Mountfield Spare Parts for Lawnmower HW531 PD (2016)
€7.82
Tax included
Mountfield Spare Parts for Lawnmower HW531 PD (2016)
We supply original Mountfield spare parts on offer at unbeatable prices, we are an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance or repair issues for Mountfield Self-Propelled Lawnmower HW531 PD (2016) - 294556843/M16.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Mountfield Spare Parts for Lawnmower HW531 PD (2016)
We supply original Mountfield spare parts on offer at unbeatable prices, we are an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance or repair issues for Mountfield Self-Propelled Lawnmower HW531 PD (2016) - 294556843/M16.
In the following table, look for the model of the Brushcutter and the respective parts of the code.
| Lawnmower MOUNTFIELD HW531 PD (2016) - 294556843/M16 pag.1 | ||
| # | Part Num. | Description |
| 1 | 322055264/0 | Lower cover |
| 2 | 322055265/0 | Upper cover |
| 3 | 322602026/0 | Control Button |
| 4 | 112728699/0 | SELF-TAPPING SCREW K60 x 22 |
| 5 | 125943004/0 | Screw |
| 6 | 122450477/0 | Spring |
| 7 | 322981471/1 | Fix plate |
| 8 | 112728697/0 | Screw |
| 9 | 322602027/0 | Lens |
| 10 | 322602028/0 | HEIGHT ADJUST DECAL |
| 11 | 112154510/0 | LOW SELF-LOCKING NUT M6 |
| 12 | 112523040/0 | WASHER M6 6.6 x 18 x 1.6 |
| 13 | 122517873/0 | Busch |
| 14 | 381003475/0 | REAR HEIGHT ADJUST LEVER To 31-August-2015 |
| 14 | 381003475/1 | REAR HEIGHT ADJUST LEVER From 01-September-2015 To 31-August-2017 |
| 14 | 381003475/2 | Height Adjust Lever From 01-September-2017 |
| 15 | 322778475/0 | HEIGHT ADJUST BRACKET |
| 16 | 112815270/0 | Screw |
| 17 | 122450480/0 | Spring |
| 18 | 322545152/0 | plate |
| 19 | 112728697/0 | SELF-TAP SCREW PT TORX K50 x 16 |
| 20 | 322778473/0 | Bracket To 31-August-2018 |
| 20 | 322778473/1 | Bracket From 01-September-2018 |
| 21 | 181003114/0 | GEARBOX |
| 22 | 122450478/0 | Spring |
| 23 | 381302883/0 | Front Wheel Axle To S / N 20BA2WBH076280 |
| 23 | 381302883/1 | Front Wheel Axle From S / N 20BA2WBH076281 |
| 24 | 381302889/0 | Rear Wheel Axle To S / N 20BA2WBH082521 |
| 24 | 381302889/1 | Rear Wheel Axle From S / N 20BA2WBH082522 |
| 25 | 135063902/0 | Belt From 01-September-2017 To 31-August-2018 |
| 25 | 135063902/1 | Belt From 01-September-2018 |
| 25 | 135064100/0 | Belt To 31-August-2017 |
| 26 | 119216035/0 | Ball Bearing |
| 27 | 122570134/0 | LEFT PINION GEAR |
| 28 | 122570133/0 | RIGHT PINION GEAR |
| 29 | 112608600/0 | CIRCLIP D=12 |
| 30 | 122753000/0 | PIN D=5.2 x 25.65 |
| 31 | 381002046/0 | HEIGHT ADJUST TIE BAR To S / N 20BA2WBH082521 |
| 31 | 381002046/1 | HEIGHT ADJUST TIE BAR To S / N 20BA2WBH082522 |
| 32 | 122519823/0 | Pin |
| 33 | 322785305/0 | Support To 31-August-2015 |
| 33 | 322785305/1 | Support From 01-September-2015 |
| 34 | 112728697/0 | Screw |
| 35 | 112436051/0 | plate |
