Makita Spare Parts for Demolition Hammer HM1214C
€118.09
Tax included
Makita Spare Parts for Demolition Hammer HM1214C
Makita original spare parts for to replace broken parts or to fix HM1214C 27 lb. AVT® Demolition Hammer SDS‑MAX bits.Fix Your HM1214C 27 lb. AVT® Demolition Hammer SDS‑MAX bits. All Parts can be supplied at low and discounted prices. Our Spares are Genuine Parts and Come with a full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Demolition Hammer HM1214C
Fix Your HM1214C 27 lb. AVT® Demolition Hammer SDS‑MAX bits. All Parts can be supplied at low and discounted prices. Our Spares are Genuine Parts and Come with a full Guarantee.
In the following table, look for the model of the Hammer and the respective parts of the code.
| Demolition Hammer Makita HM1214C | ||
| # | Part Num. | Description |
| 1 | 424165-8 | TOOL HOLDER CAP X HM1203C |
| 2 | 233973-4 | RING SPRING 26 X HM1203C |
| 3 | 267386-7 | WASHER 30 X HM1203C |
| 4 | 450894-7 | CHUCK COVER HM1203C |
| 5 | 262147-0 | RUBBER RING 30 X HM1203C |
| 6 | 324987-5 | CHUCK RING HM1203C |
| 7 | 450895-5 | RELEASE COVER X HM1203C |
| 8 | 310279-8 | TOOL RETAINER X HM1203C |
| 9 | 346015-6 | SPRING GUIDE HM1203C |
| 10 | 234086-4 | COMPRESSION SPRING 56 X HM1203C |
| 11 | 961232-3 | RETAINING RING |
| 12 | 450893-9 | CHANGE RING COVER X HM1203C |
| 13 | 324969-7 | RING GEAR HM1203C |
| 14 | 324988-3 | RETAINING RING HM1203C |
| 15 | 266499-1 | SCREW M 6 X 30 X HM1214C |
| 16 | 451113-4 | BARREL COVER X HM1214C |
| 17 | 233970-0 | RING SPRING 35 X HM1203C |
| 18 | 158984-7 | BARREL X HM1214C |
| 19 | 266010-9 | BOLT M8x30 X HM1303 |
| 20 | 262148-8 | RUBBER RING 39 X HM1203C |
| 21 | 267387-5 | WASHER 39 X HM1203C |
| 22 | 213079-4 | RING 35,5 X HM1203C |
| 23 | 324985-9 | TOOL HOLDER X HM1203C |
| 24 | 213980-3 | O-RING 21 X HR4501C |
| 25 | 213431-6 | O-RING 23 HR5001C |
| 26 | 213394-6 | RUBBER RING X HR5001C |
| 27 | 325681-2 | IMPACT BOLT HM1214C |
| 28 | 324993-0 | SHOULDER SLEEVE X HM1203C |
| 29 | 262149-6 | RUBBER RING 24 X HM1203C |
| 30 | 324993-0 | SHOULDER SLEEVE X HM1203C |
| 31 | 325680-4 | STRIKER X HM1214C |
| 32 | 213499-2 | O-RING 5.31 X HM1203C |
| 33 | 213581-7 | O-RING 44 X HM1203C |
| 34 | 331856-3 | CYLINDER 40 X HM1214C |
| 35 | 451110-0 | CYLINDER GUIDE HM1214C |
| 36 | 234107-2 | COMPRESSION SPRING 58 X HM1214C |
| 37 | 451103-7 | WEIGHT GUIDE HM1214C |
| 38 | 331854-7 | CONUNTER WEIGHT X HM1214C |
| 39 | 234107-2 | COMPRESSION SPRING 58 X HM1214C |
| 40 | 325661-8 | SLIDE SLEEVE X HM1214C |
| 41 | 231985-1 | RING SPRING 43 X HR5001C |
| 42 | 257297-4 | RING 45 X HM1214C |
| 43 | 213510-0 | O-RING 36 HR2010 |
| 44 | 268121-6 | PIN 12 X HR5201C |
| 45 | 213499-2 | RING 5.31 X HM1203C |
| 46 | 450961-8 | PISTON X HM1203C |
| 47 | 213149-9 | O-RING 35 X HM1203C |
| 48 | 450890-5 | CONNECTING ROD HM1203C |
| 49 | 268235-1 | PIN 6 X HM1214C |
| 50 | 213754-2 | O-RING 71 X HM1200 |
| 51 | 451115-0 | GEAR COVER HM1214C |
| 52 | 266499-1 | SCREW M 6 X 30 X HM1214C |
| 53 | 226699-5 | GEAR 52 X HM1214C |
| 54 | 211290-2 | BALL BEARING 6203ZZ |
| 55 | 213313-2 | SEAL OIL 20 HR2410 |
| 56 | 267166-1 | WASHER 14 X HM0860C |
| 57 | 226155-5 | GEAR 34-48 HM1214C |
| 58 | 212159-3 | CONROD HOUSING 1412 X HM1214C |
| 59 | 267166-1 | WASHER 14 X HM0860C |
