Makita Spare Parts for SDS-Plus Rotary Hammer HR2450
€15.20
Tax included
Makita Spare Parts for SDS-Plus Rotary Hammer HR2450
Distribution and Sale at attractive prices of MAKITA Original Spare Parts & Accessories. Low prices and a professional Assistance guaranteed. We are a Repair service able to advise you on the purchase the most suitable spare parts to quickly solve any maintenance or issue for Rotary Hammer SDS-PLUS ROTOSTOP 24MM 780W HR2450.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for SDS-Plus Rotary Hammer HR2450
Distribution and Sale at attractive prices of MAKITA Original Spare Parts & Accessories. Low prices and a professional Assistance guaranteed. We are a Repair service able to advise you on the purchase the most suitable spare parts to quickly solve any maintenance or issue for Rotary Hammer SDS-PLUS ROTOSTOP 24MM 780W HR2450.
In the following table, look for the model of Rotary Hammer and the respective parts of the code.
| ROTARY HAMMER 24MM 750W 2450 | ||
| # | Part Num. | Description |
| 1 | 286263-4 | CAP 35 X HR2020 |
| 2 | 233940-9 | ELASTIC RING 19 FOR HR2432 |
| 3 | 417629-9 | FRONT COVER X X HR2020 |
| 4 | 257241-1 | RING 21 X HR2020 |
| 5 | 345187-4 | WASHER GUIDE X HR2020 |
| 6 | 233916-6 | SPRING 21-29 X HR2020 |
| 7 | 921923-8 | SCREW M 8 X 120 X HR2020 |
| 8 | 417630-4 | HANDLE BASE X X HR2020 |
| 9 | 153503-4 | GRIP X MT811 |
| 10 | 266069-6 | PT SCREW S X 45 HR2410 |
| 11 | 417794-4 | STOPPER LEVER |
| 12 | 162229-7 | LEVER |
| 13 | 213278-8 | RING 13 X HR2020 |
| 14 | 183441-6 | GEAR BOX |
| 15 | 153290-5 | BEARING X HR2020 |
| 16 | 233918-2 | CIRCLIP 28 X HR2020 |
| 17 | 267228-5 | WASHER 30 X HR2020 |
| 18 | 233328-3 | COMPRESSION SPRING 31 X HR2020 |
| 19 | 227028-5 | GEAR 51 |
| 20 | 216022-2 | BALL 7 |
| 21 | 153365-0 | DOOR TIPS HR2450 |
| 22 | 267229-3 | WASHER 28 X HR2020 |
| 23 | 213128-7 | RING 12 X HR2020 |
| 24 | 324396-8 | SWING X HR2450 |
| 25 | 324218-2 | RING 9 X HR2020 |
| 26 | 213232-2 | RING 15 X HR2020 |
| 27 | 324216-6 | RING X HR2020 |
| 28 | 213073-6 | RING 9 X HR2020 |
| 29 | 233917-4 | CIRCLIP 28 X HR2020 |
| 30 | 324214-0 | STRIKER X HR2020 |
| 31 | 213227-5 | RING 16 X HK0500 |
| 32 | 331632-5 | PISTON HR2450 |
| 33 | 267104-3 | FLAT WASHER 12 X HR2400 |
| 34 | 324215-8 | PISTON PIN X X HR2020 |
| 35 | 267104-3 | FLAT WASHER 12 X HR2400 |
| 36 | 211012-0 | BEARING X 9524NB |
| 37 | 961003-8 | RETAINING RING S7 |
| 38 | 233343-7 | SPRING COMPRESSION 7 |
| 39 | 331993-3 | CLUTCH X HR2450 |
| 40 | 324248-3 | SHAFT CLUTCH HR2450 |
| 41 | 219014-0 | ECCENTRIC 10 X HR2020 |
| 42 | 226550-9 | GEAR 26 X HR2020 |
| 43 | 266273-7 | SCREW 4 X 12 X 4604D |
| 44 | 345179-3 | RETAINING BEARING X HR2020 |
| 45 | 267234-0 | FLAT WASHER 8 X HR2020 |
| 46 | 211032-4 | BEARING X 1902 |
| 47 | 324212-4 | RING 8 X HR2020 |
| 48 | 213725-9 | RING 68 X HR2020 |
| 49 | 153687-8 | CASING INSIDE X HR2450 |
| 50 | 213380-7 | SEAL 24 |
| 51 | 210060-6 | BEARING 609LLU HR2430 |
| 52 | 267231-6 | FLAT WASHER 9 X HR2020 |
| 53 | 240047-4 | FAN 60 X HR2020 |
| 54 | 515668-4 | ARMATURE X HR2440 |
| 55 | 681636-0 | INSULATION WASHER |
| 56 | 211021-9 | BEARING 607LLB |
| 57 | 266052-3 | PT SCREW 4X60 |
| 58 | 419201-3 | BAFFLE PLATE X HR2020 |
| 59 | 633488-5 | FIELD ASSY X HR2020 HR2440 |
| 60 | 417632-0 | MOTOR HOUSING X HR2432 |
| 62 | 689111-0 | SPACER X HR2020 |
| 63 | 643988-7 | BRUSH HOLDER X HR2020 |
| 65 | 191962-4 | CARBON BRUSHE SET CB-419 (406.407) 6408 |
| 66 | 643989-5 | BRUSH HOLDER X HR2020 |
| 68 | 650508-0 | SWITCH TG813TLB-1 HR2020 |
| 69 | 153284-0 | HANDLE COVER X HR2020 |
| 70 | 265999-8 | SCREW 4X25 |
| 71 | 682566-8 | CABLE 10 HR2450 |
| 74 | 687052-4 | CLAMP Cable tie X 6408 |
| 75 | 265995-6 | SCREW M4X18 X 6408 / 6221DW |
| 76 | 265999-8 | SCREW 4X25 |
| 77 | 421494-0 | RUBBER 19 X 9521NB |
| 78 | 417795-2 | BUTTON LOCK HR2450 |
| 79 | 233341-1 | COMPRESSION SPRING 3 |
| 80 | 226399-7 | GEAR 10 X BHR200 |
| 81 | 265999-8 | SCREW 4X25 |
| 82 | 345363-0 | PLATE CHANGE X HR2450 |
| 83 | 961017-7 | RING-3 X 4305T |
| 84 | 417796-0 | BASIC GUIDE HR2450 |
| 85 | 233344-5 | COMPRESSION SPRING 4 |
| 86 | 961011-9 | RETAINING RING E4 |
| 87 | 941102-2 | FLAT WASHER 5 |
| 88 | 233342-9 | COMPRESSION SPRING 6 |
| 89 | 163430-7 | PLATE LOCK HR2450 |
| 999 | 193606-2 | SERVICE KIT HR2020 |
