Makita Spare Parts for SDS-Plus Rotary Hammer HR2450FT
€6.29
Tax included
Makita Spare Parts for SDS-Plus Rotary Hammer HR2450FT
We have the original Spares for SDS-Plus Rotary Hammer HR2450FT, the diagram, parts list and tool repair that help you need to get your tools running like new again.Fix Your SDS-Plus Rotary Hammer HR2450FT. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for SDS-Plus Rotary Hammer HR2450FT
Fix Your SDS-Plus Rotary Hammer HR2450FT. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of jackhammers and the respective parts of the code.
| HR2450FT - ROTARY HAMMER 24MM 780W W/LED | ||
| # | Part Num. | Description |
| 7 | 921923-8 | SCREW M 8 X 120 X HR2020 |
| 8 | 417630-4 | BASE X HANDLE X HR2020 |
| 9 | 135302-6 | HANDLE X HR2020 |
| 10 | 266069-6 | SCREW PT S X 45 HR2410 |
| 11 | 417794-4 | GEARBOX LEVERAGE CAP HR2450 |
| 12 | 162229-7 | DRIVE LEVER X HR2450 |
| 13 | 213278-8 | RING 13 X HR2020 |
| 14 | 183441-6 | GEAR BOX X HR2450 |
| 15 | 153290-5 | BEARING X HR2020 |
| 16 | 233929-7 | ELASTIC RING 29 X HR2450FT |
| 17 | 267782-9 | WASHER 31 X HR2450FT |
| 18 | 233401-9 | COMPRESSION SPRING 32 HR2450FT |
| 19 | 227109-5 | GEAR 51 X HR2450FT |
| 21 | 153696-7 | TOOL HOLDER X HR2450FT |
| 22 | 267229-3 | WASHER 28 X HR2020 |
| 23 | 213074-4 | RING 9 X HR2450FT |
| 24 | 324400-3 | STRIKER X HR2450FT |
| 25 | 324402-9 | RING 10 X HR2450FT |
| 26 | 213232-2 | RING 15 X HR2020 |
| 27 | 324216-6 | RING X HR2020 |
| 28 | 213073-6 | RING 9 X HR2020 |
| 29 | 233917-4 | ELASTIC RING 28 X HR2020 |
| 30 | 324214-0 | HAMMER X HR2020 |
| 31 | 213227-5 | RING 16 X HK0500 |
| 32 | 331632-5 | PISTON X HR2450 |
| 33 | 267104-3 | FLAT WASHER 12 X HR2400 |
| 34 | 324215-8 | PINION X PISTON X HR2020 |
| 35 | 267104-3 | FLAT WASHER 12 X HR2400 |
| 36 | 211012-0 | BEARING X 9524NB |
| 37 | 961003-8 | RETAINER RING S7 |
| 38 | 233343-7 | COMPRESSION SPRING X HR2450 |
| 39 | 331993-3 | CLUTCH X HR2450 |
| 40 | 324248-3 | CLUTCH SHAFT X HR2450 |
| 41 | 219014-0 | ECCENTRIC 10 X HR2020 |
| 42 | 226550-9 | GEAR 26 X HR2020 |
| 43 | 266273-7 | SCREW 4 X 12 X 4604D |
| 44 | 345179-3 | BEARING RETAINER X HR2020 |
| 45 | 267234-0 | FLAT WASHER 8 X HR2020 |
| 46 | 211032-4 | BEARING X 1902 |
| 47 | 324212-4 | RING 8 X HR2020 |
| 48 | 213725-9 | RING 68 X HR2020 |
| 49 | 153687-8 | INTERNAL HOUSING X HR2450 |
| 50 | 213380-7 | GASKET 24 |
| 51 | 210060-6 | BEARING 609LLU HR2430 |
