Metabo Spare Parts for Percussion Drill SBE 850
We are METABO original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Percussion Drill SBE 850 - 00842000.
In the following table, look for the model of the Percussion Drill and the respective parts of the code.
| Percussion Drill SBE 850/00842000 | ||
| # | Part Num. | Description |
| 1 | 31001028 | Armature compl.,230 V |
| 2 | 31101079 | Field coil w.field coil,230 V |
| 3 | 14111826 | Self-tap. fill. h. screw |
| 4 | 34340922 | Electronic switch with dial |
| 5 | 34449318 | Cable with plug |
| 6 | 34339430 | Cable sleeve |
| 7 | 34336249 | Cable clip |
| 8 | 31605199 | Brush holder module,230V - V-El. 850W |
| 9 | 34339407 | Cover w.o. electronic |
| 12 | 31501325 | Motor housing |
| 13 | 14311581 | Ball bearing, 6X 19X 6 |
| 14 | 14311580 | Ball bearing, 8x22x7 |
| 15 | 14319243 | O-ring |
| 16 | 34339475 | Intermediate flange |
| 17 | 34409758 | Rubber plug |
| 18 | 14111602 | Self-tap fill h screw |
| 19 | 14111699 | Self-tap. fill. h. screw |
| 20 | 14111706 | Self-tap. fill. h. screw |
| 21 | 34337604 | Sealing ring |
| 22 | 31400103 | Side support handle compl. |
| 23 | 34151163 | Depth stop |
| 24 | 34339853 | Pistol grip 2-part, gummed |
| 26 | 34100597 | Bush |
| 27 | 33913307 | Shift fork |
| 28 | 14115659 | Retaining ring |
| 30 | 34409793 | Seal |
| 31 | 34409592 | Rubber buffer |
| 32 | 34160434 | Spindle |
| 34 | 34105565 | Slotted disc |
| 35 | 14118168 | Retaining ring |
| 36 | 14115660 | Circlip |
| 37 | 34000401 | Sliding block |
| 38 | 34154001 | Guide bolt |
| 39 | 31604196 | Control knob compl. |
| 40 | 14115581 | Ring |
| 41 | 31604194 | Switch housing compl. |
| 42 | 14112361 | Self-tap. fill. h. screw |
| 43 | 34152023 | Cylindrical pin |
| 44 | 34170194 | Cheese-head screw |
| 45 | 33805732 | Rating Plate |
| 46 | 31605154 | Gear housing compl. |
| 47 | 31604280 | Gear flange compl. |
| 48 | 31604282 | Pinion shaft w.slip-clutch |
| 49 | 14311579 | BALL BEARING, 15x32x9 |
| 52 | 31604695 | Carbon brush set,230 V |
| 880 | 34413093 | Grease 50Gr 1,8oz |
| 882 | 34413080 | Grease FG 126 |
| 884 | 34413056 | Grease SF 011 50Gr 1,8oz |
| 886 | 34413103 | Grease 50Gr 1,8oz |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Metabo websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Metabo brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
