Maruyama Hedge Cutter HT237D Parts
search
  • Maruyama Hedge Cutter HT237D Parts
  • Maruyama Hedge Cutter HT237D Parts Diagram
  • Maruyama Hedge Cutter HT237D Parts Diagram - 1
  • Maruyama Hedge Cutter HT237D Parts Diagram - 2
  • Maruyama Hedge Cutter HT237D Parts Diagram - 3

Maruyama Hedge Cutter HT237D Parts

€144.66
Tax included

Maruyama Parts for Hedge Cutter MX55

Fix Your Hedge Cutter Maruyama MX55. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
ITEM CODE: 271226
Quantity
Usually Ships in: 10/15 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Maruyama Parts for Hedge Cutter HT237D

Fix Your Hedge Cutter Maruyama HT237D. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following tables, look for the spare part and its respective code.
Hedge Cutter Maruyama HT237D

Maruyama Hedge Cutter HT237D Parts
Main Body Pag.1
# Part. Num. Description
1-1 362426 HT237D
1-2 271226 Guide Plate
1-3 270682 Blade
1-4 274877 Blade Guard
1-5 991914 Screw
1-6 271229 Screw
1-7 991913 Washer
1-8 991941 U-Nut
1-9 217677 Cover of Blade
1-10 271396 Rear Handle Ass'y Incl.11-29
1-11 271278 Rear Handle (L)
1-12 271279 Rear Handle (R)
1-13 271280 Lever,Throttle
1-14 271281 Stop Lever
1-15 271282 Lock Lever
1-16 271283 Lock Lever Stopper
1-17 271284 Rod
1-18 271285 Switch
1-19 271398 Cable Comp
1-20 271287 Spacer
1-21 271288 Spring
1-22 271289 Spring
1-23 270400 Spring
1-24 271276 Screw
1-25 271274 Handle Stay (L)
1-26 271275 Handle Stay (R)
1-27 271276 Screw
1-28 270424 Spacer
1-29 271277 Spacer
1-30 270566 Label
1-31 287394 Label
1-32 271221 Tube
1-33 271908 Screw
1-34 277400 Screw
1-35 271909 Screw
1-36 271911 Screw
1-37 270843 Washer
1-38 271222 Upper Case
1-39 271410 Pinion
1-40 270021 Clutch Drum
1-41 270423 Bearing
1-42 580767 Bearing
1-43 266959 Label
1-44 266960 Label
1-45 991937 Grease Nipple
1-46 271223 Lower Case
1-47 271224 Plate
1-48 991924 Screw
1-49 270423 Bearing
1-50 270552 Crank Comp
1-51 271225 Rod Ass'y
1-52 271227 Felt
1-53 271895 Screw
1-54 271910 Screw
1-55 991941 U-Nut
1-56 580777 Snap Ring
1-57 278303 Front Handle Ass'y
1-58 266957 Label
Engine Pag.2
2-1 875089 Engine
2-2 278641 Cylinder
2-3 289643 Gasket
2-4 267290 Cap Screw
2-5 272744 Insulator
2-6 267049 Gasket
2-7 265924 Cap Screw
2-8 278263 Muffler Comp
2-9 266402 Cap Screw
2-10 278273 Gasket
2-11 278264 Tail Pipe Comp
2-12 278288 Cylinder Cover Ass'y Incl.13-15
2-13 277793 Cylinder Cover
2-14 286399 Knob
2-15 286270 Washer
2-16 278210 Muffler Cover Comp
2-17 261607 Cap Screw
2-18 278208 Crankcase
2-19 261181 Bearing
2-20 262712 Oil Seal
2-21 262713 Oil Seal
2-22 054676 Snap Ring
2-23 261246 Cap Screw
2-24 272204 Piston
2-25 264891 Piston Ring
2-26 261036 Piston Pin
2-27 288520 Bearing, Needle
2-28 261576 Clip,Piston
2-29 283155 Shaft Comp
2-30 280404 Clutch Ass'y Incl.31-33
2-31 280568 Clutch Shoe
2-32 280569 Clutch Boss
2-33 280570 Spring
2-34 278161 Magneto Ass'y Incl.35-41
2-35 278176 Rotor/Fan
2-36 278293 Ignition Coil Ass'y Incl.37-41
2-37 278367 Spark Plug Wire Ass'y Incl.38,39
2-38 282292 Plug Boot
2-39 261075 Connector
2-40 261072 Cap
2-41 280080 Insulator
2-42 280936 Ratchet
2-43 285552 Spring
2-44 020299 E-Ring
2-45 267492 Lead
2-46 261076 Woodruff Key
2-47 261077 Nut,Rotor
2-48 280381 Spacer
2-49 278831 Cap Screw
2-50 288264 Spark Plug
2-51 278294 Grommet
2-52 278207 Starter Ass'y Incl.53-59
2-53 278693 Pulley
2-54 280931 Spiral Spring
2-55 262922 Screw
2-56 283291 Rope Ass'y Incl.57-59
2-57 283292 Starter Rope
2-58 261725 Starter Grip
2-59 283293 Rope Stopper
2-60 267290 Cap Screw
2-61 278300 Label
2-62 267191 Cap Screw
Carburetor - Fuel Tank Pag.3
3-1 278297 Carburetor Ass'y Incl.2-15
3-2 268499 Pump Body
3-3 262991 Purge Body
3-4 262992 Cover Plate
3-5 261874 Primer Bulb
3-6 283905 Diaphragm, Meterring
3-7 262993 Gasket
3-8 262994 Diaphragm,Fuel Pump
3-9 282576 Gasket
3-10 289396 Main Jet
3-11 261871 O-Ring
3-12 261876 E-Ring
3-13 261658 Swivel
3-14 264682 Screw
3-15 262996 Screw
3-16 268535 Stay
3-17 278750 Gasket
3-18 278090 Cleaner Ass'y Incl.19-21
3-19 265576 Housing
3-20 264695 Filter
3-21 278760 Cleaner Cover
3-22 261117 Clip
3-23 268963 Gasket
3-24 280102 Screw
3-25 278209 Fuel Tank Ass'y Incl.26-36
3-26 277791 Fuel Tank
3-27 283438 Tank Cap Ass'y Incl.28,29
3-28 283727 Gasket
3-29 283764 Breather Ass'y
3-30 265752 Fuel Pipe Pick-up Ass'y Incl.31-36
3-31 264031 Fuel Pipe Ass'y Incl.32-34
3-32 261115 Grommet
3-33 261690 Fuel Pipe
3-34 263038 Return Pipe
3-35 264653 Filter Ass'y
3-36 261117 Clip
3-37 269690 Cap Screw
Accessories Pag.4
4-1 278278 Instruction Manual
4-2 278279 Instruction Manual I
4-3 278280 nstruction Manual
4-4 524392 Parts List
4-5 264606 Tool Set Incl.6-8
4-6 264607 Box Spanner
4-7 219431 Wrench
4-8 219432 Wrench