| 36 | 112645708/0 | PIN D=6 x 20 |
| 37 | 322600145/0 | Wheel Protection NOT for Delta Hole wheels |
| 38 | 322600208/0 | Wheel protection |
| 39 | 122601909/0 | Pulley |
| 40 | 122450481/0 | Front Axle Lift Spring |
| Lawnmower MOUNTFIELD HW531 PD (2016) - 294556843/M16 pag.2 | ||
| 1 | 322500113/0 | FRONT DECK COVER |
| 2 | 112728697/0 | SELF-TAP SCREW PT TORX K50 x 16 |
| 3 | 112728699/0 | SELF-TAPPING SCREW K60 x 22 |
| 4 | 322055524/0 | FRONT PLASTIC INSERT [BLACK] To 31-December-2018 |
| 4 | 322055524/1 | FRONT PLASTIC INSERT From 01-January-2019 |
| 5 | 322226217/0 | Front panel Red Light Red |
| 5 | 322226221/0 | Front Top Cover Black |
| 5 | 322226242/0 | FRONT TOP COVER [RED] |
| 6 | 322393742/0 | FRONT HANDLE [BLACK] To 31-December-2018 |
| 6 | 322393742/1 | FRONT HANDLE [BLACK] From 01-January-2019 |
| 7 | 381004779/0 | STEEL DECK MP1 554-SD [RED] Side Discharge To 31-August-2016 |
| 7 | 381004794/0 | STEEL DECK MP1 554-SD [RED] Side Discharge From 01-September-2016 To 31-August-2018 |
| 7 | 381004856/0 | STEEL DECK MP1 554-SD GREYSide Discharge From 01-September-2018 |
| Lawnmower MOUNTFIELD HW531 PD (2016) - 294556843/M16 pag.3 | ||
| 1 | 322108315/0 | SIDE DISCHARGE FLAP [BLACK] |
| 2 | 322600309/0 | SIDE DISCHARGE DEFLECTOR [BLACK] |
| 3 | 122450456/0 | Spring |
| 4 | 112604896/0 | STARLOCK WASHER D=6 |
| 5 | 112727803/0 | SCREW TCB TORX M6 x 14 |
| 6 | 322806639/0 | FULCRUM BRACKET |
| 7 | 112154510/0 | LOW SELF-LOCKING NUT M6 |
| 8 | 122517869/1 | DEFLECTOR ROD |
| 9 | 118203853/0 | BLACK NUT CAP M6 |
| Lawnmower MOUNTFIELD HW531 PD (2016) - 294556843/M16 pag.4 | ||
| 1 | 381005195/0 | RIGHT HANDLE BRACKET To 31-August-2017 |
| 1 | 381005195/1 | RIGHT HANDLE BRACKET From 01-September-2017 To 31-August-2018 |
| 1 | 381005195/2 | RIGHT HANDLE BRACKET Black From 01-September-2018 |
| 2 | 381005197/0 | LEFT HANDLE BRACKET Black To 31-August-2017 |
| 2 | 381005197/1 | LEFT HANDLE BRACKET Black From 01-September-2017 To 31-August-2018 |
| 2 | 381005197/2 | LEFT HANDLE BRACKET Black From 01-September-2018 |
| 3 | 112727801/0 | SCREW TCB TORX M6 x 20 |
| 4 | 322545213/0 | FIXING PLATE |
| 5 | 322600310/0 | REAR DOOR (Not For Electric Start Models) |
| 6 | 381102204/0 | Rear conveyor assembly To S / N 19JA2WBH017664 |
| 6 | 381102204/1 | Rear conveyor ASSEMBLY From S / N 19JA2WBH017665 |
| 7 | 112728699/0 | SELF-TAPPING SCREW K60 x 22 |
| 8 | 322060271/0 | PROTECTION Mulching To 31-August-2015 |
| 8 | 322060271/1 | PROTECTION Mulching From 01-September-2015 To 31-August-2018 |
| 8 | 322060271/2 | PROTECTION Mulching From 01-September-2018 |
| 9 | 112728530/0 | SCREW To 31-August-2015 |
| 9 | 112728531/0 | SCREW From 01-September-2015 To 31-August-2016 |
| 9 | 112735645/0 | SCREW From 01-September-2016 |
| 10 | 112154510/0 | LOW SELF-LOCKING NUT M6 |
| 11 | 112815205/0 | SCREW |
| 12 | 112521330/0 | Washer |
| 13 | 119035000/0 | O-Ring |