| 52 | 267231-6 | FLAT WASHER 9 X HR2020 |
| 53 | 240047-4 | FAN 60 X HR2020 |
| 54 | 515668-4 | ARMATURE X HR2440 |
| 55 | 681636-0 | INSULATING WASHER |
| 56 | 211021-9 | BALL BEARING 607LLB |
| 57 | 266052-3 | SCREW PT 4X60 |
| 58 | 419201-3 | DEFLECTOR X HR2020 |
| 59 | 633488-5 | STATOR X HR2020 HR2440 |
| 60 | 417973-4 | MOTOR HOUSING DA3010F-HR2440 |
| 62 | 689111-0 | SPACER X HR2020 |
| 63 | 643988-7 | CARBON BRUSH HOLDER X HR2020 |
| 65 | 191962-4 | CARBON BRUSH SET CB-419 (406.407) 418 |
| 66 | 643989-5 | BRUSH HOLDER X HR2020 |
| 68 | 650508-0 | SWITCH TG813TLB-1 |
| 69 | 153284-0 | HANDLE COVER X HR2020 |
| 70 | 265999-8 | SCREW 4X25 |
| 71 | 682566-8 | CORD SLEEVE X HR2450 |
| 73 | 645253-0 | CAPACITOR X 6408 |
| 74 | 687124-5 | TERMINAL CLAMP MT953 |
| 75 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 76 | 265999-8 | SCREW 4X25 |
| 77 | 421494-0 | RUBBER RING 19 X 9521NB |
| 78 | 417795-2 | BLOCK BUTTON X HR2450 |
| 79 | 233341-1 | COMPRESSION SPRING X HR2450 |
| 80 | 226399-7 | GEAR 10 X BHR200 |
| 81 | 265999-8 | SCREW 4X25 |
| 82 | 345363-0 | GEARBOX PLATE X HR2450 |
| 83 | 961017-7 | RING E-3 X 4305T |
| 84 | 417796-0 | BASE X GUIDE X HR2450 |
| 85 | 233344-5 | COMPRESSION SPRING 4 |
| 86 | 961011-9 | RETAINER RING E4 |
| 87 | 941102-2 | FLAT WASHER 5 |
| 88 | 233342-9 | COMPRES.ION SPRING 6 X HR2450 |
| 89 | 163430-7 | PLATE BLOCK X HR2450 |
| 90 | 345280-4 | WASHER X HP2051F |
| 91 | 631471-6 | LIGHT CIRCUIT X HP2051F |
| 92 | 267271-4 | FLAT WASHER 9 X HR2450FT |
| 93 | 324401-1 | BUSHING 9 X HR2450FT |
| 94 | 194080-7 | SDS-PLUS RAPID HOLDER |
| 95 | 286263-4 | CAP 35 X HR2020 |
| 96 | 233940-9 | ELASTIC RING 19 FOR HR2432 |
| 97 | 418217-5 | TOOL HOLDER COVER HR2450FT |
| 98 | 345333-9 | RETAINER FOR HR2450FT |
| 99 | 216022-2 | BALL 7 |
| 100 | 345187-4 | GUIDE WASHER X HR2020 |
| 101 | 233916-6 | SPRING 21-29 X HR2020 |
| 102 | 267279-8 | FLAT WASHER 21 X HR2450FT |
| 103 | 324355-2 | SDS-PLUS X HR2450FT |
| 104 | 216013-3 | BALL 6 |
| 105 | 231669-1 | TORSION SPRING 31 X HR2450FT |
| 106 | 345334-7 | CHANGE RING X HR2450FT |
| 107 | 418218-3 | CHANGE RING COVER X HR2450FT |
| 108 | 216018-3 | BALL 5 HP2030 |
| 109 | 345335-5 | SPRING X HR2450FT |
| 110 | 267270-6 | WASHER 24 X HR2450FT |
| 111 | 233924-7 | RETAINER RING 21 X HR2450FT |
| 999 | 193606-2 | SERVICE PACK KIT HR2020 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
