Makita Spare Parts for Bench Saw LH1040F

Name: Makita Spare Parts for Bench Saw LH1040F
Brand: Makita
SKU: Makita LH1040F
Price: 134.42 EUR
Availability: InStock

€134.42

Tax included

Makita Spare Parts for Table Saw LH1040F

Distribution and Sale at attractive prices of MAKITA Original Spare Parts. Low prices and a professional Assistance guarantee, repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Table Saw LH1040F.

ITEM CODE: 141140-6

253762-1
418624-2
153996-5
316821-3
165388-6
318895-0
256280-8
421362-7
211061-7
324183-5
257163-5
443103-1
262511-5
599519-9
213021-5
331681-2
265437-0
643650-4
226465-0
343639-9
344377-6
265708-5
654561-8
231593-8
231955-0
344464-1
265985-9
687124-5
266029-8
911213-7
233414-0
345425-4
267070-4
912222-9
251644-1
416006-2
418618-7
141140-6
271601-3
961018-5
251961-9
253024-7
418621-8
153993-1
285685-5
253804-1
418625-0
154463-3
316824-7
165389-4
322316-6
256836-7
421589-9
211206-7
324496-4
257262-3
453028-1
265324-3
631611-6
213621-1
331682-0
265455-8
651522-9
231025-5
343641-2
231674-8
344381-5
265893-4
681640-9
232075-3
345226-0
265995-6
911113-1
266034-5
911223-4
233415-8
345426-2
267136-0
921452-1
251667-9
418616-1
252103-8
418619-5
141144-8
272230-5
181044-0
253186-1
418623-4
153995-7
286212-1
317779-9
253823-7
418630-7
158561-5
183881-8
322865-3
257162-7
421867-7
516718-8
211256-2
324497-2
257675-8
265355-2
631613-2
224333-1
331683-8
265488-3
652772-9
231297-2
343799-7
231675-6
344385-7
265984-1
682516-3
911206-4
233042-1
345423-8
266020-6
266492-5
911383-2
241909-9
345427-0
267280-3
941201-0
251812-6
418617-9
252105-4
418620-0
141630-9
273495-2
645200-1
122707-9

Quantity

Usually Ships in: 7/10 Business Days Approx.

Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Description
Product Details
Attachments

Makita Spare Parts for Table Saw LH1040F

Distribution and Sale at attractive prices of MAKITA Original Spare Parts

. Low prices and a professional Assistance guarantee, repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Table Saw LH1040F.

In the following table, look for the model Bench Saw and the respective parts of the code.

