Makita Spare Parts for Miter Saw 2414NB
search
  • Makita Spare Parts for Miter Saw 2414NB
  • Makita Spare Parts for CUT-OFF Machine 2414NB

Makita Spare Parts for CUT-OFF Machine 2414NB

€1.25
Tax included

Makita Spare Parts for CUT-OFF Machine 2414NB

We are MAKITA original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you to purchase the most suitable spare part to quickly solve any maintenance or repair issues for Makita 2414NB.
ITEM CODE: 911333-7
Quantity
Usually Ships in: 7/10 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Makita Spare Parts for CUT-OFF Machine 2414NB

We are MAKITA original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you to purchase the most suitable spare part to quickly solve any maintenance or repair issues for Makita 2414NB.

In the following table, look for the model of the hammerr and the respective parts of the code.
.

CUT-OFF MACHINE Makita 2414NB
2 911333-7 SCREW M6 X 20
3 224299-5 FLANGE INTERNAL 90 2414B
4 251680-7 BOLT C / BORDINO 10X25
5 344662-7 COVER CENTRAL
6 251887-5 BUTTERFLY SCREW M6x10
7 265121-7 SCREW M 6 X MT240
8 182628-7 HANDLE COMPLETE
9 651922-3 SWITCH TG71B
10 152463-7 LEVER SWITCH CPL
11 415366-9 ROCKER
12 231397-8 SPRING COMPRESSION 4
13 281207-9 BRACKET
14 256012-3 PIN
15 411478-6 BUTTON SWITCH
16 213162-7 SEAL 14
17 257185-5 RING 17
18 224299-5 INTERNAL FLANGE 90
19 257185-5 RING 17
20 265995-6 SCREW M4X18
21 165232-7 PROTECTION BLADE
22 211282-1 BEARING 6203ZZ X MT240
23 316527-3 BEARING
24 226415-5 GEAR 41
25 322633-4 POST
26 210067-2 BEARING 6000ZZ X MT952
27 911273-9 SCREW M5x50
29 911258-5 SCREW M5x35
30 159750-5 HOUSING MOTOR CPL
32 636008-4 STATOR
33 322049-3 HOOK
34 265995-6 SCREW M4X18
35 687063-9 RELIEF
36 682540-6 SLEEVE
38 415369-3 BAFFLE PLATE
39 210042-8 BEARING 629LLB
40 681633-6 WASHER
41 510240-7 ARMATURE EX cod. 516563-1
42 241515-0 FAN 92
43 267714-6 WASHER 15
44 211206-7 BALL BEARING
45 263005-3 PIN RUBBER 6
46 322665-1 FREEZE
47 231240-1 SPRING 7
48 150916-0 GEAR HOUSING CPL
49 951163-4 PIN 5-20
50 272021-4 KNOB
51 322239-8 SCREW CLAMP
52 951066-2 PIN 3-18
53 344089-1 SUPPORT PLATE
54 251887-5 BUTTERFLY SCREW M6x10
55 282010-1 CHAIN
56 322209-7 BOLT CLAMP
57 311949-2 GUIDE SCREW
58 911451-1 HEAD SCREW CILIND. M8x30
59 265201-9 HEXAGON BOLT M10x25
60 344087-5 GUIDE PLATE
61 266059-9 SCREW M5X75
62 911273-9 SCREW M5x50
63 191953-5 CHARCOALS CB-203
64 643710-2 PLUG BRUSH XHM1500
65 233113-4 SPRING COMPRESSION 45
66 165066-8 DISC STOPS SPRING 2414B
67 265407-9 NUT M10
68 252130-5 NUT M10-17
69 267713-8 WASHER 10
70 331428-4 TUBE 16-113
71 252014-7 NUT M6-10
72 942151-2 WASHER 6
73 922312-0 BOLT M6 X 12
74 344088-3 PLATE
75 911308-6 SCREW M6x10
76 421487-7 LEG STRETCH
77 267713-8 WASHER 10
78 265406-1 BOLT M10 X 130
79 165230-1 BASE
80 253731-2 FLAT WASHER 8
81 321680-2 SCREW M8
82 253731-2 FLAT WASHER 8
83 342679-4 JAW PLATE
84 253752-4 FLAT WASHER 8
85 942201-3 WASHER 8
86 931402-8 NUT M8
87 253903-9 WASHER 6 3700B
88 168320-9 DRIVING SAFETY X 2414NB
89 415661-7 CAP X 2414B

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
