Metabo Spare Parts for Rotary Hammer KHE 2851
€1.82
Tax included
Metabo Spare Parts for Rotary Hammer KHE 2851
Metabo original spare parts for to replace broken parts for to fix Rotary Hammer KHE 2851 - 00657000.Fix Your Rotary Hammer. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Metabo Spare Parts for Rotary Hammer KHE 2851
Fix your Rotary Hammer KHE 2851 - 00657000 All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of the Drill and the respective parts of the code.
| Combination Hammer KHE 2851/00657000 | ||
| # | Part NUm. | Description |
| 1 | 31605100 | Adaptor SDS -PLUS |
| 2 | 14319516 | Shaft sealing ring |
| 3 | 14311509 | Needle sleeve,30x37x16 |
| 4 | 33900715 | Washer |
| 5 | 34200349 | Pressure spring,34,7x38,3x1,8x27,7 |
| 6 | 34339782 | Retaining ring |
| 7 | 31604784 | Gear housing compl. |
| 8 | 34000403 | Sliding block |
| 9 | 14115638 | Circlip |
| 10 | 34101306 | Support ring |
| 11 | 34207062 | Cup spring |
| 12 | 31606406 | Ratched wheel set |
| 14 | 34343100 | Support ring |
| 15 | 14115636 | Circlip |
| 16 | 31604785 | Drill driving sleeve cpl. |
| 17 | 14319520 | Shaft sealing ring |
| 18 | 34100581 | Bushing |
| 19 | 34105903 | Piston |
| 20 | 34101298 | Support ring |
| 21 | 14319515 | O-ring |
| 22 | 33900719 | Washer |
| 23 | 14319521 | O-ring |
| 24 | 34105895 | Catching sleeve |
| 25 | 14118184 | Circlip |
| 26 | 34409314 | Sealing ring |
| 27 | 31604335 | Striker compl. |
| 28 | 34105868 | exciter sleeve compl. |
| 29 | 32005048 | Ball holder |
| 30 | 34409864 | Seal |
| 31 | 31604786 | Gear flange cpl. |
| 32 | 34407067 | Felt seal |
| 33 | 34409592 | Rubber buffer |
| 34 | 14112340 | Filister head screw |
| 35 | 14112361 | Self-tap. fill. h. screw |
| 36 | 31604447 | Control knob compl. |
| 37 | 34337675 | Seal |
| 38 | 33912961 | Washer |
| 39 | 14311428 | Axial needle bearing |
| 40 | 14115255 | Cup spring |
| 41 | 31604788 | Pinion shaft compl. |
| 42 | 33913435 | guide sheet |
| 43 | 31604446 | Shift element compl. |
| 45 | 34170336 | Cap screw |
| 46 | 31605087 | Keyless chuck w.adaptor |
| 47 | 31605088 | Quick-change adaptor |
| 48 | 31605227 | Side support handle compl. |
| 49 | 34337604 | Sealing ring |
| 50 | 33000183 | Fan |
| 51 | 31000927 | Armature compl.,230 V (w. tacho gen.) |
| 52 | 14319243 | O-ring |
| 53 | 33805493 | Rating plate |
| 54 | 34308414 | Electronic unit,230V 50/60Hz |
| 55 | 14111699 | Self-tap. fill. h. screw |
| 56 | 14111602 | Self-tap fill h screw |
| 57 | 34339853 | Pistol grip 2-part, gummed |
| 58 | 14311488 | Ball bearing, 8x22x7 |
| 59 | 14311517 | Ball bearing,6x19x6 |
| 60 | 34339977 | Intermediate flange |
| 61 | 34152023 | Cylindrical pin |
| 62 | 14111826 | Self-tap. fill. h. screw |
| 63 | 31100981 | Field coil 230V |
| 64 | 31501325 | Motor housing |
| 66 | 31605196 | Brush holder module,230V |
| 67 | 31604697 | Carbon brush set,230 V |
| 68 | 34340925 | Poti switch |
| 69 | 14111706 | Self-tap. fill. h. screw |
| 70 | 34336249 | Cable clip |
| 71 | 34339430 | Cable sleeve |
| 72 | 34448673 | Cord with plug |
| 73 | 31604789 | Maintenance kit |
| 880 | 34413080 | Grease FG 126 |
| 890 | 34413121 | Tube Grease,50g Klueber Microlube GL 261 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Metabo websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Metabo brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Metabo KHE 2851 - 00657000
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N METABO:
- METABO S/N START WITH ( 0 ) and have 8 DIGITS