| 60 | 424196-7 | SEAL RING X HM1214C |
| 61 | 158983-9 | CRANK HOUSING X HM1214C |
| 62 | 211327-5 | BALL BEARING HM1202C |
| 63 | 325659-5 | CRANK SHAFT HM1214C |
| 64 | 325660-0 | COUNTER SHAFT HM1214C |
| 65 | 212225-6 | NEEDLE BEARING 1613 |
| 66 | 325662-6 | WASHER 8 X HM1214C |
| 67 | 213754-2 | SEAL RING 71 X HM1200 |
| 68 | 268222-0 | PIN 8 X HM1214C |
| 69 | 158985-5 | BEARING BOX COMP. X HM1214C |
| 70 | 213176-6 | O-RING 14 X AN901 |
| 71 | 451104-5 | GREASE CAP X HM1214C |
| 72 | 266087-4 | SCREW M6 X 25 X HM1214C |
| 73 | 211032-4 | BEARING X 1902BALL |
| 74 | 962112-6 | RETAINING RING R-22 X BFL080FZ |
| 75 | 961004-6 | RETAINING RING S8 |
| 76 | 213262-3 | O-RING 18 4100R |
| 77 | 451108-7 | FILTER CASE X HM1214C |
| 78 | 443147-1 | FILTER X HM1214C |
| 79 | 213569-7 | O-RING 45 X AN621 |
| 80 | 451109-5 | FILTER CASE COVER |
| 81 | 451116-8 | REAR COVER X HM1214C |
| 82 | 266499-1 | SCREW M 6 X 30 X HM1214C |
| 83 | 331855-5 | SEALING SCREW HM1214C |
| 84 | 211249-9 | BALL BEARING 6302LLU HM1203C |
| 85 | 267397-2 | WASHER 15 X HM1203C |
| 86 | 240003-4 | FAN X 2702 |
| 87 | 517838-1 | ARMATURE X HM1214C |
| 88 | 681642-5 | WASHER X LS1013 |
| 89 | 210059-1 | BALL BEARING 6000 HR2010 |
| 90 | 451107-9 | WASHER GUIDE X HM1214C |
| 91 | 267809-5 | WAVE WASHER 19 FOR HM1202 |
| 92 | 451111-8 | BAFFLE PLATE X HM1214C |
| 93 | 266095-5 | SCREW 5 X 55 HR5001C |
| 94 | 636303-2 | STATOR FOR HR5201C |
| 95 | 451117-6 | MOTOR HOUSING X HM1214C |
| 96 | 632D00-2 | BRUSHES HOLDER HM1203C |
| 97 | 195844-2 | CARBON BRUSHE SET CB-175 |
| 98 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 99 | 158986-3 | CONTROLLER COVER COMP. HM1214C |
| 100 | 263027-3 | RUBBER PIN 4 X HM0860C |
| 101 | 651423-1 | SWITCH X 3706 |
| 102 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 103 | 687169-3 | STRAIN RELIEF HP1620 |
| 104 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 106 | 682560-0 | CORD GUARD X HM1202C / 9079S |
| 107 | 620226-4 | CONTROLLER |
| 108 | 266834-3 | SCREW M4X18 |
| 109 | 232209-8 | LEAF SPRING X HM0860C |
| 110 | 451112-6 | SLIDE LEVER HM1214C |
| 111 | 263027-3 | RUBBER PIN 4 X HM0860C |
| 112 | 451105-3 | LENS FOR HM1214C |
| 113 | 451118-4 | REAR HANDLE X HM1214C |
| 114 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 115 | 451106-1 | SWITCH LEVER HM1214C |
| 116 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 117 | 266499-1 | SCREW M 6 X 30 X HM1214C |
| 118 | 866749-0 | LABEL HM1214C |
| 119 | 451119-2 | HANDLE COVER X HM1214C |
| 120 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 121 | 265439-6 | SCREW M8X150 X HM1100C |
| 122 | 417002-3 | SIDE HANDLE CAM HM1202C |
| 123 | 318430-4 | BASE HANDLE 90A HM1214C |
| 124 | 951166-8 | SPRING PIN 5/24 |
| 125 | 318431-2 | HANDLE BASE 90B HM1214C |
| 126 | 417003-1 | SIDE HANDLE X HM1202C |
| 127 | 417002-3 | SIDE HANDLE CAM HM1202C |
| 128 | 252640-2 | HANDLE KNOB M8 X |
| 129 | 135283-4 | HANDLE DX HM1214C |
| 130 | 346546-5 | PLATE X HM1214C |
| 131 | 442180-0 | DOUBLE SIDED TAPE HM1214C |
| 132 | 126094-8 | CONTROLLER + HOLDER HM1214C |
| 999 | 195114-9 | SERVICE KIT HM1203C / 1213C |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Makita websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
