at the most competitive prices on the web, we are a service center with repair service able to advise you to purchase the most suitable spare part to quickly resolve any maintenance or repair issues for 4100KB 5" Dry Masonry Saw, with Dust Extraction.
In the following table, look for the model of Dustless Cutter and the respective parts of the code.![]()
| 4100KB 5" Dry Masonry Saw, with Dust Extraction | ||
| # | Part Num. | Description |
| 1 | 450838-7 | HANDLE COVER |
| 2 | 650248-0 | SWITCH SGES115C-3 |
| 3 | 424585-6 | DUST PROTECTION HOOD |
| 4 | 654532-5 | CLAMP 1P |
| 5 | 265995-6 | * SCREW M4X18 X 6408 / 6221DW |
| 7 | 911263-2 | CYLINDER HEAD SCREW M5x40 |
| 9 | 682540-6 | SLEEVE JN1601 |
| 10 | 687124-5 | MT953 CABLE CLAMP |
| 11 | 141726-6 | MOTOR CASE |
| 12 | 265995-6 | * SCREW M4X18 X 6408 / 6221DW |
| 13 | 645200-1 | CAPACITOR |
| 14 | 424634-9 | SPONGE |
| 15 | 191963-2 | CARBON BRUSHES CB-303 |
| 16 | 643750-0 | CARBON BRUSH HOLDER CAP |
| 17 | 599095-3 | FIELD 220V |
| 18 | 450839-5 | DEFLECTOR |
| 19 | 266038-7 | SCREW M5 X 70 HP2030 |
| 20 | 213262-3 | GASKET 18 4100R |
| 21 | 253192-6 | FLAT WASHER 14 |
| 22 | 211395-8 | BEARING 608LLU |
| 23 | 681644-1 | INSULATING WASHER X 9227CB |
| 24 | 513769-2 | ARMATURE 240V COMPLETE |
| 25 | 240109-8 | FAN 70 |
| 26 | 211092-6 | BALL BEARING 629DD |
| 27 | 226695-3 | GEAR 17 |
| 28 | 961002-0 | RETAINING RING S6 |
| 29 | 144781-7 | GEAR BOX 4100KB |
| 30 | 251586-9 | SCREW M6 4100KB |
| 31 | 213444-7 | RING 30 |
| 32 | 226696-1 | GEAR 44 |
| 33 | 961052-5 | RETAINING RING S12 |
| 34 | 911223-4 | CYLINDER HEAD SCREW M5X16 |
| 35 | 135948-8 | BEARING BOX |
| 36 | 211129-9 | BALL BEARING 6201DD NSK |
| 37 | 325603-2 | POST |
| 38 | 285858-0 | BEARING RETENTION 19-33 |
| 39 | 213279-6 | RING 18 X MT582 |
| 40 | 253397-8 | CUP WASHER 15 4100KB |
| 41 | 224423-0 | INNER FLANGE 36 |
| 42 | 224424-8 | OUTER FLANGE 36 |
| 43 | 266510-9 | SCREW M6x18 |
| 44 | 257982-9 | LOCKING RING X HS6101 |
| 45 | 271443-5 | LEVER 49 100KB |
| 46 | 264103-6 | NUT M6 |
| 47 | 253111-2 | FLAT WASHER 6 X 9803 |
| 48 | 161775-7 | BASE 4100KB |
| 49 | 252103-8 | NUT X JR3020 |
| 50 | 266515-9 | SCREW M5 |
| 51 | 416741-2 | JOINT X ASPIRATOR X SG1250 / 2 |
| 52 | 213460-9 | GASKET 35 HK / HR1800 / HM12 |
| 53 | 458035-9 | DUST GUARD RIGHT SIDE |
| 54 | 213005-3 | RING 5 |
| 55 | 265995-6 | * SCREW M4X18 X 6408 / 6221DW |
| 56 | 458605-4 | LH POWDER COVER |
| 57 | 233267-7 | COMPRESSION SPRING 7 X AN621 |
| 58 | 941151-9 | WASHER 6 X HM1303 |
| 59 | 265658-4 | SCREW M6x26 |
| 60 | 347305-0 | PLATE |
| 61 | 126911-2 | DUST COVER 4100KB |
