Annovi & Reverberi Parts for Pressure Washer AR747
€14.23
Tax included
Annovi Reverberi Parts for Pressure Washer AR 747
We are Annovi Reverberi original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Pressure Washer AR 747 - 12362.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Annovi Reverberi Parts for Pressure Washer AR 747
We are Annovi Reverberi original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Pressure Washer AR 747 - 12362.
In the following tables, look for the spare part and its respective code.
| Pressure Washer Model AR 747 - 12362 Pag.1 | ||
| # | Part Num. | Description |
| 1 | 2500050 | hook |
| 2 | 2500035 | blue Casing |
| 3 | 1680880 | washer |
| 4 | 2500320 | wheel |
| 5 | 2500090 | plate |
| 6 | 2320190 | screw |
| 7 | 2100300 | screw |
| 8 | 2600100 | cable clamp |
| 9 | 850370 | screw |
| 10 | 2100300 | screw |
| 11 | 2500020 | handle |
| 12 | 2500130 | Rubber |
| 13 | 880280 | screw |
| 14 | 2180300 | washer |
| 15 | 2500120 | Axle |
| 16 | 2500110 | tank |
| 17 | 2500010 | base |
| 18 | 1270960 | pipe cleaner |
| 19 | 2500310 | knob |
| 20 | 42113 | Pre-assembly plug |
| 21 | 2500330 | pipe cleaner |
| 22 | 2000230 | filter |
| 23 | 2509000 | Pre-assembly base |
| Corpo Pompa 747 12362 Pag.2 |
||
| 1 | 1980470 | screw |
| 2 | 1980300 | nut |
| 3 | 1980210 | piston guide |
| 4 | 740290 | O-ring |
| 5 | 800560 | O-ring |
| 6 | 1080250 | O-ring |
| 7 | 1271170 | ring |
| 8 | 1080190 | O-ring |
| 9 | 1271160 | piston |
| 10 | 1980200 | seat |
| 11 | 1470210 | O-ring |
| 12 | 1982520 | Hose |
| 13 | 480480 | O-ring |
| 14 | 1250280 | sphere |
| 15 | 1560520 | spring |
| 16 | 1460430 | O-ring |
| 17 | 1540170 | shutter |
| 18 | 1080091 | spring |
| 19 | 394280 | O-ring |
| 20 | 1200690 | O-ring |
| 21 | 1270091 | injector |
| 22 | 1981190 | screw |
| 23 | 1080190 | O-ring |
| 24 | 660190 | O-ring |
| 25 | 1982990 | piston |
| 26 | 1981320 | spring |
| 27 | 880840 | O-ring |
| 28 | 1983360 | junction |
| 29 | 1982170 | head |
| 30 | 820510 | O-ring |
| 31 | 880581 | stopper |
| 32 | 2029752 | Pre-assembly box TSS |
| 33 | 1260162 | stopper |
| 34 | 960160 | O-ring |
| 35 | 1981460 | bushing |
| 36 | 880240 | valve |
| 37 | 1981450 | bushing |
| 38 | 1080401 | ring |
| 39 | 2460180 | Tenuta water |
| 40 | 1981470 | piston guide |
| 41 | 770130 | O-ring |
| 42 | 1260440 | Watertight 3 |
| 43 | 1980170 | ring |
| 44 | 1980430 | spacer |
| 45 | 1260460 | oil seal |
| 46 | 770090 | O-ring |
| 47 | 1980460 | pump body |
| 48 | 180030 | screw |
| 49 | 1981140 | spring |
| 50 | 1981440 | piston |
| 51 | 1980150 | ring |
| 52 | 1322230 | spring |
| 53 | 1980130 | Fifth wheel |
| 54 | 1980250 | Fifth wheel |
| 55 | 1980240 | Fifth wheel |
| 56 | 1980340 | O-ring |
| 57 | 2022201 | fork |
| 58 | 1461470 | junction |
| 59 | 1989264 | Pre-assembly head |
| 60 | 1980310 | screw |
| 61 | 1260820 | O-ring |
| 62 | 650530 | washer |
| 63 | 1340260 | filter |
| 64 | 390180 | O-ring |
| 65 | 2440210 | extension |
| 66 | 1150640 | O-ring |
| 67 | 2500450 | stopper |
| 68 | 1980290 | stopper |
| 69 | 1465850 | junction |
| 70 | 2500140 | extension |
| 71 | 3230 | manometer |
| 72 | 1080041 | piston |
| 73 | 1080070 | plug |
| 74 | 1271070 | spring |
| 75 | 1980220 | disk |
| 76 | 1980390 | insert |
| 77 | 2500270 | extension + 1267810 >>42575 |
| 78 | 2500080 | knob |
| 79 | 42143 | Kit TSS |
| A | 2581 | valve Kit |
| B | 2593 | piston Kit |
| C | 2511 | Oil seals Kit |
| E | 2582 | Kit water seal |
| F | 2799 | seal Kits |
| Motor 747 - 12362 Pag.3 |
||
| 1 | 1983110 | disk |
| 2 | 1981210 | bearing |
| 3 | 1980340 | O-ring |
| 4 | 2320830 | screw |
| 5 | 1982040 | flange |
| 6 | 1260750 | ring |
| 7 | 1460590 | bearing |
| 8 | 1460040 | shield |
| 9 | 1461200 | oil seal |
| 10 | 394280 | O-ring |
| 11 | 1460370 | fan |
| 12 | 1460340 | conveyor |
| 13 | 1680960 | washer |
| 14 | 1460460 | screw |
| 15 | 660170 | O-ring |
| 16 | 2320131 | box |
| 17 | 1262400 | washer |
| 18 | 2020570 | screw |
| 19 | 2320270 | cover |
| 20 | 2320280 | switch |
| 21 | 2021480 | Grommet |
| 22 | 1760450 | cable |
| 23 | 2100840 | O-ring |
| 24 | 1982190 | capacitor 40 Mf |
| 25 | 4704 | engine |
| Pistola + lancia + Tubo 747 12362 Pag.4 |
||
| 1 | 40925 | gun |
| 2 | 40029 | Lance + head |
| 3 | 3780441 | High pressure hose |
| 4 | 2000770 | O-ring |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Annovi & Reverberi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Annovi & Reverberi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Annovi Reverberi 747 - 12362
6 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10/15 BUSINESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N AR:
- AR S/N START WITH ( 1 or 2 ) and have 5 DIGITS
