FASA Pressure Cleaner KAPPA Parts
€306.02
Tax included
FASA Original Parts for Pressure Cleaner KAPPA
Fix Your Hot Water High Pressure Cleaner KAPPA A 230/50 TS BLU FASA - 8.052.0803. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
FASA Original Parts for Pressure Cleaner KAPPA
Fix Your Hot Water High Pressure Cleaner KAPPA A 230/50 TS BLU FASA - 8.052.0803. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following tables, look for the spare part and its respective code.
| Pressure Cleaner KAPPA A 230/50 TS BLU FASA - 8.052.0803 | ||
Motor Pump Pag.1 |
||
| # | Part Num | Description |
| 0 | 5.001.0824 | MOTOP.PT'03 110h100 230-240/50 D.12 9'35 TS IN.1,7 (FKX) |
| 1 | 3.404.0017 | CAPACITATOR 25mF 450V D.39X94 F/M |
| 7 | 4.008.0583 | FAN COVER FOR '96 ENGINE WITHOUT GRID |
| 9 | 6.005.0253 | KIT 236 LW LOWERED FAN + RING |
| 11 | 3.001.0020 | RADIAL BALL BEARING 620 3 2RS |
| 14 | 5.009.0533 | FRONT FLANGE PT'03 D.110 W/A N.TEN. |
| 15 | 3.201.0008 | OIL SEAL RING D.17X35X 7 |
| 16 | 3.001.0030 | RADIAL BALL BEARING 6303 (17X47X14) |
| 17 | 4.005.0218 | INCLINED PLATE 9'35 PT'03 |
| 19 | 6.005.0087 | KIT 87 LW ROLLER CAGES FOR MOTOP. FIBER/PT'03 |
| 20 | 6.005.0181 | EXT KIT 167 LW 3 PISTONS + SPRINGS PT'03 |
| 22 | 6.005.0226 | ORD KIT 209 O-RINGS FOR PT'03 |
| 24 | 6.005.0183 | EXT KIT 169 LW INJECTOR 1.7 +POR TAG.+CHECK VALVE PT'03 |
| 25 | 6.005.0079 | ORD KIT 79 LW OIL SEAL RINGS FOR PARTNER D.12/FIBER |
| 26 | 6.005.0184 | ORD KIT 170 LW VALVE INSP./DELIVERY PT' 03 |
| 27 | 4.005.0210 | HEAD PT'03 WASH |
| 28 | 6.005.0133 | ORD KIT 124 WATER SEAL RINGS PARTNER D.12 |
| 29 | 6.005.0134 | KIT 125 LW BRASS SEAL RINGS + SPACERS PT D.12 |
| 30 | 4.005.0211 | GUIDE BODY PISTON PT'03 W/SUCTION HOLE DET. |
| 31 | 5.006.0216 | ENGINE '03 D110H100 230-240/50 (WIRES W/TERM.FKX) |
| 32 | 5.007.0187C | EXT GUIDE BODY PT'03 PIST.D.12 W/ TS-ASP.-VALV.COMP.-M.13KG |
| 33 | 5.008.0182C | HEAD PT'03 D.12 |
| 34 | 5.009.0716 | ASSEMBLY VALV.COMP. W/TS X PT'0 3 CABLE L=510 SPRING 13KG |
| Chassis Pag.2 | ||
| 1 | 4.008.0789 | TIGER-MACH PIPE SUPPORT |
| 2 | 4.013.0450 | FKX UPPER FAIRING -BLUE- RAL.5015 INJECTION |
| 3 | 6.005.0148 | 135 BLACK FKX TANK KIT WITH CAP |
| 4 | 4.008.0867 | HYDRO RIO HANDLE |
| 5 | 4.608.0180 | TEKNA4/RIO TANK CAP |
| 6 | 4.012.0150 | H05VV-F CABLE 3X1.5 MT.5.4 SCHUKO ANTI-SPLASH F/F |
| 7 | 6.005.0190 | EXT KIT 176 WHEELS + STUDS FOR RIO |
| 8 | 4.008.0868 | RIO NEUTRAL DETERGENT TANK |
| 9 | 4.008.0869 | HOLDER FOR RIO HYDRO |
| 10 | 4.618.0049 | EXT PIPE MT 8 SWIVEL CONNECTOR 3/8F WITH MAN. TYPE R1 1/4 210bar |
| 11 | 3.700.0036 | EXT GUN S'02C 3/8'-M22 |
| 12 | 6.002.0309 | EXT LANCE W/O COVER A/B 1.10-V- M22 HOT (MAX 220BAR 3200PSI) |
| 13 | 5.012.0222 | KIT FOR RIO (RAP.ATT.31000062) |
| 14 | 7.100.1726 | COVER +BOOKLET RIO/KAPPA A+CE LAVOR 7L A5 64F |
| Boiler Pag.3 | ||
| 1 | 4.007.0183 | NUT FOR NOZZLE HOLDER PIN FOR J ET FIRE '98 |
| 2 | 3.100.0075 | M 1/8 CONICAL F D.4 CURVED CONNECTOR COD.E2L39C02 |
| 3 | 4.012.0102 | BRUSH MOTOR CABLE L=850 SEC.0, ,75 IEC227-3/1979 W/O FAST. |
| 4 | 4.608.0145 | OIL DELIVERY PIPE RILSAN PARANA' L=540 |
| 5 | 4.005.0194 | FKX BOILER COVER (DECORATED) |
