Mountfield Spare Parts for Lawnmower SP 41 (2017)
€80.50
Tax included
Mountfield Spare Parts for Lawnmower SP 41 (2017)
We supply original Mountfield spare parts on offer at unbeatable prices, we are an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance or repair issues for Mountfield Self-Propelled Lawnmower SP 41 (2017) 297412048/M17.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Mountfield Spare Parts for Lawnmower SP 41 (2017)
We supply original Mountfield spare parts on offer at unbeatable prices, we are an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance or repair issues for Mountfield Self-Propelled Lawnmower SP 41 (2017) 297412048/M17.
In the following table, look for the model of the Brushcutter and the respective parts of the code.
| PETROL LAWNMOWER MOUNTFIELD SP 41 (2017) 297412048/M17 | ||
| Deck Pag.1 | ||
| # | Part Num. | Description |
| 1 | 322066750/0 | PLASTIC DECK [RED] EP414 |
| 1 | 322066752/0 | PLASTIC DECK [DARK RED] EP414 |
| 2 | 322060245/0 | BELT PROTECTION GUARD EP41 |
| 3 | 112154210/0 | SELF-LOCK WINGED NUT M8 |
| 5 | 322785361/0 | SUPPORT PLATE |
| 6 | 322735599/0 | HEIGHT ADJUST QUADRANT |
| 7 | 381003352/0 | HEIGHT ADJUST LEVER |
| 8 | 381005089/0 | WHEEL STUB AXLE To 31-August-2016 |
| 8 | 381005163/0 | WHEEL STUB AXLE From 01-September-2016 |
| 9 | 122519811/0 | WHEEL BOLT |
| 10 | 112521350/0 | WASHER M8 8.4 x 16 x 1.6 |
| 11 | 112155000/0 | LOW SELF-LOCKING NUT M8 |
| 12 | 112728690/0 | SELF-TAP SCREW KA50 x 25 |
| 13 | 322608563/0 | REAR BRACKET |
| 15 | 381003353/0 | HEIGHT ADJUST LEVER |
| 16 | 112728689/0 | CREW KA50 x 12 |
| 17 | 322735601/0 | HEIGHT ADJUST QUADRANT |
| 18 | 112728690/0 | SELF-TAP SCREW KA50 x 25 |
| 19 | 122033417/0 | REAR WHEELS AXLE |
| 20 | 122753001/0 | PIN D=4 x 32 |
| 21 | 112608600/0 | CIRCLIP D=12 |
| 22 | 112521370/0 | WASHER M12 13 24 X 2.5 |
| 23 | 322570135/0 | RIGHT PINION GEAR |
| 24 | 119216035/0 | BEARING 6001 2RS (12 x 28 x 8) |
| 25 | 322785379/0 | AXLE SUPPORT PLATE |
| 26 | 322600203/0 | INNER WHEEL COVER D=175 |
| 27 | 322570136/0 | LEFT PINION GEAR |
| 28 | 322120118/0 | PLASTIC DRIVE GEAR D=175 |
| 29 | 112523040/0 | WASHER M6 6.6 x 18 x 1.6 |
| 30 | 112735592/0 | SELF-TAP SCREW M6 x 20 |
| 31 | 322686101/0 | WHEEL c/w BUSH D=175mm To 31-August-2018 |
| 31 | 381007475/0 | WHEEL c/w BUSH D=175mm From 01-September-2018 |
| 32 | 322034516/0 | WHEEL BUSH D=175 |
| 33 | 322110642/0 | HUB CAP D=175 [GREY] |
| 34 | 322686100/0 | DELTA WHEEL D=175 Ø 175 |
| Handle, Lower Part Pag.2 | ||
| 1 | 381006769/0 | R/H-L/H LOWER HANDLE [BLACK] |
| 2 | 112523020/0 | WASHER M5 5.5 x 15 x 1.6 |
| 3 | 112728450/0 | SELF-TAP SCREW 4.8 x 19 |
| 4 | 112819110/0 | CARRIAGE BOLT M8 x 50 |
| 5 | 118566110/0 | HANDLE CAP D=22 [BLACK] |
| 6 | 122671651/0 | WASHER 8.3 x 22 x 2 |
| 7 | 122399900/0 | 3 SPOKE HANDWHEEL [BLACK] |
| 8 | 112293200/0 | Nut |
| 10 | 381008687/0 | HANDLE SCREWS KIT |