| 14 | 112728697/0 | SCREW |
| 15 | 322034002/0 | Washing connection |
| 16 | 322140246/0 | MULCHING PLUG [MP1 55] |
| 18 | 122042073/0 | BUSH From 01-September-2018 |
| Lawnmower MOUNTFIELD HW531 PD (2016) - 294556843/M16 pag.5 | ||
| 1 | 381006739/1 | Upper Handle, Black without Sponge To 31-August-2017 |
| 1 | 381006739/2 | Upper Handle, Black without Sponge From 01-September-2017 |
| 1 | 381006745/1 | Upper Handle, side with sponge grip Black To 31-August-2017 |
| 1 | 381006745/2 | Upper Handle, side with sponge grip Black From 01-September-2017 To 31-August-2018 |
| 1 | 381006745/3 | Handle, Upper side Black with sponge grip Black From 01-September-2018 |
| 2 | 122430313/0 | PULL CORD GUIDE |
| 3 | 112521330/0 | Washer |
| 4 | 112154510/0 | LOW SELF-LOCKING NUT M6 |
| 5 | 118390020/0 | Cable clip |
| 6 | 181003363/1 | ENGINE BRAKE LEVER |
| 7 | 181030057/0 | ENGINE BRAKE CABLE L=1385 |
| 7 | 181030106/0 | ENGINE BRAKE CABLE |
| 8 | 112727788/0 | SCREW M6 x 55 |
| 9 | 112154510/0 | LOW SELF-LOCKING NUT M6 |
| 10 | 181003364/0 | CLUTCH DRIVE LEVER |
| 11 | 381030104/0 | CLUTCH DRIVE CABLE |
| 12 | 181005539/0 | Throttle cable |
| 13 | 381007563/0 | LOWER HANDLE Black To S / N SK8177202 |
| 13 | 381007563/1 | Lower Handle Black From S / N SK8177203 |
| 14 | 322399835/0 | HANDLE KNOB |
| 15 | 122131750/0 | NUT M8 |
| 16 | 322680016/0 | HANDLE FIXING WASHER |
| 17 | 381103350/0 | UPPER LOCK HANDLE LEVER [BLACK] |
| 18 | 381003253/0 | LOCKING HANDLE LEVER [BLACK] |
| Lawnmower MOUNTFIELD HW531 PD (2016) - 294556843/M16 pag.6 | ||
| 1 | 381007477/0 | WHEEL ASSEMBLY c/w BEARING D=210 |
| 2 | 119216035/0 | BEARING 6001 2RS (12 x 28 x 8) |
| 3 | 322110640/0 | HUB CAP D=200 [GREY] |
| 4 | 381007479/1 | DRIVE WHEEL ASSEMBLY D=280 To S / N 19JA2WBH009756 |
| 4 | 381007479/2 | DRIVE WHEEL ASSEMBLY D=280 From S / N 19JA2WBH009757 |
| 5 | 322110641/0 | DELTA HUB CAP D=280 [GREY] |
| 6 | 112728706/0 | SCREW |
| 7 | 322120115/0 | REAR WHEEL DRIVE GEAR Only for Self Propelled Models |
| Lawnmower MOUNTFIELD HW531 PD (2016) - 294556843/M16 pag.7 | ||
| 1 | 122465607/3 | BLADE BOSS With Pulley, Crankshaft Ø 22.2 To 31-December-2018 |
| 1 | 122465607/4 | BLADE BOSS With Pulley, Crankshaft Ø 22.2 From 01-January-2019 |
| 2 | 181004409/0 | MULCHING BLADE 55 MP1 |
| 3 | 112508125/0 | SPRING WASHER 28 x 10 x 1.5 To 31-December-2018 |
| 3 | 112508128/0 | SPRING WASHER From 01-January-2019 |
| 4 | 112523080/0 | WASHER M10 11 x 30 x 2.5 Only for 554 Models To 31-August-2016 |
| 4 | 322680021/0 | Washer Only for 554 Models From 01-September-2016 To 31-August-2019 |
| 4 | 322680021/1 | Washer Only for 554 Models From 01-September-2019 |
| 5 | 112735698/0 | HEX-HEAD SCREW 3/8" x 2" |
| 6 | 112139100/0 | WOODRUFF KEY 4 x 6.5 D=16 |
| 7 | 112735108/1 | TELF-FORM SCREW 3/8" x 10" UNC |
| Lawnmower MOUNTFIELD HW531 PD (2016) - 294556843/M16 pag.8 | ||
