing |
| 29 | 3750280 | Cable Guide |
| 30 | 3724050 | Engine Crankcase Gasket |
| 31 | 2432040 | Nut |
| 32 | 2123100 | Screw |
| 33 | 3654050 | Spring |
| 34 | 3749570 | Starter Cup |
| 35 | 8540810 | Starter Cup Assy |
| 36 | 2135180 | Screw |
| 37 | 4563660 | cylinder cover Yellow |
| 38 | 4122120 | Muffler |
| 41 | 3724340 | Muffler gasket |
| 42 | 3744850 | Spark Plug Cap |
| 43 | 3657530 | Spark Plug Cable terminal |
| 44 | 3210024 | Spark Plug |
| 45 | 2135150 | Screw |
| 46 | 3724260 | Cylinder gasket |
| 47 | 3123150 | Piston Ring |
| 48 | 3158260 | Piston pin |
| 49 | 3356050 | Circlip |
| 50 | 8541120 | Piston assembly Ø 38 |
| 51 | 8541110 | Cylinder - Piston assembly |
| 52 | 4253290 | Fuel Filter |
| 53 | 8745541 | Hose Grommet |
| 54 | 8741370 | Tank Cap Assy |
| 55 | 4252470 | Fuel Tank assembly |
| 61 | 2112310 | Screw |
| 62 | 8724340 | Gaskets Set |
| 63 | 4612587 | Engine Support Flange |
| ALPINA STAR 41 (2007) 284120009/M- Pag.2 | ||
| 1 | 3724360 | Cylinder Manifold Gasket |
| 2 | 3750410 | Intake manifold - DISCONTINUED |
| 3 | 2670280 | Nut |
| 4 | 2135050 | Screw |
| 5 | 3724400 | Carburetor Manifold Gasket |
| 6 | 3785070 | Thermal Spacer |
| 7 | 1L4353270/1 | Carburetor |
| 8 | 8750390 | Air Filter Support |
| 9 | 2312090 | Washer |
| 10 | 2135250 | Screw |
| 11 | 3781600 | Air filter |
| 12 | 4563670 | Air Filter Cover Yellow |
| 13 | 2123100 | Screw |
| 14 | 3613420 | Washer |
| 15 | 4562220 | Starter Pulley |
| 16 | 3723640 | Starter Spring Disc |
| 17 | 4611480 | Starter Spring |
| 18 | 8563650 | Starter Carter |
| 19 | 2135040 | Screw |
| 20 | 3784030 | Starter rope |
| 21 | 3750067 | Starter handle |
| 22 | 3745530 | grommet |
| 23 | 4252680 | Starter assembly |
| 24 | 3744870 | Primer |
| 25 | 4353150 | Carburettor Diaphragm-Seal Kit |
| 30 | 2461030 | Square Nut |
| ALPINA STAR 41 (2007) 284120009/M- Pag.3 | ||
| 1 | 2123030 | Screw |
| 2 | 3750330 | Front Casing Support |
| 3 | 3744290 | Front anti-vibration rubber |
| 4 | 4563560 | Front handle |
| 5 | 2312150 | Washer |
| 6 | 2123140 | Screw |
| 7 | 3750340 | Ring Reduction - DISCONTINUED |
| 8 | 4563531 | Carter Transmission |
| 9 | 8563540 | Pair of Handle Shells |
| 10 | 3743630 | Safety Lever |
| 11 | 3654490 | Spring |
| 12 | 3743620 | Throttle lever - OBSOLETE - NO LONGER AVALAIBLE |
| 13 | 3749270 | Knob |
| 14 | 3612710 | Stop plate |
| 15 | 2123070 | Screw |
| 16 | 3L3786200/1 | Cables protection |
| 17 | 4252450 | Throttle Cable |
| 18 | 3211120 | Earth wire |
| 19 | 3211490 | Switch Coil Cable (Red) |
| 20 | 3744300 | Rear Anti-vibration Grommet |
| 21 | 2135150 | Screw |
| 22 | 2432030 | Nut |
| 23 | 2135160 | Screw |
| 24 | 2126050 | Screw |
| 25 | 3112170 | Ball bearing |
| 26 | 3353080 | Seeger ring |
| 27 | 3L8520990/3 | Transmission Hub Assembly Ø26 |
| 28 | 3L4121861/1 | Clutch Drum assembly |
| 29 | 3642191 | Bearing Hub |
| 30 | 4251400 | Drive Shaft Assembly |
| 31 | 4251204 | Transmission Tube Assembly (Ø26) |
| 32 | 2312150 | Washer |
| 33 | 2135060 | Screw |
| 34 | 2135030 | Screw |
| 35 | 3615000 | Wire Blade |
| 36 | 2432040 | Nut |
| 37 | 2312150 | Washer |
| 38 | 3L8563570/1 | Safety guard assembly |
| 39 | 4253460 | Harness |
| ALPINA STAR 41 (2007) 284120009/M- Pag.4 | ||
| 1 | 3L4252780/1 | Gears Case Assembly Ø26 - Available in Adaptable Version, with Universal Head Adapter and Stone Guard Kit |
| 7 | 2135050 | Screw |
| 8 | 2653090 | Screw |
| 9 | 2653460 | Screw |
| 15 | 3121170 | Seal ring |
| 16 | 3641700/1 | Head Collar DC D = 26 05 |
| 17 | 3641640 | Upper ring |
| 18 | 3612640 | Lower ring |
| 19 | 4560610 | Fixed Cup |
| 22 | 4611880 | Disc 4 Tips |
| 31 | 4353240/1 | 2 Wire Head |
| ALPINA STAR 41 (2007) 284120009/M- Pag.5 | ||
| 1 | 6910500 | Transmission Carter Assembly Ø24 |
| 2 | 6910502 | Carter Chain |
| 3 | 6910503 | Oil tank |
| 4 | 6910504 | Lid Ø24 |
| 5 | 6910506 | Flange |
| 6 | 6910507 | Screw |
| 7 | 6910508 | Oil Pump Assembly |
| 8 | 4112610 | Guide bar 10inch |
| 9 | 4113551 | 10 inch chain |
| ALPINA STAR 41 (2007) 284120009/M- Pag.6 | ||
| 1 | 6910520 | Blades assembly |
| 2 | 6910521 | Transmission Carter Assembly |
| 3 | 6910524 | Gear Head Assembly |
| 4 | 6910523 | Lever + Adjustment Bracket |
| 5 | 4252640 | Sleeve |
| 6 | 2382430 | Spacer |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Alpina websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Alpina brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
