Makita Spare Parts for Band Saw DPB181Z - 18V LITIO
search
  • Makita Spare Parts for Band Saw DPB181Z - 18V LITIO
  • Makita Spare Parts for Band Saw DPB181Z - 18V LITIO

Makita Spare Parts for Band Saw DPB181Z - 18V LITIO

€107.37
Tax included

Makita Spare Parts for Band Saw DPB181Z - 18V LITIO

Makita genuine spare parts for the repair or replacement of Band Saw DPB181Z - 18V LITIO.
ITEM CODE: 142686-5
Quantity
on 7/10 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Makita Spare Parts for Band Saw DPB181Z - 18V LITIO

Makita genuine spare parts for the repair or replacement of Band Saw DPB181Z - 18V LITIO.

In the following table, look for the model of Band Saw and the respective parts of the code.
Band Saw DPB181Z - 18V LITIO

Band Saw DPB181Z - 18V LITIO
# Part Num. Description
1 187711-5 HOUSING MOTOR
2 266326-2 SCREW 4x18 X MT601
3 266326-2 SCREW 4x18 X MT601
6 421940-3 COVER FOR MOTOR DC 8390D
8 454650-7 COVER GEAR BOX
9 267855-8 WASHER
10 227331-4 GEAR 14
12 227332-2 GEAR 36
13 227331-4 GEAR 14
15 211242-3 BEARING 6902ZZ X 6413
16 257348-3 RING 15
17 454649-2 GEAR BOX
18 211242-3 BEARING 6902ZZ X 6413
19 961055-9 RETAINING RING S15
21 688172-7 FILTER LINE
22 688172-7 FILTER LINE
23 266326-2 SCREW 4x18 X MT601
25 266326-2 SCREW 4x18 X MT601
30 419504-5 RELEASE BUTTON FOR BPB180
31 454651-5 LEVER SWITCH
32 688172-7 FILTER LINE
34 643899-6 TERMINAL BATTERY
35 266326-2 SCREW 4x18 X MT601
36 961017-7 RING-3 X 4305T
37 256689-4 PIN 4
38 197222-2 PULLEY COVER
39 231955-0 SPRING RETAINER 12 X 5903R
40 272230-5 LEVER 54
41 266326-2 SCREW 4x18 X MT601
42 454614-1 BASE LEVER
43 214408-4 BEARING
44 326351-6 ECCENTRIC
45 142686-5 FRAME
46 922218-2 SCREW M5x14 EBH341U
47 346728-9 PLATE
48 346729-7 LOWER BRACKET
49 266326-2 SCREW 4x18 X MT601
50 234313-9 SPRING COMPRESSION 9
51 256033-5 PIN 6
52 266326-2 SCREW 4x18 X MT601
53 343494-9 SOCKETS 5 X2106W
54 165738-5 SLIDING PLATE
55 267164-5 WASHER 15 HP2040-2041-2042
56 253874-0 FLAT WASHER 4
57 266326-2 SCREW 4x18 X MT601
58 424589-8 RUBBER RING
60 265484-1 BOLT M6x18
61 454730-9 HOOD
62 253010-8 FLAT WASHER 6
63 424589-8 RUBBER RING
65 265484-1 BOLT M6x18
66 454730-9 HOOD
67 253010-8 FLAT WASHER 6
68 251337-0 SCREW M5 X2106W
69 210033-9 BEARING 696ZZ X 2107FK
70 941152-7 FLAT WASHER 6
71 210033-9 BEARING 696ZZ X 2107FK
72 251337-0 SCREW M5 X2106W
73 210033-9 BEARING 696ZZ X 2107FK
74 941152-7 FLAT WASHER 6
75 210033-9 BEARING 696ZZ X 2107FK
76 319075-1 HOLDER TOP 42
77 266326-2 SCREW 4x18 X MT601
78 256033-5 PIN 6
79 210033-9 BEARING 696ZZ X 2107FK
80 210033-9 BEARING 696ZZ X 2107FK
81 941152-7 FLAT WASHER 6
82 210033-9 BEARING 696ZZ X 2107FK
83 251337-0 SCREW M5 X2106W
84 251337-0 SCREW M5 X2106W
85 210033-9 BEARING 696ZZ X 2107FK
86 941152-7 FLAT WASHER 6
87 210033-9 BEARING 696ZZ X 2107FK
88 256033-5 PIN 6
89 210033-9 BEARING 696ZZ X 2107FK
90 266326-2 SCREW 4x18 X MT601
91 319074-3 42 LOWER HOLDER
92 263002-9 RUBBER PIN 4
93 232201-4 SPRING FLAT X PV7000C
94 266326-2 SCREW 4x18 X MT601
95 266326-2 SCREW 4x18 X MT601
97 266213-5 SCREW M5 X 12 X 5621RDW
