Makita Spare Parts for Motor Pump EPH1000X
€1.64
Tax included
Makita Spare Parts for Water Pump EPH1000X
Makita genuine spare parts for the repair or replacement of High Pressure 4 Stroke Water Pump 33,5CC 4T EPH1000X.Fix Your High Pressure 4 Stroke Water Pump 33,5CC 4T EPH1000X. All Spares can be supplied at discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Makita Spare Parts for Water Pump EPH1000X
Makita genuine spare parts for the repair or replacement of High Pressure 4 Stroke Water Pump 33,5CC 4T EPH1000X.
Fix Your High Pressure 4 Stroke Water Pump 33,5CC 4T EPH1000X. All Spares can be supplied at discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of Motor Pump and the respective parts of the code.
| Water Pump EPH1000X | ||
| # | Part Num. | Description |
| 1 | XKO0000128 | COUPLING ASS'Y |
| 2 | K000340065 | COUPLING PACKING |
| 3 | K000340782 | NIPPLE |
| 4 | K000340781 | COUPLING |
| 5 | K940019032 | HOSE BAND |
| 6 | XKO0000170 | MECHANICAL SEAL EPH1000X |
| 7 | K000110114 | WASHER |
| 8 | XKO0120081 | FAN |
| 9 | K000110255 | CASING FAN |
| 10 | K889855042 | O RING |
| 11 | K000118450 | PLUG SET |
| 12 | K000114277 | HANDLE EPH1000X |
| 13 | K000115108 | PUMP CASING |
| 14 | K743119045 | HEX. BOLT |
| 15 | XKO0000120 | PLUG SET |
| 16 | K000113326 | CHECK VALVE |
| 17 | K000113325 | SUCTION FLANGE |
| 18 | K743119046 | HEX. BOLT |
| 19 | K743119032 | HEX. BOLT |
| 20 | K000113837 | SUCTION HOSE |
| 21 | K000118193 | STRAINER SET |
| 22 | K890255031 | O RING |
| 23 | K734532057 | HEX. SOCKET BOLT |
| 24 | K854255006 | SEAL WASHER |
| 25 | K000110256 | FLANGE BRACKET |
| 26 | K000116487 | SPACER |
| 27 | K000117126 | BASE SET |
| 28 | K743119047 | HEX. BOLT |
| 29 | 0119059531 | SOCKET HEAD BOLT M5X16(W.SW) |
| 30 | 5935006000 | HOUSING, BLOWER CP |
| 31 | 0600159970 | BALL BEARING |
| 32 | 0119089970 | SOCKET HEAD BOLT |
| 33 | 0200169970 | WASHER |
| 34 | 5932501200 | SHAFT |
| 35 | 0130069940 | BOLT ASS'Y M6X16(W,SW) |
| 36 | 5937006011 | FLYWHEEL |
| 37 | 0043704200 | SCREW ASS'Y M4X20 |
| 38 | 168816-0 | GYÚJTÁS/BHX2500 |
| 39 | 0654009931 | PIN |
| 40 | 424105-6 | PLUG CAP |
| 41 | 5257018001 | WIRE COMPLETE |
| 42 | 5257500300 | GROMMET |
| 43 | 5929505200 | LABEL, TRADE MARK |
| 44 | 5935500500 | PLUG COVER |
| 45 | 0140059921 | SCREW M5X8 |
| 46 | 0140059370 | SCREW ASS'Y M5X12 |
| 47 | 5935500800 | CYLINDER COVER |
| 48 | 0119059520 | SOCKET HEAD BOLT M5X40 |
| 49 | 0140059962 | SCREW M5X6 |
| 50 | 5923503400 | MUFFLER COVER |
| 51 | 168469-5 | EXHAUST MUFFLER |
| 52 | 5923501601 | MUFFLER GURD |
| 53 | 5923008011 | SPARK ARRESTER |
| 54 | 0043605160 | SCREW ASS'Y M5X16(W,SW) |
| 55 | 5931004000 | ROCKER COVER COMPLETE |
| 56 | 162307-3 | ROCKER COVER GASKET |
| 57 | 0650109950 | SPARK PLUG CMR6A |
| 58 | 5931009000 | CYLINDER BLOCK SET |
| 59 | 424201-0 | CHECK VALVE |
| 60 | 0119059470 | SOCKET HEAD BOLT M5X16 |
| 61 | 266573-5 | SOCKET HEAD BOLT M5X33 |
| 62 | 424200-2 | ALKATRÉSZ/BHX2500 |
| 63 | 162274-2 | CAM GEAR COVER GASKET ER2650LH |
| 64 | 5921500502 | CAMGEAR COVER |
| 65 | 0043605140 | CSAVAR M5X14 RBC250/220/RB |
| 66 | 5926500600 | OIL GAUGE |
| 67 | 0213169990 | GASKET |
| 68 | 5936500100 | CASE GASKET |
| 69 | 374650000 | OIL CASE |
| 70 | 0043605180 | SCREW RST250/RBC250/220/RB |
| 71 | 5921501000 | LEAD VALVE |
| 72 | 5921501100 | RETAINER PLATE |
| 73 | 0119049960 | SOCKET HEAD BOLT M4X10 |
| 74 | 5937500201 | PLATE |