| 1 | 181006411/0 | GRASSCATCHER FRAME To 31-August-2019 |
| 1 | 181006411/1 | GRASSCATCHER FRAME From 01-September-2019 |
| 2 | 322557177/0 | FIXING PLATE |
| 3 | 112728697/0 | SELF-TAP SCREW PT TORX K50 x 16 |
| 4 | 122517884/0 | DEFLECTOR ROD |
| 5 | 181102349/0 | GRASSBAG MP1 50-55 [BLACK] without Logo |
| 6 | 381486039/0 | GRASSCATCHER TOP-FULL INDICATOR [BLACK] |
| 7 | 122450479/0 | DEFLECTOR SPRING |
| 8 | 322600308/0 | DEFLECTOR [BLACK] |
| 9 | 322109569/0 | DEFLECTOR SUPPORT [BLACK] |
| Lawnmower MOUNTFIELD HW531 PD (2016) - 294556843/M16 pag.9 | ||
| 1 | 112292102/0 | HEXAGON NUT M6 |
| 2 | 118550276/1 | RECOIL ASSEMBLY 140/160cc [WBE] |
| 3 | 118550274/0 | RECOIL HANDLE |
| 4 | 118550779/0 | RECOIL ROPE |
| 5 | 118550778/0 | RECOIL PULLEY & SPRING |
| 6 | 118550275/0 | RECOIL PAWL SET |
| 7 | 118550336/0 | Nut |
| 8 | 118550335/0 | Starter cup |
| 9 | 118550254/0 | FLYWHEEL FAN |
| 10 | 118550253/0 | FLYWHEEL |
| 11 | 118550774/0 | GUARD |
| 12 | 112791213/1 | SCREW M6 x 18 |
| 13 | 118550907/0 | BOLT |
| 14 | 118550301/0 | STUD |
| 15 | 118550255/1 | ELECTONIC IGNITION COIL |
| 16 | 112791500/0 | SCREW M6 x 25 |
| 17 | 118551274/0 | SPARK PLUG CAP |
| 18 | 118551288/0 | TENSION SPRING |
| 19 | 112791500/0 | SCREW M6 x 25 |
| 20 | 118551205/0 | FLYWHEEL BRAKE/STOP ASSEMBLY |
| 21 | 118550259/0 | THROTTLE CONTROL ASSEMBLY |
| 22 | 118550337/0 | CASING CLAMP |
| 23 | 118550338/0 | SCREW |
| 24 | 112791213/1 | SCREW |
| 25 | 118550260/0 | Spring |
| 26 | 118550266/0 | GOVERNOR ARM |
| 27 | 118550397/0 | GOVERNOR LINK |
| 28 | 118550263/0 | Spring |
| 29 | 118550264/0 | CHOKE CONTROL ROD |
| 30 | 118550390/0 | Carburetor |
| 31 | 118550738/0 | CARBURETOR GASKET |
| 32 | 118550737/0 | AIR FILTER ASSEMBLY |
| 33 | 118550257/0 | PAPER AIR FILTER |
| 34 | 118550739/0 | AIR FILTER COVER |
| 35 | 118550377/0 | BREATHER FUEL PIPE |
| 36 | 118550930/0 | STUD BOLT |
| 37 | 112292102/0 | HEXAGON NUT M6 |
| 38 | 118550929/0 | GASKET |
| 39 | 118550928/0 | CARBURETOR INSULATOR |
| 40 | 118550315/0 | STUD BOLT |
| 41 | 118550316/1 | FUEL TANK |
| 42 | 118550943/0 | FUEL TANK CAP |
| 43 | 118550806/0 | Nut |
| 44 | 118550314/0 | Fuel filter |
| 45 | 118550340/0 | Fuel pipe |
| 46 | 118551264/0 | Carburetor gasket |
| 47 | 118551266/0 | Carburetor gasket |
| 48 | 118550388/0 | CARBURETTOR FLOAT KIT |
| 49 | 118550389/0 | Repair kit |
| 50 | 118550805/0 | BOLT |
| 51 | 118550806/0 | Nut |
| 52 | 118550918/0 | PIPE CLIP |
| 55 | 118550408/0 | ENGINE ASSEMBLY 160cc WBE0701 |
| Lawnmower MOUNTFIELD HW531 PD (2016) - 294556843/M16 pag.10 | ||
| 1 | 112674550/0 | SCREW TE M6 x 30 |
| 2 | 118551208/0 | CRANKCASE COVER |
| 3 | 118550379/0 | OIL SEAL |
| 4 | 118550775/0 | RUBBER GROMMET |
| 5 | 118550312/1 | SPEED GOVERNOR |
| 6 | 118550380/1 | CRANKCASE GASKET |
| 8 | 118550283/0 | Washer |
| 9 | 118550271/0 | Camshaft |
