Makita Spare Parts for Die Grinder GD0800C

€11.55
Tax included

Makita Spare Parts for Die Grinder GD0800C

Makita genuine spare parts or replacement parts for to fix Die Grinder GD0800C.
ITEM CODE: 191978-9
Quantity
on 7/10 Business Days Approx

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Makita Spare Parts for Die Grinder GD0800C

Makita genuine spare parts or replacement parts for to fix Die Grinder GD0800C.

In the following table, look for the model of the Die Grinder and the respective parts of the code.
Die Grinder GD0800C

Die Grinder GD0800C
# Part Num. Description
1 763645-2 LOCK NUT X GD0810C
2 193012-1 BUSH 6 X GD0800C
3 324042-3 SHAFT X GD0800C
4 213209-7 RING 16 X 6510SB
5 285700-5 RETAINING BEARING X GD0800C
6 211141-9 BEARING 6901LLB X GD0800C
7 961052-5 RETAINING RING S12
8 317368-0 CANNON X GD0800C
9 961052-5 RETAINING RING S12
10 211142-7 BEARING 6001LLB X GD0800C
11 962106-1 RETAINING RING R28
12 233901-9 SPRING 12 X GD0800C
13 323989-8 RING STOP X GD0800C
14 265082-1 SCREW M4 X 8 X GD0800C
17 962106-1 RETAINING RING R28
18 961052-5 RETAINING RING S12
19 211142-7 BEARING 6001LLB X GD0800C
20 253084-9 ROND.P.12 8419B / 5016NB
21 317367-2 BEARING BOX X GD0800C
22 240036-9 FAN 57 X GD0800C
23 515219-3 ARMATURE X GD0800C
24 681656-4 INSULATING WASHER X GD0810C
25 253823-7 Plain washer 7 X JS1600
26 210023-2 BEARING 9910/11
28 421770-2 RUBBER RING 22 X GD0800C
29 688117-5 COMPASS X GD0800C
30 259039-2 LOCKING 6 X 9566CV
31 413076-2 BAFFLE X GD0800C
32 266259-1 SCREW M4 X 60 X GD0800C
33 344871-8 RETAINING X GD0800C
34 417237-6 COVER INSULATION X GD0800C
35 626524-4 STATOR X GD0800C
39 266256-7 SCREW 3 X 10 X GD0800C
40 643760-7 BRUSH X BO6040
41 191978-9 CARBON BRUSHES CB 318
42 265995-6 SCREW M4X18 X 6408 / 6221DW
43 687052-4 CLAMP Cable tie X 6408
44 632945-0 LOCK SWITCH X GD0800C
46 682559-5 SAVE CABLE X 6822
47 651418-4 SWITCH ST115A-40 X 9541
48 687113-0 COVER X GD0800C
50 417185-9 BACK COVER X GD0800C
51 265995-6 SCREW M4X18 X 6408 / 6221DW
52 631391-4 CONTROL X GD0800C
53 417187-5 LEVER SWITCH X GD0800C
54 233071-4 SPRING COMPRESSION 4 X 9541
55 643974-8 BRUSH X BO6040
56 417812-8 CASING MOTOR BO6040
58 417813-6 CONTROL SWITCH X GD0800C
59 265999-8 SCREW 4X25
60 763646-0 TAPER BUSH 6 X GD0800C
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