| 75 | 0660000361 | SWITCH |
| 76 | 0043104080 | SCREW M4X8L |
| 77 | 5933500300 | SPRING RETAINER |
| 78 | 5933500200 | VALVE SPRING |
| 79 | 125554-7 | SZELEP HIMBA /BHX2500 |
| 80 | 5933500000 | PUSH ROD |
| 81 | 256200-2 | ROCKER SHAFT |
| 82 | 5933500500 | VALVE |
| 83 | 5933500400 | VALVE |
| 84 | 5923500600 | CAM LIFTER SHAFT |
| 85 | 313169-4 | CAM LIFTER |
| 86 | 125552-1 | CAM GEAR ASS'Y |
| 87 | 5923500501 | CAM GEAR SHAFT |
| 88 | 195141-6 | PISTON RING SET |
| 89 | 233983-1 | CIRCLIP |
| 90 | 318613-6 | PISTON |
| 91 | 5932500900 | PISTON PIN |
| 92 | 212085-6 | NEEDLE ROLLER BEARING |
| 93 | 0323039990 | WOODRUFF KEY |
| 94 | 213537-0 | OIL SEAL (L) |
| 95 | 5932501000 | CLIP |
| 96 | 5932008000 | CRANKSHAFT CT |
| 97 | 213769-9 | OIL SEAL S EM4250 |
| 98 | 125472-9 | FUEL TANK CAP ASS'Y |
| 99 | 5926016000 | CAP, FUEL TANK ASS'Y |
| 100 | 140436-2 | ROD RBC/RBL/RBK/RST, ÚJ |
| 101 | 5196500302 | DAMPER MP352.4Z |
| 102 | 424102-2 | DAMPER MP352.4Z |
| 103 | 424103-0 | DAMPER MP352.4Z |
| 104 | 5936500200 | FUEL TANK |
| 105 | 0561059990 | CLAMP RBC220/22 |
| 106 | 163447-0 | FILTER RST250/RBC250/220/RBL |
| 107 | 162309-9 | TUBE |
| 108 | 195142-4 | COVER STARTER AY |
| 109 | 5315023000 | PULLEY |
| 110 | 5425003010 | SCREW KIT RBC225/255 |
| 111 | 451923-9 | REEL |
| 112 | 232257-7 | SPIRAL SPRING |
| 113 | 5315001030 | STOPPER |
| 114 | 5215002110 | INDÍTÓGOMB RBC225/255 |
| 115 | 5315022040 | STARTER ROPE |
| 116 | 911218-7 | SCREW ASS'Y M5X14 |
| 117 | 5939503800 | LABEL,MODEL |
| 118 | 413120-5 | TÖMÍTÉS |
| 119 | 5923005002 | INSULATOR COMPLETE MCZ |
| 120 | 0021705000 | NUT M5 |
| 121 | 0022706000 | NUT M6 |
| 122 | 0022706000 | NUT M6 |
| 123 | 0149069972 | ADJUST SCREW |
| 124 | 346261-1 | CARBURETOR INSULATOR |
| 125 | 0043605180 | SCREW RST250/RBC250/220/RB |
| 126 | 413138-6 | CARBURATOR GASKET EBH341 |
| 127 | 5926501300 | CLAMP |
| 128 | 0140059370 | SCREW ASS'Y M5X12 |
| 129 | 168783-9 | CARBURETOR |
| 130 | 5236018040 | FORGÓRÉSZ RBL250/RBC225/255 |
| 131 | 5426005030 | WASHER |
| 132 | 5316005120 | RING RBL250/RBC225/255 |
| 133 | 266581-6 | SCREW RBL250/RBC22 |
| 134 | 5926002020 | PUMP SPRING |
| 135 | 5246001010 | GASKET RBL250/RBC225/255 |
| 136 | 5936015010 | JET |
| 137 | 5926002040 | PUMP GASKET |
| 138 | WJ00009599 | DIAPHRAGM RBL250/RBC22 |
| 139 | 266582-4 | PUMP COVER SCREW |
| 140 | 5236046050 | PRIMER PUMP COVER |
| 141 | 424314-7 | PRIMER PUMP |
| 142 | 5236046140 | AIR PURGE BODY ASS'Y |
| 143 | 168574-8 | DIAPHRAGM CPL EBH341U |
| 144 | 442154-1 | DIAPHRAGM GASKET |
| 145 | 5936015020 | BODY-ASSY-PUMP |
| 146 | 5016004010 | BODY PUMP RBL250/RBC225/255 |
| 147 | 0561080010 | HOSE CLAMP |
| 148 | 5931500900 | BREATHER PIPE |
| 149 | 422042-8 | PIPE |
| 150 | 125468-0 | FILTER PLATE BHX2500 |
| 151 | 451925-5 | CHOKE LEVER EM-4250 |
| 152 | 213540-1 | O RING P15 |
| 153 | 424316-3 | CHECK VALVE (1) |
| 154 | 0240139970 | O RING P14 |
| 155 | 451924-7 | CHECK VALVE PLATE |
| 156 | 424315-5 | CHECK VALVE |
| 157 | 168577-2 | GASKET SEPARATOR |
| 158 | 5933501600 | SEPARATOR PLATE |
| 159 | 450560-6 | CHOKE PLATE |
| 160 | 423376-2 | GASKET RBC230 |
| 161 | 345919-9 | PLATE |
| 162 | 265188-5 | SCREW M5X68 (W, SW SUS) |
| 163 | 443141-3 | FILTER EBH341U |
| 164 | 450561-4 | COVER AIR FILTER EM4250 |
| 165 | 911218-7 | SCREW ASS'Y M5X14 |
| 1 | 6255008000 | THROTTLE LEVER X MP352.4 |
| 2 | 0630059920 | THROTTLE CABLE X MP352.4 |