| Handle, Upper Part Pag.3 | ||
| 1 | 381006739/0 | UPPER HANDLE [BLACK] without Sponge To 31-August-2011 |
| 1 | 381006739/1 | UPPER HANDLE [BLACK] without Sponge From 01-September-2011 To 31-August-2017 |
| 1 | 381006739/2 | UPPER HANDLE [BLACK] without Sponge From 01-September-2017 |
| 2 | 122430313/0 | PULL CORD GUIDE |
| 3 | 112521330/0 | WASHER M6 (6.4 x 12 x 1.6) |
| 4 | 112154510/0 | LOW SELF-LOCKING NUT (M6) |
| 5 | 118390020/0 | CABLE CLIP |
| 6 | 181030079/0 | ENGINE BRAKE CABLE L=995 Honda / B & S / GGP 100cc |
| 7 | 181003363/0 | ENGINE BRAKE LEVER Black To 31-August-2011 |
| 7 | 181003363/1 | ENGINE BRAKE LEVER Black From 01-September-2011 |
| 8 | 112727783/0 | CROSS-HEAD SCREW M6 x 40 |
| 9 | 322551640/0 | CABLE HOLDER BLOCK To S/N 20AA2WBH066503 |
| 9 | 322551685/0 | CABLE HOLDER BLOCK ø22 From S/N 20AA2WBH066504 |
| 10 | 112154510/0 | LOW SELF-LOCKING NUT (M6) |
| Transmission Pag.4 | ||
| 1 | 181003108/0 | GEARBOX [BLACK] |
| 2 | 112645705/0 | ROLL PIN D=5 x 32 ø5X32 |
| 3 | 122601909/0 | Pulley |
| 4 | 135063730/0 | TRAPEZOIDAL BELT Z26 |
| 5 | 122753000/0 | PIN D=5.2 x 25.65 |
| 6 | 125430216/0 | TENSION SPRING From 01-September-2017 |
| 6 | 125430216/1 | TENSION SPRING To 31-August-2010 |
| 6 | 125430217/0 | TENSION SPRING From 01-September-2010 To 31-August-2017 |
| Blade Pag.5 | ||
| 1 | 1111-9120-01 | BLADE BOSS Stiga Packed into 122465607/4 |
| 1 | 122465607/3 | BLADE BOSS D=22.2mm To 31-December-2018 |
| 1 | 122465607/4 | BLADE BOSS D=22.2mm Ø 22.2 From 01-January-2019 |
| 2 | 181004152/0 | WINGED BLADE D.390 To 31-August-2011 |
| 2 | 181004360/3 | Mulching blade From 01-September-2011 |
| 3 | 122160400/0 | SPRING WASHER 50 x 2 x 10.2 |
| 4 | 112523080/0 | WASHER M10 11 x 30 x 2.5 |
| 5 | 112735698/0 | HEX-HEAD SCREW 3/8" x 2" |
| 6 | 112139100/0 | WOODRUFF KEY 4 x 6.5 D=16 |
| 7 | 112691910/0 | HEX-HEAD SCREW (M8 x 65) |
| 8 | 112523060/0 | WASHER M8 8.4 x 24 x 2 |
| 9 | 122167842/0 | Spacer From 01-September-2010 |
| 10 | 112154210/0 | SELF-LOCK WINGED NUT M8 |
| 11 | 122040265/0 | MOTOR BUSH |
| Grass-Catcher Pag.6 | ||
| 1 | 322600212/0 | DEFLECTOR [BLACK] |
| 2 | 122450467/0 | DEFLECTOR SPRING |
| 3 | 122517870/0 | DEFLECTOR ROD |
| 4 | 181006420/0 | GRASSCATCHER FRAME To 31-August-2019 |
| 4 | 181006420/1 | GRASSCATCHER FRAME From 01-September-2019 |
| 5 | 181002320/0 | GRASSBAG [BLACK] |
| Engine - Carburettor, Tank Pag.7 | ||
| 1 | 118550693/0 | RECOIL ASSEMBLY 100cc |
| 2 | 118550694/0 | RECOIL HANDLE |
| 4 | 118550695/0 | RECOIL PULLEY AND SPRING |
| 5 | 118550696/0 | STARTER PAWL SET |
| 6 | 118550713/0 | LONG STUD BOLT |
| 7 | 118550714/0 | STUD BOLT |
| 8 | 112689515/0 | HEX-HEAD SCREW M6 x 45 |
| 9 | 118550712/0 | FUEL TANK |
| 10 | 118550711/0 | FUEL TANK CAP |
| 11 | 118550715/0 | FUEL FILTER |
| 12 | 118550716/0 | FUEL TUBE |
| 13 | 118550697/0 | CARBURETTOR |
| 14 | 118550706/0 | STUD |
| 15 | 112292102/0 | HEXAGON NUT M6 WITH EXAGONAL FLANGE |
