Makita Spare Parts for Magnetic Drill HB500

€34.02
Tax included

Makita Spare Parts for Magnetic Drill HB500

Makita genuine spare parts for the repair or replacement of Magnetic Drill BH500.
- Magnetic force 907 Kg
- For drilling steel and metals in general in metallic carpentry and construction
ITEM CODE: EIB202
Quantity
on 7/10 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Makita Spare Parts for Magnetic Drill HB500

Makita genuine spare parts for the repair or replacement of Magnetic Drill BH500.
- Magnetic force 907 Kg
- For drilling steel and metals in general in metallic carpentry and construction

In the following table, look for the model of Magnetic Drill and the respective parts of the code.
Makita HB500
Magnetic Drill HB500
1 EIB202 BACK COVER
2 EIB101 SCREW 4,8X38
3 EIB102-2 ARMATURE
4 UDC022 BEARING 608 2Z
5 EIB042 RETAINING RING R28
6 EIB105 BRUSH HOLDER
7 EIB106C CARBON BRUSHES
8 EIB172 SPRING WASHER B4
9 EIB108 SCREW M4X12
10 EIB152 PLATE
11 EIB143 RETAINING RING R11
12 EIB111 RING 22
13 EIB157 SCREW 4,8X50
14 UDC023 BEARING 6001 2Z
15 EIB205 COVER HOUSING INPUT.
16 EIB204 GEAR HOUSING
17 EIB117 GEAR 34
18 EIB007 POST 11-17
19 EIB017 LEVER SPEED '
20 EIB008 CURSOR CHANGE
21 EIB120 PIN 4X12
22 UDC014 BEARING 6203 RS
23 EIB122 POST
24 EIB034A WASHER 5X5X12
26 EIB125 POWER CABLE
28 EIB126 SEAL CARCASS enlarged.
29 EIB083 PROTECTION
32 EIB004 GEAR 45
34 EIB076 WASHER 15X22X0,2
35 EIB130 RETAINING RING R15
36 EIB131 POST 13
38 EIB132 GEAR 34-40
39 EIB034 KEY 5X5X28
40 UDC020 ROLLER BEARING HK0810
42 EIB135 BAFFLE
43 EIB136 SCREW 3,9X60
44 EIB137-B STATOR
45 EIB203 HOUSING MOTOR
46 EIB139 CAPACITOR
49 EIB206 WASHER 3.2
50 EIB153 SCREW 2,9X9,5
51 EIB085 STOPS CABLE
1 M0034 MAGNETIC BASE
2 20348 BODY SUPPORT
3 M0081 SOCKET
4 M0042 SHAFT
5 M0072 CORK SHAFT
6 SC620CAP SCREW M6X20
7 60100A PLATE
8 20389 PLATE
9 10081 PIVOT KNOB
10 10082 KNOB
11 10084 TOP PLATE
12 SC615CAP SCREW M6x15
13 20305M SWITCH PANEL
14 10215 RACK
15 30046A OIL TANK
16 10076C SUPPORT TANK
18 10085A SCREW M5X25
19 10085B NUT M5
20 10231 FITTING M16
21 40026 FITTING M16
22 BD062 CHUCK
23 M0167 SLIDE
24 M0516 SUPPORT SLIDE
26 M0050-2 SEAL
27 M0521 SOCKET
28 M0050-1 SEAL
29 M0066 SOCKET 6
30 SC630CAP SCREW M6X30
31 MM1-5G PRINTED CIRCUIT
32 MM1-4M LED CIRCUIT
33 MM1-22 GREEN BUTTON
34 MM1-17 PLATE PCB
35 MM1-1 YELLOW BUTTON
36 MM1-10 RED BUTTON
37 MM1-3 SEAL LED
38 SC510BUT SCREW M5X16
39 50015C FITTING 1 / 8-6
40 BD029 OIL PIPE
41 M0443 TUBE 12
42 VISO15 PROTECTION
43 10094 WASHER 6
44 BD068 SCREW M5x10
45 NWP-04 PLATE
46 RIVET 2MM RIVETTO 2
47 BD046 NUT
48 TORX KNOB TORX