| 10 | 118550385/0 | CRANKSHAFT |
| 11 | 118550288/0 | WOODRUFF KEY |
| 12 | 118550284/0 | CONNECTING ROD |
| 13 | 118551213/0 | Piston |
| 14 | 118550286/0 | PISTON RING SET |
| 15 | 118550280/0 | BALL BEARING |
| 16 | 118550936/0 | GOVERNOR ARM SHAFT |
| 17 | 118550291/0 | VALVE LIFTER |
| 18 | 118551251/0 | PUSH ROD |
| 19 | 118551212/0 | CYLINDER HEAD |
| 20 | 118550296/2 | CYLINDER HEAD COVER |
| 21 | 118551277/0 | SCREW M6 x 14 |
| 22 | 9400-0244-00 | SPARK PLUG [CHAMPION RC12YC] |
| 23 | 118550297/0 | SCREW |
| 24 | 118550298/0 | STUD BOLT |
| 25 | 118550270/0 | MUFFLER GASKET |
| 26 | 118550269/0 | MUFFLER |
| 27 | 118550268/1 | MUFFLER GUARD |
| 28 | 118550806/0 | Nut |
| 29 | 118550300/0 | OIL SEAL |
| 30 | 112674550/0 | SCREW TE M6 x 30 |
| 31 | 118550311/1 | OIL DIPSTICK ASSEMBLY |
| 32 | 118551210/0 | BREATHER CAP |
| 33 | 118551211/0 | BREATHER CHAMBER GASKET |
| 34 | 118550303/0 | PLATE |
| 35 | 118550273/0 | VALVE ARM SET |
| 36 | 118550910/0 | INTAKE/EXHAUST VALVE KIT |
| 37 | 118551300/0 | VALVE SPRING |
| 38 | 118550895/0 | RETAINER VALVE SPRING |
| 39 | 118551253/0 | PLATE |
| 43 | 112790500/0 | HEX-HEAD SCREW M6 x 10 |
| 44 | 118550935/0 | OIL SEAL |
| 45 | 118550856/0 | LOCK PIN |
| 46 | 118551237/0 | Cylinder Head Gaskets |
| 47 | 118551233/0 | CYLINDER GASKET |
| 48 | 118551269/0 | HOLDER PLATE |
| 49 | 118550915/0 | Piston pin |
| 50 | 118550914/0 | PISTON PIN CLIP |
| Lawnmower MOUNTFIELD HW531 PD (2016) - 294556843/M16 pag.11 | ||
| 1 | 322055463/1 | ENGINE BASE COVER [BLACK] |
| 3 | 322055452/0 | TOP ENGINE COVER [BLACK-OBLONG] |
| 4 | 322055450/0 | TOP ENGINE COVER [BLACK-OBLONG] |
| 5 | 322055439/0 | TOP ENGINE COVER [BLACK-ROUND] |
| 6 | 381002068/0 | ENGINE COVER [BLACK/RED] |
| 7 | 381002067/0 | ENGINE COVER [BLACK/YELLOW] |
| 8 | 112728680/0 | FLANGED SCREW D=5 x 25 |
| 10 | 322055516/0 | TOP ENGINE COVER [GREY] |
| 11 | 112728099/1 | SELF-TAPPING SCREW 4.2 x 16 |
| 12 | 322055517/0 | ENGINE BASE COVER [YELLOW] |
| 12 | 322055552/0 | ENGINE BASE COVER BLACK |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Castelgarden websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Castelgarden brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
HW531 PD (2016) - 294556843/M16
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10/15 BUSINESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N ALPINA:
- STIGA GROUP S/N START WITH (1 or 2) and have 9 DIGITS
New
You might also like
Comments (0)
No customer reviews for the moment.
Viewed products
Customers who bought this product also bought:
16 other products in the same category:
Mountfield Spare Parts for Lawnmower HW531 PD (2016)
We supply original Mountfield spare parts on offer at unbeatable prices, we are an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance or repair issues for Mountfield Self-Propelled Lawnmower HW531 PD (2016) - 294556843/M16.