| 16 | 118550702/0 | AIR CLEANER ASSEMBLY |
| 17 | 118550704/0 | FOAM AIR FILTER |
| 18 | 118550703/0 | AIR FILTER COVER |
| 19 | 118550698/0 | PRIMER PUMP |
| 20 | 118550705/0 | BREATHER FUEL PIPE |
| 21 | 112292102/0 | HEXAGON NUT M6 WITH EXAGONAL FLANGE |
| 21 | 112292102/0 | HEXAGON NUT M6 WITH EXAGONAL FLANGE |
| 22 | 118550710/0 | STUD BOLT |
| 23 | 112735699/0 | SCREW M6 x 12 |
| 24 | 118550709/0 | MUFFLER GUARD |
| 25 | 118550708/0 | MUFFLER |
| 26 | 118550707/0 | MUFFLER GASKET |
| 31 | 118550719/0 | IGNITION COIL |
| 32 | 112792099/0 | HEX HEAD SCREW M6 x 30 |
| 33 | 118550658/0 | SPARK PLUG [K7RTC] |
| 35 | 118550720/0 | THROTTLE VALVE SPRING |
| 36 | 118550721/0 | GOVERNER ROD |
| 38 | 118550732/0 | ENGINE 100cc OHV [RS100] |
| 98 | 322055521/0 | ENGINE RING COVER RS100 [GREY] |
| 99 | 322055518/0 | ENGINE RING COVER RS100 [YELLOW] |
| 99 | 381002079/0 | ENGINE COVER RS100 [BLACK] |
| Engine - Piston, Crankshaft Pag.8 | ||
| 39 | 118550728/0 | BRAKE/STOP SWITCH ASSEMBLY |
| 40 | 118550727/0 | Spring |
| 41 | 118550717/0 | FLYWHEEL NUT |
| 42 | 118550718/0 | FLYWHEEL ASSEMBLY |
| 43 | 118550661/0 | OIL SEAL |
| 44 | 118550729/0 | CYLINDER HEAD ASSEMBLY |
| 45 | 112735699/0 | SCREW M6 x 12 |
| 46 | 118550659/0 | Cover |
| 47 | 118550733/0 | Gasket, breath groove |
| 48 | 118550660/0 | OIL FILTER |
| 49 | 118550680/0 | CYLINDER HEAD GASKET |
| 50 | 118550681/0 | CYLINDER HEAD COVER |
| 51 | 112735699/0 | SCREW M6 x 12 |
| 52 | 112791500/0 | SCREW M6 x 25 |
| 53 | 118550672/0 | CRANKCASE COVER |
| 54 | 118550668/0 | OIL SEAL |
| 55 | 118550669/0 | OIL DIPSTICK ASSEMBLY |
| 56 | 118550670/0 | O RING |
| 57 | 118550664/0 | Pin |
| 61 | 118550674/0 | CRANKSHAFT |
| 62 | 118550673/0 | WASHER |
| 63 | 118550675/0 | CONNECTING ROD |
| 64 | 118550678/0 | Circlip + Piston Pin |
| 65 | 118550677/0 | PISTON ASSEMBLY |
| 66 | 118550679/0 | PISTON RING SET |
| 67 | 118550682/0 | CAMSHAFT |
| 68 | 112735699/0 | SCREW M6 x 12 |
| 69 | 118550662/0 | SPEED GOVERNOR ASSEMBLY |
| 70 | 118550665/0 | GOVERNOR ARM SHAFT |
| 71 | 118550666/0 | Washer |
| 72 | 118550671/0 | Gasket |
| 73 | 118550723/0 | SUPPORT GOVERNOR |
| 74 | 118550726/0 | Screw |
| 75 | 118550722/0 | Nut |
| 76 | 118550667/0 | Cotter pin |
| 77 | 118550683/0 | TAPPET VALVE |
| 78 | 118550684/0 | LIFTER VALVE |
| 79 | 118550685/0 | Plate |
| 80 | 118550686/0 | VALVE ADJUSTING BOLT |
| 81 | 118550687/0 | Rocker Valves |
| 82 | 118550688/0 | Nut |
| 83 | 118550689/0 | Nut |
| 85 | 118550724/0 | Plate |
| 86 | 112735699/0 | SCREW M6 x 12 |
| 87 | 118550725/0 | GOVERNOR SPRING |
| 89 | 112791500/0 | SCREW M6 x 25 |
| 90 | 112735699/0 | SCREW M6 x 12 |
| 91 | 118550692/0 | EXHAUST VALVE |
| 92 | 118550691/0 | INTAKE VALVE |
| 93 | 118550690/0 | SPRING |
| 94 | 118550699/0 | CARBURETTOR GASKET KIT |
| 95 | 118550731/0 | CYLINDER HEAD GASKET KIT |
| 96 | 118550730/0 | ENGINE GASKET SET |