Table Saw LH1040F Spare Parts Pag.1
#	Part Num.	Description
1	153993-1	CARCASS BLADE X LH1040F
2	262511-5	REDUCTION RUBBER X HM1300
3	251667-9	SCREW M8X75 X LS1030
4	141144-8	COVER HOUSING X LH1040F
5	252103-8	NUT X JR3020
6	911223-4	HEAD SCREW CILIND. M5X16
7	345423-8	DIVIDING KNIFE X LH1040F
8	251644-1	BOLT WITH RIM 8X20
12	226465-0	GEAR X LS 1040
13	213621-1	RING 46 X 4157KB
14	316821-3	BEARING BOX X LS1040
15	211256-2	BEARING X AM4024LG
16	285685-5	FERMA BEARING 64 X LS1040
17	911223-4	HEAD SCREW CILIND. M5X16
18	322865-3	POST X LS1040
19	224333-1	FLANGE INTERNAL X LS1013
20	257262-3	RING 16 X LH1040F
21	224333-1	FLANGE INTERNAL X LS1013
22	265355-2	SCREW M8X20 X LS1030
23	343639-9	CENTRAL PLATE X LS1030
24	345226-0	COVER CENTRAL X LS1013
25	265324-3	SCREW M8X12
26	231593-8	SPRING TORSION 36 X LS1030
27	418625-0	HEADSET BLADE X LH1040F
28	267136-0	FLAT WASHER 5
29	911213-7	SCREW M5X12 X 5143R
30	265985-9	BOLT M6 X LS1040
31	265995-6	SCREW M4X18 X 6408 / 6221DW
32	418620-0	COVER CIRCUIT X LH1040F
33	654561-8	CLAMP X LH1040F
34	631613-2	STARTING CIRCUIT X LH1040F
35	265995-6	SCREW M4X18 X 6408 / 6221DW
36	687124-5	CLAMP ties MT953
37	599519-9	STATOR X LH1040F
38	418621-8	DEFLETTORE X LH1040F
39	211061-7	BALL BEARING 6000DD X 6221
40	681640-9	INSULATOR X 2702
41	516718-8	INDUCED LS1040
42	241909-9	FAN X LS1040
43	343641-2	PIN LOCK X LS1030
44	211206-7	BALL BEARING 6202V
45	267280-3	FLAT WASHER 15 X LH1040F
46	231297-2	SPRING 9 X LS1030
47	324496-4	PIN 8 X LH1040F
48	266029-8	SCREW M5X65
49	418630-7	SWITCH BOX X LH1040F
50	265995-6	SCREW M4X18 X 6408 / 6221DW
51	265995-6	SCREW M4X18 X 6408 / 6221DW
52	652772-9	RELAY 305.232.01 X LH1040F
53	153996-5	PLATE X LH1040F
54	266020-6	SCREW M4 X 12
55	153995-7	GRIP X LH1040F
56	941201-0	FLAT WASHER 8
57	331683-8	ASSE 9-126 X LH1040F
59	911383-2	SCREW M6 X60 X 2702
60	181044-0	CARBON BRUSH SET CB-153 (CB-152.154)
61	643650-4	CARBON BRUSH CAP
62	158561-5	MOTOR HOUSING X LH1040F
63	682516-3	CORD ARMOR 9.3-85
65	165389-4	BLADE GUARD X LH1040F
66	911206-4	SCREW M5x10
67	272230-5	LEVER 54
68	231955-0	SPRING RETAINER 12 X 5903R
69	331682-0	SCREW M 8 X 150 X LH1040F
70	265995-6	SCREW M4X18 X 6408 / 6221DW
71	645200-1	CAPACITOR
72	418618-7	PIN X LH1040F
73	443103-1	FELT RING 6 X LH1040F
74	253186-1	FLAT WASHER 7 X 420S
75	231025-5	COMPRESION SPRING 8 X 8411DW
76	418616-1	SWITCH BUTTON ON LH1040F
77	418617-9	SWITCH BUTTON OFF X LH1040F
78	231025-5	COMPRESSION SPRING 8 X 8411DW
79	253186-1	FLAT WASHER 7 X 420S
80	443103-1	FELT RING 6 X LH1040F
81	418618-7	PIN X LH1040F
82	418623-4	LIGHT SWITCH BOX X LH1040F
83	651522-9	SWITCH SLE6A X LS0714FL
84	418624-2	LIGHT SWITCH BOX COVER
85	265893-4	SCREW 3 X 12 X 6796D
86	231674-8	TORSION SPRING 9 X LH1040F
87	421589-9	HOOD X LS1013
88	345427-0	LEVER LOCK X LH1040F
89	911113-1	SCREW M4X10 X LS1013
155	266492-5	SCREW M4X25-9527PB 9528PB
10	183881-8	CONVOGLIATORE SX X LH1040F
11	421362-7	HOOD X 5017RKB
90	265995-6	SCREW M4X18 X 6408 / 6221DW
91	265995-6	SCREW M4X18 X 6408 / 6221DW
92	912222-9	SCREW M5X16
93	912222-9	SCREW M5X16
94	272230-5	LEVER 54
95	231955-0	RETAINER SPRING 12 X 5903R
96	331681-2	SCREW M8 X 70 X LH1040F
97	233042-1	COMPRESSION SPRING 14 X 6911DW
98	257675-8	SLEEVE 8 X LH1040F
99	317779-9	BENCH HOLDER X LH1040F
100	141630-9	WORK BENCH
101	165388-6	SUPPORT PLATE LH1040F
102	418619-5	UNDER GUARD R LH1040F
103	631611-6	CIRCUIT LIGHT X LH1040F
104	266034-5	SCREW 4X16 CT
105	233415-8	COMPRESSION SPRING 21 LH1040F
106	251812-6	SCREW M5x10
107	251961-9	BOLT M6x10 X LS1040
108	345425-4	SUPPORT PROTECTION X LH1040F
109	231675-6	TORSION SPRING 11 X LH1040F
110	267070-4	FLAT WASHER 10X4602DW
111	911223-4	SCREW M5X16
112	324497-2	PIN PROTECTION X X LH1040F
113	911223-4	HEAD SCREW CILIND. M5X16
114	345426-2	PROTECTION X LH1040F
115	961018-5	RETAINING RING E5
116	253804-1	WASHER 6 X LS1013
117	257163-5	RING 6 X LS1013
118	344377-6	PLATE ADJUSTMENT LS1040
119	265984-1	BOLT M6 X 2702
120	253823-7	ROND. FLAT 7 X JS1600
121	257162-7	RING 7 X LS1030
122	416006-2	LEVER 100 X LS1013
123	911113-1	SCREW M4X10 X LS1013
124	265437-0	BOLT M10 X LS1040
125	253024-7	WASHER 10 X LS1013
126	256836-7	ROD X LS1040
127	154463-3	ARM X LH1040F
128	421867-7	ARM COVER X X LH1040F
129	324183-5	PIN X LS0714FL
130	213021-5	RETAINING RING 5 X LS1013
131	271601-3	SCREW X LS1030
132	256280-8	PIN X LS1040
133	344464-1	SPRING COVER X LS1013
134	233414-0	COMPRESSION SPRING 27 X LH1040F
135	343799-7	PLATE LS1040
136	344385-7	LATCH X LS1040
137	911113-1	SCREW M4X10 X LS1013
138	265455-8	SCREW M8x30
139	253762-1	WASHER 8 X LS1040
140	252105-4	NUT M8X13
141	453028-1	KERF BOARD LH1040F
142	453028-1	KERF BOARD LH1040F
143	265488-3	SCREW M8x30 X LH1040F
144	318895-0	GUIDE FENCE X LH1040F
145	316824-7	TURN BASE X LS1040
146	265708-5	SCREW M6 X 20 X LS1040
147	141140-6	BASE CPL X LH1040F
148	266034-5	SCREW 4X16 CT
149	232075-3	LEAF SPRING LS1013
150	344381-5	SPRING LS1040 / LH1040F
151	273495-2	KNOB 32 X LS1030
152	911213-7	SCREW M5X12 X 5143R
153	921452-1	BOLT 8X30
154	286212-1	HOOD 20 X LS1013
156	322316-6	PIN 6
Accessories Pag.2
500	122707-9	Guide LH1040