| 6 | 4.007.0303 | PIPE D.40 L=325 FE 37 PRE-ZINC TO |
| 7 | 4.008.1169 | FKX ELECTRIC BOX COVER PAINTED SILVER RAL.9006 MET. |
| 8 | 5.009.0213 | EXT SWITCH ASSEMBLY 0/1 + TRANSPARENT PROTECTION 12(10) |
| 9 | 3.002.0106 | SCREW SELF-TAPING TC-TC 3.9X16 UNI 69 54 ZNT |
| 10 | 3.404.0017 | CAPACITOR 25mF 450V D.39X94 F/M |
| 11 | 3.004.0002 | FLAT WASHER 4.3X9 Sp.0.8 ZNT UNI6592 |
| 12 | 3.405.0011 | TERMINAL BLOCK PA 32/6 |
| 13 | 4.008.0127 | MULTIPLE CABLE GLAND FIRE ELECTRIC BOX |
| 14 | 4.008.0446 | BASE ELECTRICAL BOX FKX |
| 15 | 3.403.0012 | ELECTRICAL BOARD 230/50 FKX |
| 16 | 3.002.0132 | SCREW SELF-TAPING TC-TC 3.5X9.5 UNI69 54 ZNT |
| 17 | 3.002.0080 | SCREW T.C. M4X12 TRILOBATE CUT . CR. ZNT |
| 18 | 3.004.0003 | ELECTRIC TOOTHED ROUND.EX.D.4X8 Sp0.5 OF N6798A ZNT |
| 19 | 4.008.0470 | FAN MOTOR COVER FKX |
| 20 | 4.007.0180 | TIE ROD FOR FIRE '98 BOILER M6X352 ZNT |
| 21 | 3.004.0010 | ELECTRIC TOOTHED ROUND.EX.D6X11 Sp0.7 OF N6798A ZNT |
| 22 | 3.003.0011 | NUT E. M6 MEDIUM UNI 5588 CL8 ZNT |
| 23 | 3.304.0005 | MOTOR FOR BURNER 230/50 COMP. OF FAN, FLANGE, CABLES, COVER (FKX) |
| 24 | 4.008.0658 | HEAT-RESISTANT FELT BOTTOM (FKX/PARANA') |
| 25 | 4.008.0450 | HEAT-RESISTANT RIGID BOTTOM (FKX) |
| 26 | 4.007.0158 | BOILER BOTTOM FOR NUOVA FIRE |
| 27 | 4.007.0200 | WASHER 20.2X26X3 Fe37 |
| 28 | 6.005.0319 | FITTING FOR COIL WITH NOZZLE HOLDER |
| 29 | 5.609.0260 | SAFETY VALVE G1/8 M D6 200BAR MTM (00036020) |
| 30 | 4.005.0186 | BOILER BASE FKX (DIESEL CAST) |
| 31 | 4.007.0185 | SPACER FOR FIXING CLAMP JET FIRE PUMP '98 |
| 32 | 3.004.0026 | FLAT WASHER D.4.3X12 ZNT UNI6593 |
| 33 | 3.002.0179 | SELF-THREADING SCREW TC-TC 3.9X50 ZNT. |
| 34 | 5.009.0686 | EXT TRANSF. ACC. 230-240/50-60 W/PIPETTE FKX-PARANA' + CABLE |
| 37 | 4.006.0187 | NOZZLE HOLDER PIN FOR FKX BOILER |
| 38 | 3.104.0008 | EXT DIESEL NOZZLE 0.60 60 H MONEL FILTER (HAGO) |
| 39 | 6.005.0307 | FKX DEFLECTOR WITHOUT ELECTRODES |
| 40 | 5.013.0027 | MOUTHPIECE HOLDER DISC FOR FKX |
| 41 | 4.604.0011 | COIL D.202 L=15mt FOR NUOVA FIRE |
| 42 | 5.013.0050 | RIO BOILER BODY W/PAINTED BRACKET |
| 43 | 5.009.0304 | PRESSURE REGULATION VALVE ASSEMBLY FOR ULKA PUMP (SPRING L=20) |
| 44 | 4.008.0465 | EXT BLACK ANTI-FUEL PVC PIPE D.9X6 L=280 |
| 45 | 3.002.0146 | TCEI SCREW 4X35 TRILOBATE ZNT |
| 46 | 3.099.0110 | CLAMP D.12 CLAMP PAS 012 FOR GAS PUMP FIXING. (S/SCREW) |
| 47 | 3.551.0014 | ULKA DIESEL PUMP EP 5 48W 230/50 W/OR R4 VITON |
| 48 | 5.611.0043 | EXT FKX DIESEL FILTER GROUP |
| 49 | 3.411.0001 | ELECTRIC GLASS TUBE Di.4 (VSM 040) |
| 50 | 4.608.0038 | RUBBER PROTECTION FOR FIRE THERMAL |
| 51 | 3.403.0003 | THERMAL PROTECTOR L01.080.05. 1000 UL CABLES L=1200 |
| 52 | 4.606.0002 | FLOW CONNECTOR WITH HOLE FOR THERM. |
| 53 | 4.007.0322 | FKX DELIVERY SLEEVE TUBE L=42 |
| 54 | 4.008.0449 | SOFT HEAT-RESISTANT SLEEVE 31X56 th.3 FKX |
| 55 | 5.001.0824 | MOTOP.PT'03 110h100 230-240/50 D.12 9'35 TS IN.1.7 (FKX) |
| 56 | 5.009.0611 | INLET EXTENSION W/SEAL |
| 58 | 4.008.0503 | HEAT RESISTANT CERAMIC FIBER BAND 120X635 THICKNESS 4 |
| 60 | 4.007.0256 | SHAPED SUPPORT FOOT FKX |
| 61 | 4.008.0748 | BOILER CLOSING LID FOR FKX REGULATION |
| 62 | 4.008.0749 | AIR REGULATION BUTTERFLY FOR FKX |
